ENGINE CASE
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 47030000044 ENGINE CASE CPL. 85 SX 2003 | ENGINE CASE CPL. 85 SX 2003 | 1 | $461.00 | Available | 1 |
| 2 | 47030001100 CLUTCH COVER 85 SX 06 | CLUTCH COVER 85 SX 06 | 1 | $200.41 | Available | 1 |
| 18 | 0603101420 COPPER GASKET 10,2X14X2 MM 01 | COPPER GASKET 10,2X14X2 MM 01 | 1 | $3.99 | Available | 1 |
| 19 | 0770160030 O-RING 16,00X3,00 NBR 70 | O-RING 16,00X3,00 NBR 70 | 1 | $2.99 | Available | 1 |
| 20 | 58030020000 PLUG M 24X3 | PLUG M 24X3 | 1 | $6.15 | Available | 1 |
| 21 | 46030021100 OIL DRAIN PLUG M10 WS=13 | OIL DRAIN PLUG M10 WS=13 | 1 | $15.83 | Available | 1 |
| 22 | 45130022000 ANGLE PIECE 50CCM LC 2001 | ANGLE PIECE 50CCM LC 2001 | 1 | $6.92 | Available | 1 |
| 23 | 47030023100 DOWEL 13X13 | DOWEL 13X13 | 1 | — | Obsolete | View Details |
| 24 | 45130023000 DOWEL 7X9X10 | DOWEL 7X9X10 | 1 | — | Obsolete | View Details |
| 25 | 47030025000 INNER CLUTCH COVER GASKET | INNER CLUTCH COVER GASKET | 1 | $20.56 | Available | 1 |
| 26 | 47030101100 OUTER CLUTCH OVER 85 SX 06 | OUTER CLUTCH OVER 85 SX 06 | 1 | $99.76 | Available | 1 |
| 27 | 47030027100 GASKET FOR OUTER CLUTCH COVER | GASKET FOR OUTER CLUTCH COVER | 1 | $14.07 | Available | 1 |
| 39 | 47030039000 GASKET F. ENGINE CASE 85 SX 03 | GASKET F. ENGINE CASE 85 SX 03 | 1 | $20.67 | Available | 1 |
| 52 | 47035052000 WATER PUMP COVER 85 SX 2003 | WATER PUMP COVER 85 SX 2003 | 1 | $48.28 | Available | 1 |
| 53 | 47035053000 GASKET FOR WATER PUMP COVER 03 | GASKET FOR WATER PUMP COVER 03 | 1 | $12.75 | Available | 1 |
| 56 | 47003071000 SPRINGHOLDER | SPRINGHOLDER | 1 | — | Obsolete | View Details |
| 57 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | $2.99 | Available | 1 |
| 70 | 47030023000 DOWEL 14,5X19 | DOWEL 14,5X19 | 1 | $8.24 | Available | 1 |
| 71 | 0015060103 HH COLLAR SCREW M 6X10 WS=8 | HH COLLAR SCREW M 6X10 WS=8 | 1 | $3.99 | Available | 1 |
| 73 | 0015060203 HH COLLAR SCREW M 6X20 WS=8 | HH COLLAR SCREW M 6X20 WS=8 | 6 | $3.99 | Available | 6 |
| 74 | 0015060253 HH COLLAR SCREW M 6X25 WS=8 | HH COLLAR SCREW M 6X25 WS=8 | 5 | $3.99 | Available | 5 |
| 75 | 0015060303 HH COLLAR SCREW M 6X30 SW=8 | HH COLLAR SCREW M 6X30 SW=8 | 1 | $3.99 | Available | 1 |
| 76 | 0015060353 HH COLLAR SCREW M 6X35 WS=8 | HH COLLAR SCREW M 6X35 WS=8 | — | $3.99 | Available | 1 |
| 77 | 0015060403 HH COLLAR SCREW M 6X40 WS=8 | HH COLLAR SCREW M 6X40 WS=8 | 1 | $3.99 | Available | 1 |
| 78 | 0015060453 HH COLLAR SCREW M 6X45 WS=8 | HH COLLAR SCREW M 6X45 WS=8 | 1 | $2.99 | Available | 1 |
| 82 | 0015060653 HH COLLAR SCREW M 6X65 WS=8 | HH COLLAR SCREW M 6X65 WS=8 | 1 | $2.99 | Available | 1 |
| 99 | 47030099100 GASKET SET CPL. 85/105SX 04 | GASKET SET CPL. 85/105SX 04 | 1 | $225.49 | Available | 1 |
