SHOCK ABSORBER DISASSEMBLED
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | S454600024S0000 shock housing cpl | shock housing cpl | 1 | — | Check availability | |
| 2 | 36120151ST PLUG SCREW M5X6 CPL. | PLUG SCREW M5X6 CPL. | 1 | — | Check availability | |
| 3 | S208600003000FB O-ring 5,28x1,78 HNBR70 red | O-ring 5,28x1,78 HNBR70 red | 1 | — | Check availability | |
| 4 | 50180095 HS cylinder-head screw R1/8 l8 | HS cylinder-head screw R1/8 l8 | 1 | — | Check availability | |
| 5 | RP10051T Ball bearing kit | Ball bearing kit | 0 | — | Check availability | |
| 6 | 46181193 Pivotseal d.12X25,1 PDS | Pivotseal d.12X25,1 PDS | 4 | — | Check availability | |
| 7 | 52000233 Sticker XPLOR PDS 90x40 | Sticker XPLOR PDS 90x40 | 1 | — | Check availability | |
| 8 | S012900010S0400 Compression cpl. | Compression cpl. | 1 | — | Check availability | |
| 9 | RP10044T Repair kit adjuster DCC 2023 | Repair kit adjuster DCC 2023 | 0 | — | Check availability | |
| 10 | 50180217 O-ring 27x1,5 Viton70 green IS | O-ring 27x1,5 Viton70 green IS | 1 | — | Check availability | |
| 11 | 50180218 O-ring 25x1,5 Viton70 | O-ring 25x1,5 Viton70 | 1 | — | Check availability | |
| 12 | S938100027S0000 Adjustment nut pds-shock plast | Adjustment nut pds-shock plast | 1 | — | Check availability | |
| 13 | S80980001600020 Mainspring (59) 70-190.0 shock | Mainspring (59) 70-190.0 shock | 0 | — | Check availability | |
| 13 | S80980001700020 Mainspring (59) 75-190.0 shock | Mainspring (59) 75-190.0 shock | 0 | — | Check availability | |
| 13 | S80980001800020 Mainspring (59) 80-190.0 shock | Mainspring (59) 80-190.0 shock | 1 | — | Check availability | |
| 13 | S80980001900020 Mainspring (59) 85-190.0 shock | Mainspring (59) 85-190.0 shock | 0 | — | Check availability | |
| 13 | S80980002000020 Mainspring | Mainspring | 0 | — | Check availability | |
| 14 | RP10052T Spring plate repair kit | Spring plate repair kit | 0 | — | Check availability | |
| 15 | 46181656 nut M10x1 h10,5 SW19 | nut M10x1 h10,5 SW19 | 1 | — | Check availability | |
| 16 | 46181416 Piston 15,4x35,4x6 | Piston 15,4x35,4x6 | 1 | — | Check availability | |
| 17 | S71100000500000 Compression holder 10x48 | Compression holder 10x48 | 1 | — | Check availability | |
| 18 | 46811258 Washer 12x24x2,5 | Washer 12x24x2,5 | 1 | — | Check availability | |
| 19 | S624600000S0000 Piston d46 cmpl. | Piston d46 cmpl. | 1 | — | Check availability | |
| 20 | S25120000300000 Rebound disc 12x36x18,9 h14,9 | Rebound disc 12x36x18,9 h14,9 | 1 | — | Check availability | |
| 21 | S614620000S0100 Seal support 46x28 cmpl. | Seal support 46x28 cmpl. | 1 | — | Check availability | |
| 22 | S23902000000000 round-wire snap ring 49x1,75 | round-wire snap ring 49x1,75 | 1 | — | Check availability | |
| 23 | 46181505 Cover 46,15x6,7 h14,7 | Cover 46,15x6,7 h14,7 | 1 | — | Check availability | |
| 24 | S921800000000C1 Rubber pad 18x56x46 black | Rubber pad 18x56x46 black | 1 | — | Check availability | |
| 25 | S421800021S0000 bottom part cpl. with pisten r | bottom part cpl. with pisten r | 1 | — | Check availability | |
| 98 | 50180751S1 SHOCK ABSORBER FLUID 5 LT | SHOCK ABSORBER FLUID 5 LT | 0 | — | Check availability | |
| 99 | RP10053T Repair kit shock absorber | Repair kit shock absorber | 0 | — | Check availability |
