REED VALVE CASE
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 2 | 46230151044 REED VALVE ASSY CPL. | REED VALVE ASSY CPL. | 1 | — | Check availability | |
| 3 | 46230152028 Membrane | Membrane | 1 | — | Check availability | |
| 4 | 45230150000 INTAKE FLANGE | INTAKE FLANGE | 1 | — | Check availability | |
| 5 | 0025060206 HH collar screw M6x20 TX30 | HH collar screw M6x20 TX30 | 2 | — | Check availability | |
| 7 | 31008060000 rubber grommet D=8mm open | rubber grommet D=8mm open | 2 | — | Check availability | |
| 8 | 45239060050 COLLAR BUSHING 6,3X8X13X9,5 | COLLAR BUSHING 6,3X8X13X9,5 | 2 | — | Check availability | |
| 9 | 0025060306 HH collar screw M6x30 TX30 | HH collar screw M6x30 TX30 | 2 | — | Check availability | |
| 10 | 76235028000 Hose clamp GEMI 20-32 | Hose clamp GEMI 20-32 | 1 | — | Check availability | |
| 6 | 45239010000 IGNIT. COIL RETAIN. PLATE CPL. | IGNIT. COIL RETAIN. PLATE CPL. | 1 | — | Check availability | |
| 1 | 46230049000 GASKET MEMBRAN CASE | GASKET MEMBRAN CASE | 1 | — | Check availability |
