TIMING DRIVE
Parts (40)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 5843602020023 CYL. HEAD CPL. LC4/SXC SAS 04 | CYL. HEAD CPL. LC4/SXC SAS 04 | 1 | — | Check availability | View Details |
| 2 | 58530090000 DOWEL BUSHING 9,8X7,2X10 | DOWEL BUSHING 9,8X7,2X10 | 1 | — | Check availability | |
| 3 | 58036065100 CU-SEAL RING 6 X 10 X 2 | CU-SEAL RING 6 X 10 X 2 | 5 | — | Check availability | |
| 4 | 58036152600 VALVE COVER FRONT '99 | VALVE COVER FRONT '99 | 1 | — | Check availability | View Details |
| 5 | 58036052000 VALVE COVER REAR | VALVE COVER REAR | 1 | — | Check availability | View Details |
| 6 | 58036053000 VALVE COVER GASKET | VALVE COVER GASKET | 2 | — | Check availability | |
| 7 | 58330036000 CYLINDER HEAD GASKET 101,3 MM | CYLINDER HEAD GASKET 101,3 MM | 1 | — | Check availability | |
| 8 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | — | Check availability | |
| 9 | 0912060353 AH SCREW DIN0912-M 6X35 | AH SCREW DIN0912-M 6X35 | 4 | — | Check availability | |
| 11 | 0912060253 AH SCREW DIN0912-M 6X25 | AH SCREW DIN0912-M 6X25 | 6 | — | Check availability | |
| 12 | 49030028000 COLLAR NUT M8 | COLLAR NUT M8 | 2 | — | Check availability | |
| 13 | 54330043000 STUD DIN0835-M 8X40 | STUD DIN0835-M 8X40 | 2 | — | Check availability | View Details |
| 14 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 2 | — | Check availability | |
| 15 | 58036099100 COLLAR SCREW M10X80 WS=13 10.9 | COLLAR SCREW M10X80 WS=13 10.9 | 4 | — | Check availability | |
| 17 | 0993012000 CIRCLIP DIN7993-RW12 | CIRCLIP DIN7993-RW12 | 1 | — | Check availability | |
| 18 | 58036026644 VALVE GUIDE INTAKE CPL. | VALVE GUIDE INTAKE CPL. | 2 | — | Check availability | View Details |
| 19 | 58036126644 VALVE GUIDE EXHAUST CPL. | VALVE GUIDE EXHAUST CPL. | 2 | — | Check availability | |
| 21 | 0603070122 CU-SEAL RING DIN7603- 7X12X2 | CU-SEAL RING DIN7603- 7X12X2 | 2 | — | Check availability | |
| 22 | 0015060083 HH COLLAR SCREW M 6X8 WS=8 | HH COLLAR SCREW M 6X8 WS=8 | 1 | — | Check availability | View Details |
| 23 | 58336020190 VACUUM CONECTION M6/3MM '97 | VACUUM CONECTION M6/3MM '97 | 1 | — | Check availability | |
| 30 | 58436039100 EXHAUST FLANGE CPL. R/S SAS 04 | EXHAUST FLANGE CPL. R/S SAS 04 | 1 | — | Check availability | |
| 31 | 58036140100 EXHAUST FLANGE L/S | EXHAUST FLANGE L/S | 1 | — | Check availability | View Details |
| 32 | 58036041000 EXHAUST FLANGE GASKET | EXHAUST FLANGE GASKET | 2 | — | Check availability | |
| 33 | 58036040100 EXHAUST FLANGE R/S 04 | EXHAUST FLANGE R/S 04 WITHOUT SAS | — | — | Check availability | View Details |
| 34 | 58336024000 PLUG SAS BORE | PLUG SAS BORE | 1 | — | Check availability | |
| 35 | 58436054000 CU-SEAL RING 12 X 16 X 2 | CU-SEAL RING 12 X 16 X 2 | 1 | — | Check availability | |
| 42 | 58536044000 INTAKE BOOT RALLYE 2001 | INTAKE BOOT RALLYE 2001 | 1 | — | Check availability | |
| 45 | 59030061100 HOSE CLAMP GEMI 56MM 03 | HOSE CLAMP GEMI 56MM 03 | 2 | — | Check availability | View Details |
| 49 | 0912060163 AH SCREW DIN0912-M 6X16 | AH SCREW DIN0912-M 6X16 | 1 | — | Check availability | |
| 51 | 0912060203 AH SCREW DIN0912-M 6X20 | AH SCREW DIN0912-M 6X20 | 1 | — | Check availability | |
| 53 | 51005074000 RETAINING PLATE | RETAINING PLATE | 2 | — | Check availability | |
| 54 | 0912070553 AH SCREW DIN0912-M 7X55 12.9 | AH SCREW DIN0912-M 7X55 12.9 | 1 | — | Check availability | |
| 55 | 0912070603 AH SCREW DIN0912-M 7X60 12.9 | AH SCREW DIN0912-M 7X60 12.9 | 1 | — | Check availability | |
| 56 | 0912060653 SHCS DIN 912 M6x65 | SHCS DIN 912 M6x65 | 1 | — | Check availability | |
| 57 | 0912060703 AH SCREW DIN0912-M 6X70 | AH SCREW DIN0912-M 6X70 | 1 | — | Check availability | |
| 60 | 0137060003 spring washer DIN 137 B - 6 | spring washer DIN 137 B - 6 | 5 | — | Check availability | |
| 65 | 0910100003 PLUG DIN0910-M 10X1 | PLUG DIN0910-M 10X1 | 1 | — | Check availability | |
| 66 | 0603100141 sealing ring DIN 7603 10x14x1 | sealing ring DIN 7603 10x14x1 | 2 | — | Check availability | |
| 67 | 0908120153 threaded plug DIN 908 M12x1.5 | threaded plug DIN 908 M12x1.5 | 1 | — | Check availability | |
| 68 | 0770100020 o-ring 10.00x2.00 silicone | o-ring 10.00x2.00 silicone | 1 | — | Check availability |
