FRAME
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A13003001100C1 Frame | Frame | 1 | — | Check availability | |
| 2 | A13003002033 rear frame cpl | rear frame cpl | 1 | — | Check availability | |
| 3 | 09000008016U0 Special screw M8x16 ISA45 self | Special screw M8x16 ISA45 self | 4 | — | Check availability | |
| 4 | A13003092001 Frame protection sticker | Frame protection sticker | 1 | — | Check availability | |
| 5 | A13003093001 Frame protection sticker | Frame protection sticker | 1 | — | Check availability | |
| 6 | A49003099030 Cable protection | Cable protection | 2 | — | Check availability | |
| 7 | A13003083000C1 Frame cover | Frame cover | 1 | — | Check availability | |
| 8 | 0000240817401 Hexagon collar screw M8x174 IS | Hexagon collar screw M8x174 IS | 2 | — | Check availability | |
| 9 | 0035100249 AH collar screw M10x24 ISA45 | AH collar screw M10x24 ISA45 | 2 | — | Check availability | |
| 10 | 0000240813101 Hexagon collar screw M8x131 IS | Hexagon collar screw M8x131 IS | 1 | — | Check availability | |
| 11 | 0035100209S Hex.screw M10x20 ISA45 MK | Hex.screw M10x20 ISA45 MK | 4 | — | Check availability | |
| 12 | 0910000801209 Threaded bushing M8 x d21 | Threaded bushing M8 x d21 | 2 | — | Check availability | |
| 13 | A13003037033 Footpeg set | Footpeg set | 1 | — | Check availability | |
| 14 | 0094032253 PIN DIN0094-3,2X25 STEEL | PIN DIN0094-3,2X25 STEEL | 2 | — | Check availability | View Details |
| 15 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 2 | — | Check availability | |
| 16 | 54803044000 PIN FOR FOOT PED 51.5X9.8 MM | PIN FOR FOOT PED 51.5X9.8 MM | 2 | — | Check availability | |
| 17 | A46003045000 Footrest spring right | Footrest spring right | 1 | — | Check availability | |
| 18 | A46003044000 Footrest spring left | Footrest spring left | 1 | — | Check availability | |
| 19 | A13003041000 Footpeg right | Footpeg right | 1 | — | Check availability | |
| 20 | A13003040000 Footpeg left | Footpeg left | 1 | — | Check availability | |
| 21 | A13003014000 Engine brace right | Engine brace right | 1 | — | Check availability | |
| 22 | A13003013000 Engine brace left | Engine brace left | 1 | — | Check availability | |
| 23 | A13003096000 Front sprocket cover | Front sprocket cover | 1 | — | Check availability | |
| 24 | 83008000012 special screw M6x12x3 | special screw M6x12x3 | 3 | — | Check availability | |
| 25 | 0025060356 HH collar screw M6x35 TX30 | HH collar screw M6x35 TX30 | 1 | — | Check availability | |
| 26 | 0025080306 HH collar screw M8x30 | HH collar screw M8x30 | 1 | — | Check availability | |
| 27 | A13003053000 chain guide below | chain guide below | 1 | — | Check availability | |
| 28 | A13003083070 Clip 16x11x2 | Clip 16x11x2 | 2 | — | Check availability | |
| 29 | A23003094000 Frame protection set | Frame protection set | 1 | — | Check availability |
