COOLING SYSTEM
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 96235010000 Radiator | Radiator | 1 | $274.30 | Available | 1 |
| 2 | 90135016100 RADIATOR CAP | RADIATOR CAP | 1 | $21.24 | Available | 1 |
| 4 | 93335001000 SILENTBLOCK M6 | SILENTBLOCK M6 | 4 | $4.99 | Available | 4 |
| 5 | J926060003 nut hex flange-m6x1xht.6xcl4xb | nut hex flange-m6x1xht.6xcl4xb | 6 | $1.99 | Available | 6 |
| 6 | J127060001 Spring ring B6 | Spring ring B6 | 2 | $1.99 | Available | 2 |
| 7 | J125070004 washer plain-id6.5xod16xthk1xb | washer plain-id6.5xod16xthk1xb | 4 | $1.99 | Available | 4 |
| 8 | 95835041044 Radiator fan, cmpl | Radiator fan, cmpl | 1 | $209.62 | Available | 1 |
| 9 | J900000501900 SCREW TAPPING PAN DIA 4.8 | SCREW TAPPING PAN DIA 4.8 | 6 | $1.99 | Available | 6 |
| 10 | 90135020000 HOSE CLAMP D23 | HOSE CLAMP D23 | 2 | $3.99 | Available | 2 |
| 11 | J310001202900 Spring band clamp D=29 | Spring band clamp D=29 | 2 | $1.99 | Available | 2 |
| 14 | 96335065000 TANK EXPANSION | TANK EXPANSION | 1 | $19.46 | Out of Stock | Notify Me |
| 15 | 90135066000 PLUG F. EXPANSION TANK | PLUG F. EXPANSION TANK | 1 | $3.99 | Available | 1 |
| 16 | 90102055000 COMPENSATING TANK O-RING | COMPENSATING TANK O-RING | 1 | $1.99 | Available | 1 |
| 17 | J912060253 Hexagon socket screw, M6X25 | Hexagon socket screw, M6X25 | 1 | $0.99 | Available | 1 |
| 18 | 96335003000 COVER TANK EXPANSION | COVER TANK EXPANSION | 1 | $6.48 | Backorder — Restocking | 1 |
| 19 | J900000601607 SCREW SOCKET M6X1 | SCREW SOCKET M6X1 | 1 | $0.99 | Available | 1 |
| 22 | 60035067820 drain pipe | drain pipe | 1 | $5.71 | Out of Stock | Notify Me |
| 23 | J600001041700 PIPE COOLANT | PIPE COOLANT | 1 | $4.99 | Backorder — Restocking | 1 |
| 24 | 90107018011 CLAMP 10MM | CLAMP 10MM | 2 | $2.99 | Available | 2 |
| 25 | 95835068000 Strap-clip swivel | Strap-clip swivel | 1 | $3.99 | Available | 1 |
| 26 | J300000801000 Spring clip 9.5 | Spring clip 9.5 | 1 | $1.99 | Available | 1 |
| 12 | 96235026000 Radiator hose | Radiator hose | 1 | $10.00 | Available | 1 |
| 13 | 96235025000 Radiator hose | Radiator hose | 1 | $8.19 | Available | 1 |
| 42 | 96335043010 Radiator Bracket LH | Radiator Bracket LH | 1 | $5.16 | Out of Stock | Notify Me |
