FRAME
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 45203001300BE FRAME ''452L3'' ANTHR. MET. | FRAME ''452L3'' ANTHR. MET. | 1 | — | Check availability | View Details |
| 2 | 54310086200 Self locking nut M8 10.9 | Self locking nut M8 10.9 | 2 | — | Check availability | |
| 3 | 0025080656 HH collar screw M8x65 TX40 | HH collar screw M8x65 TX40 | 2 | — | Check availability | |
| 4 | 51103053000 CHAIN SLIDING PIECE BELOW '97 | CHAIN SLIDING PIECE BELOW '97 | 1 | — | Check availability | |
| 5 | 51103053051 BUSHING 8,2X10X20 | BUSHING 8,2X10X20 | 1 | — | Check availability | |
| 6 | 36003014000 LOCK WASHER 8MM | LOCK WASHER 8MM | 2 | — | Check availability | |
| 7 | 0025080306 HH collar screw M8x30 | HH collar screw M8x30 | 1 | — | Check availability | |
| 8 | 47103040033 FOOTREST CPL. 14 | FOOTREST CPL. 14 | 1 | — | Check availability | |
| 9 | 47103040000 FOOTREST L/S | FOOTREST L/S | 1 | — | Check availability | |
| 10 | 47103041000 FOOTREST R/S | FOOTREST R/S | 1 | — | Check availability | |
| 11 | 54803044000 PIN FOR FOOT PED 51.5X9.8 MM | PIN FOR FOOT PED 51.5X9.8 MM | 2 | — | Check availability | |
| 12 | 54603041000 FOOTREST SPRING L/S & R/S | FOOTREST SPRING L/S & R/S | 2 | — | Check availability | |
| 13 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 2 | — | Check availability | |
| 14 | 0094032253 PIN DIN0094-3,2X25 STEEL | PIN DIN0094-3,2X25 STEEL | 2 | — | Check availability | View Details |
| 99 | 51103053110 CHAIN SLIDING KIT BELOW MINI | CHAIN SLIDING KIT BELOW MINI | 1 | — | Check availability |
