SHOCK ABSORBER DISASSEMBLED
Parts (21)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 5 | 36120015 Lock nut shock M44x1,5 | Lock nut shock M44x1,5 | 1 | — | Check availability | |
| 6 | 36120418 Adjustment nut shock M44x1,5 | Adjustment nut shock M44x1,5 | 1 | — | Check availability | |
| 7 | 93010175S SPRING 35N/MM 35-130 130MM OR. | SPRING 35N/MM 35-130 130MM OR. | 0 | — | Check availability | |
| 7 | 93010176S SPRING 30N/MM 30-130 130MM OR. | SPRING 30N/MM 30-130 130MM OR. | 0 | — | Check availability | |
| 7 | 93010177S SPRING 40N/MM 40-130 130MM OR. | SPRING 40N/MM 40-130 130MM OR. | 0 | — | Check availability | |
| 8 | 36120386 Spring retainer 27x57x2 | Spring retainer 27x57x2 | 1 | — | Check availability | |
| 9 | 36120052 Piston rod nut M10x1 black | Piston rod nut M10x1 black | 1 | — | Check availability | |
| 10 | 36120604 Washer 10x22x2,5 | Washer 10x22x2,5 | 1 | — | Check availability | |
| 11 | 36120040 Pistonring 33x35x8 | Pistonring 33x35x8 | 1 | — | Check availability | |
| 12 | 36120071 Piston 10,5x35,6x13,65 3,5/5,5 | Piston 10,5x35,6x13,65 3,5/5,5 | 1 | — | Check availability | |
| 13 | 14360065 Rebound disc 12x28,5x4 h0 | Rebound disc 12x28,5x4 h0 | 1 | — | Check availability | |
| 14 | 36120787S Sealholder 36x26,6 cpl. | Sealholder 36x26,6 cpl. | 1 | — | Check availability | |
| 15 | 40540015 Round-wire snap ring 38x1,5 | Round-wire snap ring 38x1,5 | 1 | — | Check availability | |
| 16 | 36120780 Cover 36,12x5,5 h13 | Cover 36,12x5,5 h13 | 1 | — | Check availability | |
| 17 | 36120427 Rubber pad 14x34x19 | Rubber pad 14x34x19 | 1 | — | Check availability | |
| 18 | 36120776S1 MONOSH. BOTTOM PART L99 CPL.07 | MONOSH. BOTTOM PART L99 CPL.07 | 1 | — | Check availability | |
| 90 | 50180342S1 SHOCK ABSORBER FLUID 5 LT '03 | SHOCK ABSORBER FLUID 5 LT '03 | 1 | — | Check availability | View Details |
| 1 | 36120783S MONOSHOCK TOP PART L147 CPL.07 | MONOSHOCK TOP PART L147 CPL.07 | 1 | — | Check availability | |
| 2 | R307 REPAIR KIT BEARINGS 50 SX 07 | REPAIR KIT BEARINGS 50 SX 07 | 2 | — | Check availability | |
| 3 | 36120785 SCREW M5 C.K. RVS | SCREW M5 C.K. RVS | 1 | — | Check availability | |
| 4 | 36120782 SEAL D5,21XD8,38X1,22 | SEAL D5,21XD8,38X1,22 | 1 | — | Check availability |
