ENGINE CASE
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 52430000033 ENGINE CASE KPL. 125-200 13 | ENGINE CASE KPL. 125-200 13 | 1 | — | Obsolete | View Details |
| 3 | 52430002100 IGNITION COVER KICKSTART | IGNITION COVER KICKSTART | 1 | $48.06 | Available | 1 |
| 5 | 54630027000 DOWEL BUSHING 13,8X11X12 | DOWEL BUSHING 13,8X11X12 | 1 | $8.13 | Available | 1 |
| 6 | 45230024000 DOWEL 9,8X7X5.5 | DOWEL 9,8X7X5.5 | 2 | $3.99 | Available | 2 |
| 15 | 0025060556 HH collar screw M6x55 TX30 | HH collar screw M6x55 TX30 | 5 | $3.99 | Available | 5 |
| 21 | 58030021000 OILDRAIN PLUG W.MAG. M 12X1,5 | OILDRAIN PLUG W.MAG. M 12X1,5 | 1 | $13.30 | Available | 1 |
| 22 | 45230024000 DOWEL 9,8X7X5.5 | DOWEL 9,8X7X5.5 | 2 | $3.99 | Available | 2 |
| 22 | 58038022000 CU-seal ring DIN7603-12X18X1.5 | CU-seal ring DIN7603-12X18X1.5 | 1 | $2.99 | Available | 1 |
| 39 | 50330039000 ENGINE CASE GASKET 0,5MM '98 | ENGINE CASE GASKET 0,5MM '98 | 1 | $19.02 | Available | 1 |
| 42 | 0025060506 HH collar screw M6x50 TX30 | HH collar screw M6x50 TX30 | 11 | $3.99 | Available | 11 |
| 43 | 0025060556 HH collar screw M6x55 TX30 | HH collar screw M6x55 TX30 | 5 | $3.99 | Available | 5 |
| 44 | 0025060206 HH collar screw M6x20 TX30 | HH collar screw M6x20 TX30 | 6 | $3.99 | Available | 6 |
| 45 | 0025060606 HH collar screw M6x60 TX30 | HH collar screw M6x60 TX30 | 1 | $3.99 | Available | 1 |
| 46 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 4 | $3.99 | Available | 4 |
| 92 | 50330092000 OIL GUARD GROMMET 25X31 '98 | OIL GUARD GROMMET 25X31 '98 | 1 | — | Obsolete | View Details |
| 99 | 50330099200 GASKET KIT 125 07 | GASKET KIT 125 07 | 1 | $326.03 | Available | 1 |
