WIRING HARNESS
Parts (45)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 58311375450 WIRING HARNESS SXC 03 | WIRING HARNESS SXC 03 | 1 | — | Check availability | |
| 2 | 59011083000 SUPPORT BRACKET BLACK 2001 | SUPPORT BRACKET BLACK 2001 | 1 | — | Check availability | View Details |
| 3 | 49111425000 BULB 12V 1,2W (W2X4,6D) | BULB 12V 1,2W (W2X4,6D) | 3 | — | Check availability | View Details |
| 4 | 58011109110 Plug-in fuse, big 10A | Plug-in fuse, big 10A | 0 | — | Check availability | |
| 5 | 58011109120 Plug-in fuse, big 20A | Plug-in fuse, big 20A | 0 | — | Check availability | |
| 6 | 59011074200 START-STOP TIP SWITCH 2001 | START-STOP TIP SWITCH 2001 EU | 1 | — | Check availability | |
| 6 | 59011074000 START-STOP TIP SWITCH CPL | START-STOP TIP SWITCH CPL USA | 1 | — | Check availability | View Details |
| 7 | 50311060100 DC HORN L.E.B. 03 | DC HORN L.E.B. 03 | 1 | — | Check availability | |
| 8 | 0014060153 HH COLLAR SCREW M 6X15 WS=8 | HH COLLAR SCREW M 6X15 WS=8 | 1 | — | Check availability | View Details |
| 9 | 54603048100 clip nut M6 | clip nut M6 | 1 | — | Check availability | |
| 10 | 49111435100 CONDENSATOR 25V, 10.000 MF | CONDENSATOR 25V, 10.000 MF | 1 | — | Check availability | |
| 11 | 54511048000 CAPACITOR BRACKET | CAPACITOR BRACKET | 1 | — | Check availability | View Details |
| 12 | 54611448000 BRACKET FOR CAPACITOR | BRACKET FOR CAPACITOR | 1 | — | Check availability | |
| 13 | 58411014000 ADAPT. CABLE TPS MUKUNI 03 | ADAPT. CABLE TPS MUKUNI 03 USA | 1 | — | Check availability | View Details |
| 14 | 58411034100 VOLT.REGULATOR-RECTIFIER 12V | VOLT.REGULATOR-RECTIFIER 12V | 1 | — | Check availability | |
| 15 | 56509064100 Self locking nut M6 - 10 | Self locking nut M6 - 10 | 2 | — | Check availability | |
| 16 | 58411055200 BATTERY BRACKET 03 | BATTERY BRACKET 03 | 1 | — | Check availability | |
| 17 | 0015060103 HH COLLAR SCREW M 6X10 WS=8 | HH COLLAR SCREW M 6X10 WS=8 | 2 | — | Check availability | View Details |
| 18 | 58414040051 METAMOLL FOR REARLIGHT 99 | METAMOLL FOR REARLIGHT 99 | 1 | — | Check availability | View Details |
| 19 | 50311070100 H.LIGHT SWITCH CEV EGS AUS.'98 | H.LIGHT SWITCH CEV EGS AUS.'98 EU - SYMBOLS YELLOW | 1 | — | Check availability | |
| 20 | 58311064000 DUMMY PLUG F. SXC USA 03 | DUMMY PLUG F. SXC USA 03 USA | 1 | — | Check availability | View Details |
| 21 | 0934040003 HEXAGON NUT DIN0934-M 4 | HEXAGON NUT DIN0934-M 4 | 2 | — | Check availability | |
| 22 | 13011070060 ADAPTER FOR FLASHER SWITCH '98 | ADAPTER FOR FLASHER SWITCH '98 | 1 | — | Check availability | |
| 23 | 0084040223 CYL.HEAD SCREW DIN0084-M 4X22A | CYL.HEAD SCREW DIN0084-M 4X22A | 2 | — | Check availability | |
| 24 | 50311029000 FLASHER SWITCH CEV '98 | FLASHER SWITCH CEV '98 | 1 | — | Check availability | |
| 25 | 0985040163 FLAT HEAD SCREW DIN7985-M 4X16 | FLAT HEAD SCREW DIN7985-M 4X16 | 2 | — | Check availability | |
| 26 | 44011076100 CABLE TIE 100/2,5MM BLACK | CABLE TIE 100/2,5MM BLACK | 0 | — | Check availability | View Details |
| 26 | 44011076200 Cable tie 200/4.6mm black | Cable tie 200/4.6mm black | 0 | — | Check availability | |
| 26 | 44011076305 CABLE TIE 300/4,8MM BLACK | CABLE TIE 300/4,8MM BLACK | 0 | — | Check availability | |
| 27 | 44611207200 FLASHER UNIT 97 | FLASHER UNIT 97 | 1 | — | Check availability | |
| 28 | 58411047000 WIRING H. NUMBER P. LIGHT 2001 | WIRING H. NUMBER P. LIGHT 2001 EU | 1 | — | Check availability | View Details |
| 29 | 49011435000 BULB 12V 5W (W2,1X9,5D) | BULB 12V 5W (W2,1X9,5D) | 1 | — | Check availability | View Details |
| 30 | 59011081000 FLASH.WIRINGHARNESS REAR 2001 | FLASH.WIRINGHARNESS REAR 2001 EU | 1 | — | Check availability | |
| 31 | 58411059100 STARTERCABLE 700 MM '97 | STARTERCABLE 700 MM '97 | 1 | — | Check availability | |
| 32 | 58411059350 BATTERY CABLE L= 200 MM 03 | BATTERY CABLE L= 200 MM 03 | 1 | — | Check availability | |
| 33 | 58411058000 STARTER RELAY WITH HOLD.RUBBER | STARTER RELAY WITH HOLD.RUBBER | 1 | — | Check availability | View Details |
| 34 | 0985060003 Self lock. nut DIN985-M6-A2 | Self lock. nut DIN985-M6-A2 | 2 | — | Check availability | |
| 35 | 58411058050 HOLD. RUBBER FOR STARTRELAY | HOLD. RUBBER FOR STARTRELAY | 1 | — | Check availability | |
| 36 | 58411053100 BATTERY 12V 8,6AH 03 | BATTERY 12V 8,6AH 03 | 1 | — | Check availability | |
| 37 | 58411053050 BATTERY COVER 96 | BATTERY COVER 96 | 1 | — | Check availability | |
| 38 | 58411097100 GROUND CABLE D=6MM L=140MM '97 | GROUND CABLE D=6MM L=140MM '97 | 1 | — | Check availability | |
| 39 | 56509064100 Self locking nut M6 - 10 | Self locking nut M6 - 10 | 1 | — | Check availability | |
| 40 | 58411098100 CONTACT WASHER M6 VSV-K6 | CONTACT WASHER M6 VSV-K6 | 1 | — | Check availability | |
| 41 | 0014060153 HH COLLAR SCREW M 6X15 WS=8 | HH COLLAR SCREW M 6X15 WS=8 | 1 | — | Check availability | View Details |
| 42 | 54603048100 clip nut M6 | clip nut M6 | 2 | — | Check availability |
