FRONT FORK DISASSEMBLED
Parts (41)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 0025060306 HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 2 | — | Check availability | |
| 2 | 7819139/C SLIDER + AXLE CLAMP CPL. R/S | SLIDER + AXLE CLAMP CPL. R/S | 1 | — | Check availability | View Details |
| 3 | 7538029 GUIDE RING D=35 | GUIDE RING D=35 | 2 | — | Check availability | View Details |
| 4 | 7717065/R FOOT VALVE | FOOT VALVE | 2 | — | Check availability | View Details |
| 5 | 7528005 O-RING D=20,3 | O-RING D=20,3 | 2 | — | Check availability | |
| 6 | 7521092/D SPECIAL NUT M6X1 WITH STEP | SPECIAL NUT M6X1 WITH STEP | 1 | — | Check availability | |
| 7 | 7517217 REED VALVE 22X8,1X0,1 | REED VALVE 22X8,1X0,1 | 4 | — | Check availability | View Details |
| 8 | 7530097/B PISTON REBOUND D=26 | PISTON REBOUND D=26 | 1 | — | Check availability | |
| 9 | 7524163 PISTON RING D=26 | PISTON RING D=26 | 1 | — | Check availability | View Details |
| 11 | 75141087 LOWER REBOUND SPRING | LOWER REBOUND SPRING | 2 | — | Check availability | |
| 13 | 75321033 PIN 8X30 | PIN 8X30 | 2 | — | Check availability | View Details |
| 14 | 75181140/R TUBE BODY R/S | TUBE BODY R/S | 1 | — | Check availability | View Details |
| 15 | 7523224 STOP RING 10X1 | STOP RING 10X1 | 2 | — | Check availability | View Details |
| 16 | 75181153 GUIDE BUSH 6,4X12X12 | GUIDE BUSH 6,4X12X12 | 2 | — | Check availability | View Details |
| 17 | 7521005 SPECIAL NUT | SPECIAL NUT | 2 | — | Check availability | |
| 19 | 7701196 PLUG CPL. | PLUG CPL. | 2 | — | Check availability | |
| 20 | 7850208AR LENTIL HEAD SCREW M4X6 | LENTIL HEAD SCREW M4X6 | 2 | — | Check availability | View Details |
| 21 | 7528180 O-RING D=3,69, S=1,78 | O-RING D=3,69, S=1,78 | 2 | — | Check availability | |
| 22 | 7528008 O-RING D=34,6, S=1,78 | O-RING D=34,6, S=1,78 | 2 | — | Check availability | |
| 24 | 7850728 SPRINGS + PRELOAD SLEEVES KIT | SPRINGS + PRELOAD SLEEVES KIT | 1 | — | Check availability | |
| 25 | 7533167 DUST CAP | DUST CAP | 2 | — | Check availability | |
| 26 | 7523236 LOCK WASHER D=51,5 | LOCK WASHER D=51,5 | 2 | — | Check availability | View Details |
| 27 | 7528034 OIL SEAL 35X47X10 | OIL SEAL 35X47X10 | 2 | — | Check availability | View Details |
| 28 | 7539032AA WASHER 36X47X3 | WASHER 36X47X3 | 2 | — | Check availability | |
| 29 | 7538038/A GUIDE RING 35X15 | GUIDE RING 35X15 | 2 | — | Check availability | View Details |
| 30 | 7760069FN/C OUTER TUBE CPL. | OUTER TUBE CPL. | 2 | — | Check availability | View Details |
| 33 | 7514077 TOP REBOUND SPRING | TOP REBOUND SPRING | 2 | — | Check availability | |
| 36 | 75181139/R TUBE BODY L/S | TUBE BODY L/S | 1 | — | Check availability | |
| 38 | 7535099 COMPRESSION DAMPING SHIM | COMPRESSION DAMPING SHIM | 1 | — | Check availability | View Details |
| 39 | 7517082 SHIM 8,1X23X0,1 | SHIM 8,1X23X0,1 | 1 | — | Check availability | |
| 39 | 7517057 SHIM 8,1X21X0,2 | SHIM 8,1X21X0,2 | 1 | — | Check availability | View Details |
| 39 | 7517249 SHIM 8,1X23X0,15 | SHIM 8,1X23X0,15 | 1 | — | Check availability | |
| 40 | 7530090/B PISTON COMPRESSION D=26 | PISTON COMPRESSION D=26 | 1 | — | Check availability | View Details |
| 42 | 7521147/A SPECIAL NUT M6X1 WITH STEP | SPECIAL NUT M6X1 WITH STEP | 1 | — | Check availability | View Details |
| 43 | 7819140/C SLIDER + AXLE CLAMP CPL. L/S | SLIDER + AXLE CLAMP CPL. L/S | 1 | — | Check availability | View Details |
| 46 | 7522061 SHIM 8X12X1,5 | SHIM 8X12X1,5 | 2 | — | Check availability | |
| 47 | 0912080253 AH SCREW DIN0912-M 8X25 | AH SCREW DIN0912-M 8X25 | 2 | — | Check availability | |
| 48 | 7517044 SHIM 8,1X23X0,3 | SHIM 8,1X23X0,3 | 2 | — | Check availability | |
| 90 | 7550013 FORKOIL EBH16 SAE 7.5 | FORKOIL EBH16 SAE 7.5 | 1 | — | Check availability | |
| 99 | 7850731/C REPAIR-KIT USD 35 | REPAIR-KIT USD 35 | 1 | — | Check availability | View Details |
| 39 | 7517248 SHIM 8,1X22X0,2 | SHIM 8,1X22X0,2 | 1 | — | Check availability |
