SHOCK ABSORBER DISASSEMBLED
Parts (56)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 18 | 46811077 ADAPTOR BUSH KGW 10X22 | ADAPTOR BUSH KGW 10X22 | 2 | $23.29 | Obsolete | View Details |
| 19 | 46811050 SEAL KGW | SEAL KGW | 4 | $9.56 | Available | 4 |
| 22 | 36120135 BUMP RUBBER WP65 RED | BUMP RUBBER WP65 RED | 1 | $30.09 | Obsolete | View Details |
| 23 | 36120650 SCREW CAP M37,65 STEEL | SCREW CAP M37,65 STEEL | 1 | $108.19 | Obsolete | View Details |
| 24 | 46811044 DUST SEAL 1424 | DUST SEAL 1424 | 1 | $23.31 | Obsolete | View Details |
| 25 | 36120064 O-ring 29,74x3,53 NBR70 | O-ring 29,74x3,53 NBR70 | 1 | $2.19 | Out of Stock | Notify Me |
| 26 | 36120522S1 ADAPTER CPL. D=36 H=20,5 | ADAPTER CPL. D=36 H=20,5 | 1 | $123.99 | Out of Stock | Notify Me |
| 27 | 36120469 SHIM 28,5X14X2 | SHIM 28,5X14X2 | 1 | $12.42 | Available | 1 |
| 30 | 36120726 SHOCK ABSORB.CASE PGB KGW H=33 | SHOCK ABSORB.CASE PGB KGW H=33 | 1 | $264.64 | Obsolete | View Details |
| 31 | 0770380020 O-RING 38,00X2,00 NBR 70 SH | O-RING 38,00X2,00 NBR 70 SH | 3 | $3.99 | Available | 3 |
| 32 | 36120137 TUBE L=167 | TUBE L=167 | 1 | $83.73 | Obsolete | View Details |
| 33 | 36120019 Bush M40x1xM44x1,5x70 | Bush M40x1xM44x1,5x70 | 1 | $34.19 | Obsolete | View Details |
| 34 | 36120467 PROTECTION SLEEVE L=40 | PROTECTION SLEEVE L=40 | 1 | $21.54 | Obsolete | View Details |
| 41 | 36120015 Lock nut shock M44x1,5 | Lock nut shock M44x1,5 | 1 | $36.18 | Available | 1 |
| 42 | 36120418 Adjustment nut shock M44x1,5 | Adjustment nut shock M44x1,5 | 1 | $53.78 | Available | 1 |
| 1 | 46811525 SHOCK ABS. BOTTOM L=46 | SHOCK ABS. BOTTOM L=46 | 1 | $256.71 | Obsolete | View Details |
| 2 | 36120586S PISTON ROD D=14, L=126 | PISTON ROD D=14, L=126 | 1 | $446.49 | Obsolete | View Details |
| 3 | 46811401S NEEDLE CPL. D=4, L=142 | NEEDLE CPL. D=4, L=142 | 1 | $132.39 | Obsolete | View Details |
| 4 | 46811222 O-RING 36X0,5 | O-RING 36X0,5 | 1 | $2.79 | Obsolete | View Details |
| 5 | 46811263 WASHER | WASHER | 1 | $12.19 | Obsolete | View Details |
| 6 | 46811261 PIN 4X35 | PIN 4X35 | 1 | $4.55 | Obsolete | View Details |
| 7 | 46811262 ADJ. KNOB D=41 | ADJ. KNOB D=41 | 1 | $15.17 | Obsolete | View Details |
| 10 | 46811221 Shaft seal 29x35x3 | Shaft seal 29x35x3 | 1 | $13.79 | Obsolete | View Details |
| 11 | 46811367 INTERMEDIATO RING H=4 | INTERMEDIATO RING H=4 | 1 | $36.29 | Obsolete | View Details |
| 12 | 46811268 CIRCLIP 22X1,2 | CIRCLIP 22X1,2 | 1 | $1.93 | Obsolete | View Details |
| 13 | 46811259 NEEDLE SEAT 5X17,25 | NEEDLE SEAT 5X17,25 | 1 | $84.69 | Obsolete | View Details |
| 16 | 46811076 ADAPTOR BUSH KGW 10X20 | ADAPTOR BUSH KGW 10X20 | 2 | $15.89 | Out of Stock | Notify Me |
| 77 | 36120040 Pistonring 33x35x8 | Pistonring 33x35x8 | 1 | $8.13 | Available | 1 |
| 78 | 46811267 BUSHING 6X9X3 | BUSHING 6X9X3 | 1 | — | Check availability | |
| 79 | 46811251 BLEED SCREW M 4X6 | BLEED SCREW M 4X6 | 1 | $4.74 | Obsolete | View Details |
| 80 | 36120604 Washer 10x22x2,5 | Washer 10x22x2,5 | 1 | $24.52 | Special Order | 1 |
| 81 | 40540450 Shim 6x9,5x0,30 | Shim 6x9,5x0,30 | 1 | $2.41 | Available | 1 |
| 82 | 40540403 Shim 6x18x0,10 | Shim 6x18x0,10 | 4 | $2.41 | Available | 4 |
| 83 | 36120605S2 PISTON ROD NUT CPL. H=15,2 | PISTON ROD NUT CPL. H=15,2 | 1 | — | Check availability | |
| 85 | 36120631 RESERVOIR SCREW L=98 GREY | RESERVOIR SCREW L=98 GREY | 1 | $177.07 | Obsolete | View Details |
| 86 | 36120024 Piston 42mm reservoir | Piston 42mm reservoir | 1 | $37.40 | Obsolete | View Details |
| 87 | 36120466 O-ring 32x5 Viton70 | O-ring 32x5 Viton70 | 1 | $9.92 | Available | 1 |
| 88 | 46810022 Piston ring 36,5x39,5x3,9 | Piston ring 36,5x39,5x3,9 | 1 | $19.24 | Available | 1 |
| 89 | 36120552 SCREW FOR RESERVOIR CAP M5 | SCREW FOR RESERVOIR CAP M5 | 1 | $52.61 | Obsolete | View Details |
| 90 | 46810850S7 CC-COMPRE.DAMPING CONTROL CPL. | CC-COMPRE.DAMPING CONTROL CPL. | 1 | — | Check availability | |
| 91 | 46810334 LOCK WASHER JV24 | LOCK WASHER JV24 | 1 | $1.93 | Obsolete | View Details |
| 92 | 46810333 Steel ball 4.75mm | Steel ball 4.75mm | 1 | $1.22 | Obsolete | View Details |
| 93 | 50180131S ADJUSTING KNOB CC-MECH. CPL. | ADJUSTING KNOB CC-MECH. CPL. | 1 | $29.57 | Obsolete | View Details |
| 94 | 50180095 HS cylinder-head screw R1/8 l8 | HS cylinder-head screw R1/8 l8 | 1 | $2.85 | Available | 1 |
| 43 | 40540015 Round-wire snap ring 38x1,5 | Round-wire snap ring 38x1,5 | 1 | $3.62 | Available | 1 |
| 45 | 46810893 O-ring 5,28x1,78 NBR70 black | O-ring 5,28x1,78 NBR70 black | 1 | $1.04 | Obsolete | View Details |
| 46 | 36120151 HS lock screw M5x6 | HS lock screw M5x6 | 1 | $2.19 | Available | 1 |
| 47 | 93010181S SPRING 40N/MM 40-220 220MM ORA | SPRING 40N/MM 40-220 220MM ORA | 1 | $190.56 | Obsolete | View Details |
| 47 | 93010182S SPRING 35N/MM 35-220 220MM ORA | SPRING 35N/MM 35-220 220MM ORA | 0 | $153.71 | Obsolete | View Details |
| 48 | 36120386 Spring retainer 27x57x2 | Spring retainer 27x57x2 | 1 | $31.78 | Available | 1 |
| 49 | 46811208 Rubber cap do not open 22x5,5 | Rubber cap do not open 22x5,5 | 1 | $3.62 | Available | 1 |
| 50 | 50180342S1 SHOCK ABSORBER FLUID 5 LT '03 | SHOCK ABSORBER FLUID 5 LT '03 | 1 | $165.36 | Obsolete | View Details |
| 60 | 36120557 REBOUND BUSH H=5,6 | REBOUND BUSH H=5,6 | 1 | — | Check availability | |
| 75 | 36120603 PISTON 6+6XD=5,5/3,5 BA | PISTON 6+6XD=5,5/3,5 BA | 1 | $94.19 | Obsolete | View Details |
| 47 | 93010183S SPRING 45N/MM 45-220 220MM ORA | SPRING 45N/MM 45-220 220MM ORA | 0 | $161.39 | Special Order | 1 |
| 17 | 46811027 Ball joint bearing 15x25x13 | Ball joint bearing 15x25x13 | 2 | $22.90 | Obsolete | View Details |
