FRONT FORK DISASSEMBLED

← →

Parts (23)

#	Part Number	Description	Qty	Price	Status
8	7504212AC PLUG CAP	PLUG CAP	2	—	Obsolete	View Details
9	7528010 O-RING	O-RING	2	—	Obsolete	View Details
11	7518076 PRE LOAD BUSH 25X2,5X100	PRE LOAD BUSH 25X2,5X100	2	—	Obsolete	View Details
12	75141169 SPRING 2N/MM	SPRING 2N/MM	2	—	Obsolete	View Details
12	75141214 SPRING 2,5N/MM	SPRING 2,5N/MM	—	—	Obsolete	View Details
13	7533297 DUST SEAL	DUST SEAL	2	—	Obsolete	View Details
14	7523264 STOP RING	STOP RING	2	—	Obsolete	View Details
15	7528230 OIL SEAL 32/42/6,5-9,5	OIL SEAL 32/42/6,5-9,5	2	—	Obsolete	View Details
16	7522166AA WASHER D42X32,5X1,5	WASHER D42X32,5X1,5	2	—	Obsolete	View Details
17	7524157 PISTON RING D32	PISTON RING D32 ONLY FOR REBOUND DAMPING	1	—	Obsolete	View Details
19	75141015 REBOUND SPRING	REBOUND SPRING	2	—	Obsolete	View Details
20	75031570A SLIDER L/S 50 LC 2002	SLIDER L/S 50 LC 2002	1	—	Obsolete	View Details
21	75031570A/R SLIDER CPL. L/S 50LC 2002	SLIDER CPL. L/S 50LC 2002	1	—	Obsolete	View Details
22	7522225 WASHER 14X8X1,5	WASHER 14X8X1,5	2	—	Obsolete	View Details
23	0912080303 AH SCREW DIN0912-M 8X30	AH SCREW DIN0912-M 8X30	2	$2.99	Available	2
26	7708249/R FORK TUBE R/S SENIOR 02	FORK TUBE R/S SENIOR 02	1	—	Obsolete	View Details
27	7708250/R FORK TUBE L/S SENIOR 02	FORK TUBE L/S SENIOR 02	1	—	Obsolete	View Details
28	7512068 FOOT BUFFER	FOOT BUFFER	2	—	Obsolete	View Details
29	75031571A SLIDER R/S 50 LC 2002	SLIDER R/S 50 LC 2002	1	—	Obsolete	View Details
31	75031571A/R SLIDER CPL. R/S 50LC 2002	SLIDER CPL. R/S 50LC 2002	1	—	Obsolete	View Details
40	7547325 STICKER LEFT SIDE MARZOCCHI	STICKER LEFT SIDE MARZOCCHI	1	—	Obsolete	View Details
40	7547331 STICKER RIGHT SIDE MARZOCCHI	STICKER RIGHT SIDE MARZOCCHI	1	—	Obsolete	View Details
98	7550013 FORKOIL EBH16 SAE 7.5	FORKOIL EBH16 SAE 7.5	1	—	Obsolete	View Details
