IGNITION SYSTEM
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 76630002000JA Ignition cover | Ignition cover | 1 | $78.09 | Available | 1 |
| 2 | 49030090000 DOWEL 9,8 X 7 X 10 | DOWEL 9,8 X 7 X 10 | 2 | $2.99 | Available | 2 |
| 3 | 60039040020 generator line bracket | generator line bracket | 1 | $3.99 | Available | 1 |
| 4 | 07700240251 o-ring 24.00x2.50 Viton | o-ring 24.00x2.50 Viton | 1 | $3.99 | Available | 1 |
| 5 | 6003009400030 threaded plug M24x1.5 PA 6.6 | threaded plug M24x1.5 PA 6.6 | 1 | $4.99 | Available | 1 |
| 6 | 75030040000 IGNITI.COVER GASKET 07 | IGNITI.COVER GASKET 07 | 1 | $8.57 | Available | 1 |
| 7 | 75039004100 STATOR | STATOR | 1 | $186.44 | Available | 1 |
| 8 | 76036075050 INSET | INSET | 2 | $8.35 | Available | 2 |
| 9 | 75039005200 ROTOR | ROTOR | 1 | $288.63 | Available | 1 |
| 10 | 0025060166 HH collar screw M6x16 TX30 | HH collar screw M6x16 TX30 | 2 | $3.99 | Available | 2 |
| 11 | 76636075000 STICKCOIL HOLDER | STICKCOIL HOLDER | 1 | $17.81 | Available | 1 |
| 12 | 76039006000 STICK COIL | STICK COIL | 2 | $114.28 | Available | 2 |
| 14 | 60439093000 SPARK PLUG M12X1.25 | SPARK PLUG M12X1.25 | 1 | $32.77 | Available | 1 |
| 15 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 4 | $3.99 | Available | 4 |
| 16 | 0025060306 HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 2 | $3.99 | Available | 2 |
| 17 | 75039034000 PULSER COIL | PULSER COIL | 1 | $78.53 | Available | 1 |
| 18 | 59009062016 SPECIAL SCREW M6X16 WS=8 10.9 | SPECIAL SCREW M6X16 WS=8 10.9 | 2 | $2.99 | Available | 2 |
| 19 | 60439094000 SPARK PLUG | SPARK PLUG | 1 | $35.19 | Available | 1 |
| 13 | 0025060306S HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 3 | $3.99 | Available | 3 |
| 20 | 0025060256S SK-BUNDSCHRAUBE M6X25 ISA30 | SK-BUNDSCHRAUBE M6X25 ISA30 | 1 | $1.99 | Available | 1 |
