CYLINDER, CYLINDER HEAD
Parts (34)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A43030138000 Cylinder + Piston cpl. 150 End | Cylinder + Piston cpl. 150 End | 1 | $994.39 | Available | 1 |
| 3 | 0770890200 O-RING 89X2 NBR 70 SH | O-RING 89X2 NBR 70 SH | 1 | $3.99 | Available | 1 |
| 4 | 0770600200 O-RING 60X2 FPM 75SH | O-RING 60X2 FPM 75SH | 1 | $6.15 | Available | 1 |
| 5 | A43030060000 Combustion chamber insert | Combustion chamber insert | 1 | $48.39 | Available | 1 |
| 6 | A42030006100 Cylinder head | Cylinder head | 1 | $34.97 | Available | 1 |
| 7 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | $2.99 | Available | 1 |
| 8 | 0025060106 HH collar screw M6x10 TX30 | HH collar screw M6x10 TX30 | 1 | $3.99 | Available | 1 |
| 9 | 07702300251 O-ring 23.00X2.5 NBR 70 SH | O-ring 23.00X2.5 NBR 70 SH | 1 | $2.99 | Available | 1 |
| 10 | 0603070121 CU-SEAL RING DIN7603- 7,3X12X1 | CU-SEAL RING DIN7603- 7,3X12X1 | 6 | $1.99 | Available | 6 |
| 11 | 50430079000 CYLINDER HEAD SCREW | CYLINDER HEAD SCREW | 6 | $3.99 | Available | 6 |
| 12 | 50330045000 HH COLLAR NUT M 8 WS=12 | HH COLLAR NUT M 8 WS=12 | 4 | $2.99 | Available | 4 |
| 13 | 0835080326 STUD DIN 835 M8X32 | STUD DIN 835 M8X32 | 4 | $2.99 | Available | 4 |
| 14 | A42030035020 Cylinder base gasket | Cylinder base gasket | — | $7.47 | Available | 1 |
| 14 | A42030035025 Cylinder base gasket | Cylinder base gasket | — | $8.13 | Available | 1 |
| 14 | A42030035030 Cylinder base gasket | Cylinder base gasket | — | $8.02 | Available | 1 |
| 14 | A42030035040 Cylinder base gasket | Cylinder base gasket | — | $8.68 | Available | 1 |
| 14 | A42030035050 Cylinder base gasket | Cylinder base gasket | — | $9.12 | Available | 1 |
| 15 | 0402040980 Needle roll.DIN5402 NRB 4X9.8 | Needle roll.DIN5402 NRB 4X9.8 | 2 | $3.99 | Available | 2 |
| 18 | 51005074000 RETAINING PLATE | RETAINING PLATE | 2 | $3.99 | Available | 2 |
| 19 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 4 | $3.99 | Available | 4 |
| 22 | 0025050256 HH COLLAR SCREW M5X25 ISA30 | HH COLLAR SCREW M5X25 ISA30 | 1 | $1.99 | Available | 1 |
| 23 | A42037007000 exhaust regulation cover rh | exhaust regulation cover rh | 1 | $14.95 | Available | 1 |
| 24 | A42037006000 Gasket, control lid left | Gasket, control lid left | 2 | $6.15 | Available | 2 |
| 25 | 0770002226200 X-ring 21.89x2.62 FKM 70 | X-ring 21.89x2.62 FKM 70 | 1 | $2.99 | Available | 1 |
| 26 | A42037005000 exhaust regulation cover lh | exhaust regulation cover lh | 1 | $25.95 | Available | 1 |
| 27 | 78036020090 VACUUM CONNECTION M6 | VACUUM CONNECTION M6 | 1 | $9.01 | Available | 1 |
| 28 | A44030087000 Engine vent hose | Engine vent hose | 1 | $11.54 | Available | 1 |
| 29 | 79435047000 water temperature sensor | water temperature sensor | 1 | $27.93 | Backorder — Restocking | 1 |
| 30 | A45041075000 crank case pressure sensor | crank case pressure sensor | 1 | $58.84 | Available | 1 |
| 31 | A44041087000 Pressure sensor flange | Pressure sensor flange | 1 | $14.18 | Available | 1 |
| 32 | 0017060206 SCREW F. PLASTIC K60X20AL SW6 | SCREW F. PLASTIC K60X20AL SW6 | 1 | $3.99 | Available | 1 |
| 33 | 00050210706 VARIABLE ONE-EAR CLAMP 21,0MM | VARIABLE ONE-EAR CLAMP 21,0MM | 1 | $2.99 | Available | 1 |
| 34 | A45041075050 Pressure sensor EPDM plate | Pressure sensor EPDM plate | 1 | $6.81 | Available | 1 |
| 99 | A42030097000 Sealkit Cylinder MX 125 | Sealkit Cylinder MX 125 | — | $57.41 | Available | 1 |
