FRONT FORK DISASSEMBLED

← →

Parts (77)

#	Part Number	Description	Qty	Price	Status
1	43570216S SCREW CAP M46X1,5 CPL.	SCREW CAP M46X1,5 CPL.	2	—	Obsolete	View Details
2	46811042 O-ring 40x2 NBR70 black	O-ring 40x2 NBR70 black	2	$2.41	Available	2
3	48600018 Adjuster rebound	Adjuster rebound	2	$4.83	Available	2
5	40540603 Steel ball d3	Steel ball d3	2	$1.20	Available	2
6	48600028 Spring (1,7) l7,9	Spring (1,7) l7,9	1	$3.62	Available	1
7	48600044 O-ring 6x1,5 NBR70	O-ring 6x1,5 NBR70	2	$1.20	Available	2
8	48600076 VENT SCREW M4X8	VENT SCREW M4X8	2	$2.41	Available	2
9	48600046 O-ring 3x1,5 NBR70	O-ring 3x1,5 NBR70	2	$1.99	Available	2
10	48600043 O-ring 12x1,5 NBR70	O-ring 12x1,5 NBR70	2	$2.41	Available	2
11	48600019 Tube tap d4x25	Tube tap d4x25	2	$3.62	Available	2
12	43570254E OUTER TUBE L=510 D=49/53 BLACK	OUTER TUBE L=510 D=49/53 BLACK	2	—	Obsolete	View Details
13	43570099 Round-wire snap ring 53x2	Round-wire snap ring 53x2	2	$31.12	Available	2
15	43570204 pilot bushing 43x47x12	pilot bushing 43x47x12	2	$13.74	Available	2
16	43570092 Supportwasher 45x52,5x1,5	Supportwasher 45x52,5x1,5	2	$23.64	Available	2
17	43570201 Seal ring 43x52,9x9,5	Seal ring 43x52,9x9,5	2	$19.57	Available	2
18	43570008 Snap ring SB53x1,5 acc drawing	Snap ring SB53x1,5 acc drawing	2	$3.62	Available	2
19	43570202 Dirtscarper NOK 43mm	Dirtscarper NOK 43mm	2	$19.68	Available	2
22	43570203 Guide bushing 42x44x20	Guide bushing 42x44x20	2	$13.41	Backorder — Restocking	2
23	43570217 INNER TUBE D=43MM L=520MM	INNER TUBE D=43MM L=520MM	2	—	Obsolete	View Details
24	43570212S HYDR. STOP L=135MM D=31,9 CPL.	HYDR. STOP L=135MM D=31,9 CPL.	2	—	Obsolete	View Details
30	48600310 ADJUSTMENT TUBE L=437MM	ADJUSTMENT TUBE L=437MM	2	—	Obsolete	View Details
31	48600416 PISTON ROD D=14 L=471 M11X1	PISTON ROD D=14 L=471 M11X1	2	—	Obsolete	View Details
33	48600189 Needle 6x42,6 rebound	Needle 6x42,6 rebound	2	$40.80	Available	2
35	48600033 Spring (7,2) 4-23 needle	Spring (7,2) 4-23 needle	2	$6.15	Available	2
37	43570133 Preload bush 26,5x38x2,5	Preload bush 26,5x38x2,5	2	$3.62	Available	2
37	43570134 Preload bush 26x35x4	Preload bush 26x35x4	2	$3.62	Available	2
37	43570135 Preload bush 26x38x10	Preload bush 26x38x10	2	$4.83	Available	2
37	43570136 Preload bush 26,5x38x1,5	Preload bush 26,5x38x1,5	2	$3.62	Available	2
38	95010029S SPRING 2,8 N/MM SET D=4,2MM	SPRING 2,8 N/MM SET D=4,2MM	—	$153.99	Available	1
38	95010030S SPRING 3,0 N/MM SET D=4,2MM	SPRING 3,0 N/MM SET D=4,2MM	1	$153.99	Available	1
38	95010031S SPRING 3,2 N/MM SET D=4,2MM	SPRING 3,2 N/MM SET D=4,2MM	—	$153.99	Available	1
39	43570131 Spring retainer 33,5x38,2x3	Spring retainer 33,5x38,2x3	2	$21.22	Available	2
42	48600200S1 SCREW SLEEVE M29,3X1 L=65 CPL.	SCREW SLEEVE M29,3X1 L=65 CPL.	2	—	Obsolete	View Details
43	48600239 O-ring 8x1,25 NBR70 siliconize	O-ring 8x1,25 NBR70 siliconize	2	$1.99	Available	2
44	48600192 REBOUND SPRING D=15MM L=34,5MM	REBOUND SPRING D=15MM L=34,5MM	2	—	Obsolete	View Details
45	48600203 Tap 6x45 rebound	Tap 6x45 rebound	2	—	Obsolete	View Details
47	48600382 Spring (11,4) 0,4-8 valve	Spring (11,4) 0,4-8 valve	2	$2.41	Available	2
49	48600062 CHECK VALVE 8X24X0,1	CHECK VALVE 8X24X0,1	8	$2.41	Available	8
49	48600068 CHECK VALVE 8X18X0,1	CHECK VALVE 8X18X0,1	2	$2.41	Available	2
49	48600215 Shim 8x20x0,10	Shim 8x20x0,10	2	$2.41	Available	2
49	48600216 Shim 8x22x0,10	Shim 8x22x0,10	2	$2.41	Available	2
50	40540401 Shim 6x14x0,10	Shim 6x14x0,10	—	$2.41	Available	1
50	40540402 Shim 6x16x0,10	Shim 6x16x0,10	—	$2.41	Available	1
50	40540403 Shim 6x18x0,10	Shim 6x18x0,10	4	$2.41	Available	4
50	40540414 Shim 6x16x0,25	Shim 6x16x0,25	—	$2.41	Available	1
50	40540415 Shim 6x18x0,25	Shim 6x18x0,25	—	$2.41	Available	1
50	40540447 Shim 6x10x0,30	Shim 6x10x0,30	—	$2.41	Available	1
50	40540450 Shim 6x9,5x0,30	Shim 6x9,5x0,30	1	$2.41	Available	1
50	48600063 Shim 6x24x0,10	Shim 6x24x0,10	—	$2.41	Available	1
50	48600064 Shim 6x22x0,10	Shim 6x22x0,10	—	$2.41	Available	1
50	48600065 Shim 6x20x0,10	Shim 6x20x0,10	—	$2.41	Available	1
50	48600116 Shim 6x24x0,10 delta	Shim 6x24x0,10 delta	—	$2.41	Available	1
51	48600060 Pistonring 26x28x5	Pistonring 26x28x5	2	$6.15	Available	2
52	48600042 Piston 6,05x27,65x12 rebound	Piston 6,05x27,65x12 rebound	2	—	Obsolete	View Details
55	40540486 Nut M6x0,5 h6,5 WAF10 rebound	Nut M6x0,5 h6,5 WAF10 rebound	2	$4.83	Available	2
58	48600353 TUBE 29,3X1X370 D=8,5MM ALU	TUBE 29,3X1X370 D=8,5MM ALU	2	—	Obsolete	View Details
59	43570023 O-ring 41x2 NBR70 siliconized	O-ring 41x2 NBR70 siliconized	2	$15.94	Available	2
60	43570214S AXLE CLAMP L/S CPL. 85 SX 03	AXLE CLAMP L/S CPL. 85 SX 03	1	—	Obsolete	View Details
61	43570213S AXLE CLAMP R/S CPL. 85 SX 03	AXLE CLAMP R/S CPL. 85 SX 03	1	—	Obsolete	View Details
62	0015060203 HH COLLAR SCREW M 6X20 WS=8	HH COLLAR SCREW M 6X20 WS=8	6	$3.99	Available	6
63	48600163 Nut valve M6x0,5 h6,5 WAF17	Nut valve M6x0,5 h6,5 WAF17	2	$3.62	Available	2
64	48600202 Spring (8,5) l6,5 valve	Spring (8,5) l6,5 valve	2	$2.41	Available	2
69	48600152S1 TAP COMPRESSION CPL. 03	TAP COMPRESSION CPL. 03	2	$103.80	Out of Stock	Notify Me
70	48600061 Shim 8x24x0,40	Shim 8x24x0,40	2	$2.41	Available	2
71	48600047 Piston 6x27,8x9 compression	Piston 6x27,8x9 compression	2	$11.54	Available	2
72	46811499 O-ring 21x2 NBR70	O-ring 21x2 NBR70	4	$1.20	Available	4
73	35480320 O-ring 24x2 NBR70	O-ring 24x2 NBR70	2	$1.20	Available	2
74	48600152 TAP COMPRESSION	TAP COMPRESSION	2	$103.80	Out of Stock	Notify Me
75	48600190 Needle 10x11,6 compression	Needle 10x11,6 compression	2	$16.05	Out of Stock	Notify Me
76	48600049 O-ring 8x2 NBR70	O-ring 8x2 NBR70	2	$1.20	Available	2
79	48600051 Round-wire snap ring 12x1 DIN7	Round-wire snap ring 12x1 DIN7	2	$3.62	Available	2
80	48600034 Adjustment screw slot compress	Adjustment screw slot compress	2	—	Obsolete	View Details
81	48600004 Copper disc 29,5x33,5x1	Copper disc 29,5x33,5x1	2	$4.83	Available	2
82	48600141 Rubber cap 35x10 NBR80	Rubber cap 35x10 NBR80	2	$4.83	Available	2
83	48600401S1 FORK OIL SAE5 5L 2005	FORK OIL SAE5 5L 2005	1	$165.36	Out of Stock	Notify Me
98	T511 SILICONE GREASE F. DUST STRI	SILICONE GREASE F. DUST STRI	1	$40.69	Available	1
99	R510 REPAIR-KIT GASKET 4357 MXMA 03	REPAIR-KIT GASKET 4357 MXMA 03	1	$162.90	Available	1
