SHIFTING MECHANISM
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 79234031100 Shift lever cmpl. | Shift lever cmpl. | 1 | $120.66 | Available | 1 |
| 2 | 0024060156S HH collar screw M6x15 TX30 | HH collar screw M6x15 TX30 | 1 | $2.99 | Available | 1 |
| 4 | 0760142461 SHAFT SEAL RING 14X24X6B VITON | SHAFT SEAL RING 14X24X6B VITON | 1 | $7.80 | Available | 1 |
| 5 | 54632095000 needle sleeve HK 1412 14x20x12 | needle sleeve HK 1412 14x20x12 | 2 | $8.24 | Available | 2 |
| 6 | 54634050000 STOP DISK 14X30X1 | STOP DISK 14X30X1 | 1 | $2.99 | Available | 1 |
| 7 | 54834014000 RETURN SPRING 03 | RETURN SPRING 03 | 1 | $4.99 | Available | 1 |
| 8 | 54634020000 SPRING GUIDE | SPRING GUIDE | 1 | $7.58 | Available | 1 |
| 9 | 56534013100 TENSIONING SPRING 0,8MM | TENSIONING SPRING 0,8MM | 1 | $1.99 | Available | 1 |
| 10 | A46034005033 Shift shaft cpl. | Shift shaft cpl. | 1 | $44.76 | Available | 1 |
| 12 | 58038023400 Compression spring L=25mm D=0. | Compression spring L=25mm D=0. | 4 | $1.99 | Available | 4 |
| 13 | A46034020000 Shift fork shaft (L=66 mm) | Shift fork shaft (L=66 mm) | 1 | $9.23 | Available | 1 |
| 16 | A46034015000 Shift star cmpl. | Shift star cmpl. | 1 | $19.99 | Available | 1 |
| 17 | A47034012000 Shift drum 5 gear | Shift drum 5 gear | 1 | $67.20 | Available | 1 |
| 18 | 0025060306S HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 4 | $3.99 | Available | 4 |
| 20 | A46034024044 Detent arm cmpl. | Detent arm cmpl. | 1 | $13.63 | Available | 1 |
| 21 | 0025050256S HH collar screw M5x25 TX30 | HH collar screw M5x25 TX30 | 7 | $1.99 | Available | 7 |
| 22 | 54634052300 SLEEVE FOR LOCKING LEVER | SLEEVE FOR LOCKING LEVER | 1 | $3.99 | Available | 1 |
| 23 | 54834023000 LOCKING LEVER SPRING 03 | LOCKING LEVER SPRING 03 | 1 | $3.99 | Available | 1 |
| 24 | A46034019000 Shift fork shaft (L=93 mm) | Shift fork shaft (L=93 mm) | 1 | $9.78 | Available | 1 |
| 25 | 79234001000 SHIFTING FORK 4TH/5TH GEAR | SHIFTING FORK 4TH/5TH GEAR | 1 | $91.40 | Available | 1 |
| 26 | 0021050003 washer DIN 9021 A - 5.3 | washer DIN 9021 A - 5.3 | 2 | $1.99 | Available | 2 |
| 27 | 79234002000 SHIFTING FORK 2ND GEAR | SHIFTING FORK 2ND GEAR | 1 | $91.51 | Backorder — Restocking | 1 |
| 28 | 0410002500700 Grooved ball bearing 6805 JR C | Grooved ball bearing 6805 JR C | 1 | $51.69 | Available | 1 |
| 29 | 50233041500 PAIR NORDLOCK WASHER M6 | PAIR NORDLOCK WASHER M6 | 1 | $4.99 | Available | 1 |
| 30 | 79234003000 SHIFTING FORK 1ST/3RD GEAR | SHIFTING FORK 1ST/3RD GEAR | 1 | $91.51 | Available | 1 |
| 31 | 0402061480 NEEDLE ROLLER DIN5402 6X14,8 | NEEDLE ROLLER DIN5402 6X14,8 | 3 | $4.99 | Available | 3 |
| 32 | 79234012010 FRICTION BEARING CONTROLLER | FRICTION BEARING CONTROLLER | 1 | $27.05 | Available | 1 |
| 33 | 79234012020 Magnet bracket cmpl. | Magnet bracket cmpl. | 1 | $69.07 | Backorder — Restocking | 1 |
| 34 | 79211023000 gear position sensor | gear position sensor | 1 | $142.77 | Available | 1 |
| 35 | A46011024000 Shield gear position sensor | Shield gear position sensor | 1 | $7.80 | Available | 1 |
| 36 | 0025050146S Hex coll. screw M5x14 ISA30 se | Hex coll. screw M5x14 ISA30 se | 4 | $1.99 | Available | 4 |
