CRANKSHAFT, PISTON
Parts (37)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 57730018100 CRANKSHAFT CPL. 400 LC4-E '97 | CRANKSHAFT CPL. 400 LC4-E '97 | 1 | — | Obsolete | View Details |
| 1 | 58430018100 CRANKSHAFT CPL. 640 LC4-E ' | CRANKSHAFT CPL. 640 LC4-E ' | 1 | — | Obsolete | View Details |
| 2 | 58030015044 CONNECTING ROD REPAIR SET LC4 | CONNECTING ROD REPAIR SET LC4 | 1 | — | Obsolete | View Details |
| 2 | 58330015044 CONNECTING ROD REPAIR SET LC | CONNECTING ROD REPAIR SET LC | 1 | — | Obsolete | View Details |
| 4 | 56530081000 SHIM WASHER 36X48X0,10 | SHIM WASHER 36X48X0,10 | — | $2.99 | Available | 1 |
| 4 | 56530081100 SHIM WASHER 36X48X0,15 | SHIM WASHER 36X48X0,15 | — | $2.99 | Available | 1 |
| 4 | 56530081300 SHIM WASHER 36X48X0,30 | SHIM WASHER 36X48X0,30 | — | $2.99 | Available | 1 |
| 5 | 0888030050 WOODRUFF KEY DIN6888-3X5X13 | WOODRUFF KEY DIN6888-3X5X13 | 1 | $2.99 | Available | 1 |
| 6 | 6946005 WOODRUFF KEY 5X6,5 HARDED | WOODRUFF KEY 5X6,5 HARDED | 1 | $2.99 | Available | 1 |
| 7 | 56030081000 THRUST WASHER 30,5X45X0,10 | THRUST WASHER 30,5X45X0,10 | — | $1.99 | Available | 1 |
| 7 | 56030081100 THRUST WASHER 30,7X47X0,15 | THRUST WASHER 30,7X47X0,15 | — | $2.99 | Available | 1 |
| 7 | 56030081200 THRUST WASHER 30,5X45X0,30 | THRUST WASHER 30,5X45X0,30 | — | $2.99 | Available | 1 |
| 8 | 58030082000 CYL.ROLLER BEARING NJ 306 C3 | CYL.ROLLER BEARING NJ 306 C3 | 1 | $135.62 | Available | 1 |
| 9 | 56530123000 CYL.ROLLER BEAR. NJ 207 ECP C3 | CYL.ROLLER BEAR. NJ 207 ECP C3 | 1 | $106.03 | Available | 1 |
| 10 | 0760304771 SHAFT SEAL RING 30X47X7 BSL | SHAFT SEAL RING 30X47X7 BSL | 1 | $23.97 | Available | 1 |
| 15 | 58330095000 STEEL WASHER 16 X 30 X 3 | STEEL WASHER 16 X 30 X 3 | 1 | — | Obsolete | View Details |
| 16 | 58430028000 HEX NUT M16x1,25 L/S | HEX NUT M16x1,25 L/S | 1 | — | Obsolete | View Details |
| 21 | 58030019000 LOCKING RING VSK 20 | LOCKING RING VSK 20 | 1 | — | Obsolete | View Details |
| 22 | 0936200155 HEXAGON NUT DIN0936-M20X1,5 | HEXAGON NUT DIN0936-M20X1,5 | 1 | — | Obsolete | View Details |
| 23 | 0760122270 SHAFT SEAL RING 12 X 22 X 7 B | SHAFT SEAL RING 12 X 22 X 7 B | 1 | $18.58 | Available | 1 |
| 30 | 57530007000 I PISTON I 89 MM CPL. FORGED | PISTON I 89 MM CPL. FORGED | — | — | Obsolete | View Details |
| 30 | 57530007000 II PISTON II 89MM CPL. FORGED | PISTON II 89MM CPL. FORGED | — | — | Obsolete | View Details |
| 31 | 57530031000 OIL SCRAPER RING 89MM | OIL SCRAPER RING 89MM | 1 | — | Obsolete | View Details |
| 32 | 57530132000 TAPERED COMPR.PISTON RING 89MM | TAPERED COMPR.PISTON RING 89MM | 1 | — | Obsolete | View Details |
| 33 | 57530032000 RECTANGULAR RING 89MM | RECTANGULAR RING 89MM | 1 | $54.11 | Available | 1 |
| 34 | 58030033000 PISTON PIN 22 X 13 X 54,2 | PISTON PIN 22 X 13 X 54,2 | — | — | Obsolete | View Details |
| 35 | 58030074000 CIRCLIP A 22 X 1,5 | CIRCLIP A 22 X 1,5 | — | — | Obsolete | View Details |
| 36 | 57730007000 I PISTON I 89MM CPL. CAST '99 | PISTON I 89MM CPL. CAST '99 | 1 | — | Obsolete | View Details |
| 36 | 57730007000 II PISTON II 89MM CPL. CAST '99 | PISTON II 89MM CPL. CAST '99 | 1 | — | Obsolete | View Details |
| 37 | 57730033000 * PISTON BOLT 22X13X54,2 ' | * PISTON BOLT 22X13X54,2 ' | 1 | — | Obsolete | View Details |
| 40 | 58330007400 I PISTON I 101MM CPL. CAST '99 | PISTON I 101MM CPL. CAST '99 | 1 | — | Obsolete | View Details |
| 40 | 58330007400 II PISTON II 101MM CPL. CAST '9 | PISTON II 101MM CPL. CAST '9 | 1 | — | Obsolete | View Details |
| 41 | 58330031300 OIL SCRAPER RING 101x2,5 | OIL SCRAPER RING 101x2,5 | 1 | — | Obsolete | View Details |
| 42 | 58330932100 TAP.COMPR.PISTON RING 101X1,25 | TAP.COMPR.PISTON RING 101X1,25 | 1 | $31.12 | Available | 1 |
| 43 | 58330832000 RECTANGULAR RING 101x1,25 | RECTANGULAR RING 101x1,25 | 1 | — | Obsolete | View Details |
| 44 | 58330833000 PISTON PIN 22 X 13 X 60 | PISTON PIN 22 X 13 X 60 | 1 | $54.44 | Available | 1 |
| 45 | 58030074100 CIRCLIP C 22 X 1,5 | CIRCLIP C 22 X 1,5 | 2 | — | Obsolete | View Details |
