SHOCK ABSORBER DISASSEMBLED
Parts (42)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 50180944S1 MONOSHOCK UPPER PART CPL. | MONOSHOCK UPPER PART CPL. | 1 | — | Obsolete | View Details |
| 2 | 50180213S14 DCC-COMPR.DAMP.CONTROL CPL. 11 | DCC-COMPR.DAMP.CONTROL CPL. 11 | 1 | — | Obsolete | View Details |
| 3 | 46180010 Distance bush 10x15/18/24,5x10 | Distance bush 10x15/18/24,5x10 | 2 | $4.83 | Available | 2 |
| 4 | R12012 Ball joint bearing kit top 12m | Ball joint bearing kit top 12m | 1 | $42.01 | Available | 1 |
| 8 | 50180095 HS cylinder-head screw R1/8 l8 | HS cylinder-head screw R1/8 l8 | 1 | $2.85 | Available | 1 |
| 12 | 52000087 sticker WP warning 47x63 | sticker WP warning 47x63 | 1 | $11.76 | Out of Stock | Notify Me |
| 19 | 46810893 O-ring 5,28x1,78 NBR70 black | O-ring 5,28x1,78 NBR70 black | 1 | $0.76 | Available | 1 |
| 20 | 36120151 HS lock screw M5x6 | HS lock screw M5x6 | 1 | $2.19 | Available | 1 |
| 21 | 46811208 Rubber cap do not open 22x5,5 | Rubber cap do not open 22x5,5 | 1 | $3.62 | Available | 1 |
| 34 | 50180938 Spring retainer M56x2x63,8x33 | Spring retainer M56x2x63,8x33 | 1 | $41.24 | Available | 1 |
| 35 | 50180937 Clamp d64 | Clamp d64 | 1 | — | Obsolete | View Details |
| 36 | 14460042 HS cylinder-head screw M5x20 D | HS cylinder-head screw M5x20 D | 1 | $1.20 | Available | 1 |
| 37 | 50180965 Intermediate washer spring 64, | Intermediate washer spring 64, | 1 | $12.75 | Available | 1 |
| 38 | 50180793 Intermediate washer spring 61, | Intermediate washer spring 61, | 1 | $3.62 | Available | 1 |
| 40 | 91210081S SPRING 260 48 N/MM ORANGE | SPRING 260 48 N/MM ORANGE | — | — | Obsolete | View Details |
| 40 | 91210082S SPRING 260 51N/MM D11,25 OR. | SPRING 260 51N/MM D11,25 OR. | — | — | Obsolete | View Details |
| 40 | 91210083S SPRING 260 54N/MM D11,5 OR. | SPRING 260 54N/MM D11,5 OR. | — | — | Obsolete | View Details |
| 40 | 91210084S SPRING 260 57N/MM D11,75 OR. | SPRING 260 57N/MM D11,75 OR. | — | — | Obsolete | View Details |
| 40 | 91210089S SPRING 260 60 N/MM ORANGE | SPRING 260 60 N/MM ORANGE | — | — | Obsolete | View Details |
| 42 | 50180273 Round-wire snap ring 58,5x2 | Round-wire snap ring 58,5x2 | 1 | $2.41 | Available | 1 |
| 43 | 50180824 Spring retainer 61,5x79,1x7 | Spring retainer 61,5x79,1x7 | 1 | $30.24 | Available | 1 |
| 45 | 50180141 Piston rod nut 16x1 | Piston rod nut 16x1 | 1 | — | Obsolete | View Details |
| 46 | 50180836 Rebound disc 16x34x2 h0 | Rebound disc 16x34x2 h0 | 1 | — | Obsolete | View Details |
| 49 | 50180786S piston 16,05x50x20 cmpl. | piston 16,05x50x20 cmpl. | 1 | $56.42 | Available | 1 |
| 57 | 50180801 Rebound disc 16x43x12,5 h8 | Rebound disc 16x43x12,5 h8 | 1 | — | Obsolete | View Details |
| 57 | 50180961 Rebound disc 16x43x15 h12 | Rebound disc 16x43x15 h12 | 1 | — | Obsolete | View Details |
| 72 | 50180603S3 ADAPTER D50 H28 CPL. | ADAPTER D50 H28 CPL. | 1 | $98.33 | Available | 1 |
| 73 | 50180800 Spring retainer 18,6x43,7x2 re | Spring retainer 18,6x43,7x2 re | 1 | $9.89 | Available | 1 |
| 74 | 50180798 Rubber pad rebound 28,8x48x8 | Rubber pad rebound 28,8x48x8 | 1 | $4.83 | Available | 1 |
| 75 | 50180604 Shim 29.75x19x0.4 | Shim 29.75x19x0.4 | 2 | $2.41 | Available | 2 |
| 76 | 50180605S Seal ring cpl. 18x30x5 | Seal ring cpl. 18x30x5 | 1 | $25.95 | Backorder — Restocking | 1 |
| 77 | 50180780 Spring (3,2) 30-30 | Spring (3,2) 30-30 | 1 | $16.71 | Available | 1 |
| 79 | 50180103 O-ring 41x5 NBR70 | O-ring 41x5 NBR70 | 1 | $1.20 | Available | 1 |
| 80 | 46180119 Guide bushing 18x20x12 | Guide bushing 18x20x12 | 1 | $8.99 | Available | 1 |
| 81 | 50180606 Dirt scarper NOK 18mm black | Dirt scarper NOK 18mm black | 1 | $9.23 | Available | 1 |
| 85 | 50180126 Round-wire snap ring 53x1,75 | Round-wire snap ring 53x1,75 | 1 | $1.20 | Available | 1 |
| 86 | 50180626 Cover 50x6 h16 | Cover 50x6 h16 | 1 | $53.89 | Available | 1 |
| 87 | 50180775 Rubber pad 17x59x64 | Rubber pad 17x59x64 | 1 | $26.39 | Available | 1 |
| 90 | 50180773SA1 MONOSHOCK BOTTOM PART CPL. | MONOSHOCK BOTTOM PART CPL. | 1 | $603.45 | Available | 1 |
| 91 | 46811205 Bush M10x12/15/13x9,5 | Bush M10x12/15/13x9,5 | 1 | $7.91 | Available | 1 |
| 98 | 50180751S1 SHOCK ABSORBER FLUID 5 LT | SHOCK ABSORBER FLUID 5 LT | 1 | $175.99 | Available | 1 |
| 99 | R12018 REPAIR-KIT | REPAIR-KIT | 1 | $76.44 | Available | 1 |
