FRONT FORK DISASSEMBLED
Parts (54)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 46 | 48600525 Spring retainer 12,3x19x1,25 r | Spring retainer 12,3x19x1,25 r | 2 | — | Check availability | |
| 1 | 43570395S SCREW CAP M51X1,5 CPL. | SCREW CAP M51X1,5 CPL. | 2 | — | Check availability | View Details |
| 2 | 46811042 O-ring 40x2 NBR70 black | O-ring 40x2 NBR70 black | 2 | — | Check availability | |
| 3 | 48600564S SETTING KNOB + SCREW | SETTING KNOB + SCREW | 2 | — | Check availability | View Details |
| 8 | 48600481 Cross countersunk head screw M | Cross countersunk head screw M | 2 | — | Check availability | |
| 9 | 48600046 O-ring 3x1,5 NBR70 | O-ring 3x1,5 NBR70 | 2 | — | Check availability | |
| 12 | 43570254E OUTER TUBE L=510 D=49/53 BLACK | OUTER TUBE L=510 D=49/53 BLACK | 2 | — | Check availability | View Details |
| 13 | 43570099 Round-wire snap ring 53x2 | Round-wire snap ring 53x2 | 2 | — | Check availability | |
| 15 | 43570204 pilot bushing 43x47x12 | pilot bushing 43x47x12 | 2 | — | Check availability | View Details |
| 16 | 43570092 Supportwasher 45x52,5x1,5 | Supportwasher 45x52,5x1,5 | 2 | — | Check availability | |
| 17 | 43570201 Seal ring 43x52,9x9,5 | Seal ring 43x52,9x9,5 | 2 | — | Check availability | View Details |
| 18 | 43570008 Snap ring SB53x1,5 acc drawing | Snap ring SB53x1,5 acc drawing | 2 | — | Check availability | |
| 19 | 43570202 Dirtscarper NOK 43mm | Dirtscarper NOK 43mm | 2 | — | Check availability | View Details |
| 22 | 43570203 Guide bushing 42x44x20 | Guide bushing 42x44x20 | 2 | — | Check availability | View Details |
| 24 | 43570396S Stop 12,4x28,6x135 cpl. | Stop 12,4x28,6x135 cpl. | 2 | — | Check availability | |
| 30 | 48600695 Adjustment tube 6x442 | Adjustment tube 6x442 | 2 | — | Check availability | |
| 31 | 48600694 Piston rod 12x476 | Piston rod 12x476 | 2 | — | Check availability | |
| 33 | 48600277 Needle 4,5x43,6 | Needle 4,5x43,6 | 2 | — | Check availability | |
| 34 | 48600298 O-ring 2x1,5 NBR70 | O-ring 2x1,5 NBR70 | 2 | — | Check availability | |
| 35 | 48600444 Spring (5,4) 4-23 rebound | Spring (5,4) 4-23 rebound | 2 | — | Check availability | |
| 37 | 43570133 Preload bush 26,5x38x2,5 | Preload bush 26,5x38x2,5 | 2 | — | Check availability | |
| 37 | 43570134 Preload bush 26x35x4 | Preload bush 26x35x4 | 2 | — | Check availability | |
| 37 | 43570135 Preload bush 26x38x10 | Preload bush 26x38x10 | 2 | — | Check availability | |
| 37 | 43570136 Preload bush 26,5x38x1,5 | Preload bush 26,5x38x1,5 | 2 | — | Check availability | |
| 38 | 95010032S SPRING 3,4 N/MM SET D=4,4MM | SPRING 3,4 N/MM SET D=4,4MM | 0 | — | Check availability | |
| 38 | 95010033S SPRING 3,6 N/MM SET | SPRING 3,6 N/MM SET | 0 | — | Check availability | |
| 38 | 95010031S SPRING 3,2 N/MM SET D=4,2MM | SPRING 3,2 N/MM SET D=4,2MM | 0 | — | Check availability | |
| 39 | 43570131 Spring retainer 33,5x38,2x3 | Spring retainer 33,5x38,2x3 | 2 | — | Check availability | |
| 42 | 48600600S1 SCREW SLEEVE M29,3X1 L65 CPL. | SCREW SLEEVE M29,3X1 L65 CPL. | 2 | — | Check availability | |
| 43 | 48600299 O-ring 6x1,2 NBR70 | O-ring 6x1,2 NBR70 | 2 | — | Check availability | |
| 44 | 48600511 Spring (13,9) 17-32 rebound | Spring (13,9) 17-32 rebound | 2 | — | Check availability | View Details |
| 45 | 48600513 TAP REBOUND 07 | TAP REBOUND 07 | 2 | — | Check availability | |
| 47 | 48600382 Spring (11,4) 0,4-8 valve | Spring (11,4) 0,4-8 valve | 2 | — | Check availability | |
| 51 | 48600060 Pistonring 26x28x5 | Pistonring 26x28x5 | 2 | — | Check availability | |
| 52 | 48600042 Piston 6,05x27,65x12 rebound | Piston 6,05x27,65x12 rebound | 2 | — | Check availability | |
| 55 | 40540486 Nut M6x0,5 h6,5 WAF10 rebound | Nut M6x0,5 h6,5 WAF10 rebound | 2 | — | Check availability | |
| 58 | 48600353 TUBE 29,3X1X370 D=8,5MM ALU | TUBE 29,3X1X370 D=8,5MM ALU | 2 | — | Check availability | View Details |
| 59 | 43570023 O-ring 41x2 NBR70 siliconized | O-ring 41x2 NBR70 siliconized | 2 | — | Check availability | |
| 60 | 43570214S1 AXLE CLAMP L/S + TUBE CPL. 08 | AXLE CLAMP L/S + TUBE CPL. 08 | 1 | — | Check availability | View Details |
| 61 | 43570213S1 AXLE CLAMP R/S + TUBE CPL.08 | AXLE CLAMP R/S + TUBE CPL.08 | 1 | — | Check availability | View Details |
| 62 | 0015060203 HH COLLAR SCREW M 6X20 WS=8 | HH COLLAR SCREW M 6X20 WS=8 | 4 | — | Check availability | View Details |
| 63 | 48600163 Nut valve M6x0,5 h6,5 WAF17 | Nut valve M6x0,5 h6,5 WAF17 | 2 | — | Check availability | |
| 64 | 48600202 Spring (8,5) l6,5 valve | Spring (8,5) l6,5 valve | 2 | — | Check availability | |
| 69 | 48600586S Tap compression cpl. | Tap compression cpl. | 2 | — | Check availability | View Details |
| 71 | 48600047 Piston 6x27,8x9 compression | Piston 6x27,8x9 compression | 2 | — | Check availability | |
| 72 | 46811499 O-ring 21x2 NBR70 | O-ring 21x2 NBR70 | 2 | — | Check availability | |
| 73 | 35480320 O-ring 24x2 NBR70 | O-ring 24x2 NBR70 | 2 | — | Check availability | |
| 76 | 48600049 O-ring 8x2 NBR70 | O-ring 8x2 NBR70 | 2 | — | Check availability | |
| 81 | 48600004 Copper disc 29,5x33,5x1 | Copper disc 29,5x33,5x1 | 2 | — | Check availability | |
| 82 | 48600141 Rubber cap 35x10 NBR80 | Rubber cap 35x10 NBR80 | 2 | — | Check availability | |
| 83 | 48600401S1 FORK OIL SAE5 5L 2005 | FORK OIL SAE5 5L 2005 | 1 | — | Check availability | View Details |
| 98 | T511 SILICONE GREASE F. DUST STRI | SILICONE GREASE F. DUST STRI | 1 | — | Check availability | View Details |
| 99 | R510 REPAIR-KIT GASKET 4357 MXMA 03 | REPAIR-KIT GASKET 4357 MXMA 03 | 1 | — | Check availability | View Details |
| 41 | 48600430 Guide bushing 12x14x10 | Guide bushing 12x14x10 | 2 | — | Check availability |
