ENGINE CASE
Parts (13)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A42030000144 Engine case cpl. | Engine case cpl. | 1 | $652.89 | Available | 1 |
| 2 | A42030025000 Clutch cover gasket, inner | Clutch cover gasket, inner | 1 | $12.42 | Available | 1 |
| 4 | 75030085100 Retaining bracket crankshaft b | Retaining bracket crankshaft b | 1 | $1.99 | Available | 1 |
| 5 | 0019050106S hex lobe countersunc screw M5x | hex lobe countersunc screw M5x | 2 | $2.99 | Available | 2 |
| 6 | 54630027000 DOWEL BUSHING 13,8X11X12 | DOWEL BUSHING 13,8X11X12 | 1 | $8.13 | Available | 1 |
| 7 | 79230010000 Housing bush | Housing bush | 2 | $13.96 | Available | 2 |
| 8 | 54830027100 Dowel, 21x12 | Dowel, 21x12 | 1 | $6.15 | Available | 1 |
| 9 | 58038022000 CU-seal ring DIN7603-12X18X1.5 | CU-seal ring DIN7603-12X18X1.5 | 1 | $2.99 | Available | 1 |
| 10 | 58030021000 OILDRAIN PLUG W.MAG. M 12X1,5 | OILDRAIN PLUG W.MAG. M 12X1,5 | 1 | $13.30 | Available | 1 |
| 11 | 0402040980 Needle roll.DIN5402 NRB 4X9.8 | Needle roll.DIN5402 NRB 4X9.8 | 2 | $3.99 | Available | 2 |
| 12 | 0025060506 HH collar screw M6x50 TX30 | HH collar screw M6x50 TX30 | 11 | $3.99 | Available | 11 |
| 13 | 0025060606 HH collar screw M6x60 TX30 | HH collar screw M6x60 TX30 | 1 | $3.99 | Available | 1 |
| 99 | A42030099100 gasket kit engine 125/150 | gasket kit engine 125/150 | — | $214.93 | Available | 1 |
