CLUTCH COVER
Parts (18)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 76430001044 CLUTCH COVER CPL. | CLUTCH COVER CPL. | 1 | — | Check availability | |
| 2 | 7813002600015 CLUTCH COVER OUTSIDE | CLUTCH COVER OUTSIDE | 1 | — | Check availability | |
| 3 | 78130027000 GASKET - CLUTCH OUTER COVER | GASKET - CLUTCH OUTER COVER | 1 | — | Check availability | |
| 4 | 78130125000 CLUTCH COVER GASKET | CLUTCH COVER GASKET | 1 | — | Check availability | |
| 5 | 78030095100 OIL LEVEL GLASS VITON | OIL LEVEL GLASS VITON | 1 | — | Check availability | |
| 6 | 61030019050 CIRCLIP OIL LEVEL GLASS 03 | CIRCLIP OIL LEVEL GLASS 03 | 1 | — | Check availability | |
| 9 | 49030090000 DOWEL 9,8 X 7 X 10 | DOWEL 9,8 X 7 X 10 | 2 | — | Check availability | View Details |
| 11 | 0770180020 o-ring 18.00x2.00 NBR70 | o-ring 18.00x2.00 NBR70 | 1 | — | Check availability | |
| 12 | 58030020100 oil plug cpl. M24x3 | oil plug cpl. M24x3 | 1 | — | Check availability | |
| 14 | 0760142460 radial shaft seal 14x24x6 B | radial shaft seal 14x24x6 B | 1 | — | Check availability | |
| 15 | 0760123073 SHAFT SEAL RING 12X30X7 PTFE | SHAFT SEAL RING 12X30X7 PTFE | 1 | — | Check availability | |
| 16 | 0618121912 NEEDLE BUSH NK1212 | NEEDLE BUSH NK1212 | 1 | — | Check availability | |
| 50 | 78030080000 LOCATING SCREW | LOCATING SCREW | 1 | — | Check availability | |
| 51 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 11 | — | Check availability | |
| 52 | 58030081000 CU-SEAL RING 8 X 14 X 3 | CU-SEAL RING 8 X 14 X 3 | 1 | — | Check availability | |
| 53 | 0025060556 HH collar screw M6x55 TX30 | HH collar screw M6x55 TX30 | 1 | — | Check availability | |
| 54 | 0025060606 HH collar screw M6x60 TX30 | HH collar screw M6x60 TX30 | 1 | — | Check availability | |
| 13 | 0472024120 CIRCLIP DIN0472-24X1.2 | CIRCLIP DIN0472-24X1.2 | 1 | — | Check availability |
