WIRING HARNESS
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 58311175000 MAIN WIRING HARNESS EXC S-COMP | MAIN WIRING HARNESS EXC S-COMP | 1 | — | Obsolete | View Details |
| 3 | 58311376000 WIRING HARNESS REAR EGS | WIRING HARNESS REAR EGS | 1 | — | Obsolete | View Details |
| 5 | 54611083100 BRACKET FOR CONNECTOR '93 | BRACKET FOR CONNECTOR '93 | 1 | — | Obsolete | View Details |
| 5 | 55011599000 PULL SWITCH LOOSE | PULL SWITCH LOOSE | 1 | $27.16 | Available | 1 |
| 6 | 54611470100 HEAD LAMP SWITCH WI.CABLE '9 | HEAD LAMP SWITCH WI.CABLE '9 | 1 | — | Obsolete | View Details |
| 7 | 57011070050 SWITCH SUPPORT MERIT | SWITCH SUPPORT MERIT | 1 | — | Obsolete | View Details |
| 9 | 0014060103 HH COLLAR SCREW M 6X10 WS=8 | HH COLLAR SCREW M 6X10 WS=8 | 2 | $3.99 | Available | 2 |
| 10 | 49007439000 CLAMP RSGU 15/12 | CLAMP RSGU 15/12 | 1 | $6.15 | Available | 1 |
| 11 | 15406032000 * RETAINING PLATE | * RETAINING PLATE | 1 | — | Obsolete | View Details |
| 12 | 58011031000 * RETAINING PLATE | * RETAINING PLATE | 1 | — | Obsolete | View Details |
| 14 | 0912050123 AH SCREW DIN0912-M 5X12 | AH SCREW DIN0912-M 5X12 | 1 | $2.99 | Available | 1 |
| 15 | 0985050003 Self locking nut DIN 985 M5 | Self locking nut DIN 985 M5 | 2 | $2.99 | Available | 2 |
| 17 | 54511046000 * FLASHER LIGHT BRACKET | * FLASHER LIGHT BRACKET | 1 | — | Obsolete | View Details |
| 18 | 44611207000 * FLASHER UNIT | * FLASHER UNIT | 1 | — | Obsolete | View Details |
| 19 | 58311276000 REAR WIRNING HARNESS '93 | REAR WIRNING HARNESS '93 | 1 | — | Obsolete | View Details |
| 20 | 44011076180 * CABLE TIE 180MM | * CABLE TIE 180MM | — | — | Obsolete | View Details |
| 25 | 58011234100 VOLTAGE REG'R ULO 12V LC4 | VOLTAGE REG'R ULO 12V LC4 | 1 | — | Obsolete | View Details |
| 30 | 42013121000 BRAKE LIGHT SWITCH | BRAKE LIGHT SWITCH | 1 | — | Obsolete | View Details |
| 31 | 51011050000 FRONT BRAKE LIGHT SWITCH | FRONT BRAKE LIGHT SWITCH | 1 | $23.42 | Available | 1 |
| 35 | 49111435100 CONDENSATOR 25V, 10.000 MF | CONDENSATOR 25V, 10.000 MF | 1 | $67.75 | Available | 1 |
| 36 | 54511048000 CAPACITOR BRACKET | CAPACITOR BRACKET | 2 | — | Obsolete | View Details |
| 37 | 54611448000 BRACKET FOR CAPACITOR | BRACKET FOR CAPACITOR | 1 | — | Obsolete | View Details |
| 38 | 0981550193 SHEET MET.SCR.DIN7981- 5,5x19 | SHEET MET.SCR.DIN7981- 5,5x19 | 1 | — | Obsolete | View Details |
| 60 | 54511060100 DC HORN 12V NIKKO | DC HORN 12V NIKKO | 1 | — | Obsolete | View Details |
| 61 | 58307021000 BRACKET FOR HORN '93 | BRACKET FOR HORN '93 | 1 | — | Obsolete | View Details |
| 62 | 54603048100 clip nut M6 | clip nut M6 | 1 | $4.99 | Available | 1 |
