WIRING HARNESS
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 58311475000 MAIN WIRING HARNESS EGS LC4'93 | MAIN WIRING HARNESS EGS LC4'93 | 1 | — | Check availability | |
| 2 | 58311476000 * WIRING HARNESS REAR '93 | * WIRING HARNESS REAR '93 | 1 | — | Check availability | |
| 3 | 58311376000 WIRING HARNESS REAR EGS | WIRING HARNESS REAR EGS | 1 | — | Check availability | |
| 4 | 58311077000 * WIRING HARNESS-IGNITION LOCK | * WIRING HARNESS-IGNITION LOCK | 1 | — | Check availability | |
| 5 | 58311470000 LIGHT SWITCH CPL. EGS LC4'93 | LIGHT SWITCH CPL. EGS LC4'93 | 1 | — | Check availability | |
| 5 | 58311470100 % LIGHT SWITCH | % LIGHT SWITCH | 1 | — | Check availability | |
| 6 | 58311071000 SHORT CIRCUIT SWITCH DOMINO' | SHORT CIRCUIT SWITCH DOMINO' | 1 | — | Check availability | |
| 7 | 44611207000 * FLASHER UNIT | * FLASHER UNIT | 1 | — | Check availability | |
| 8 | 54511046000 * FLASHER LIGHT BRACKET | * FLASHER LIGHT BRACKET | 1 | — | Check availability | |
| 10 | 58311030000 * DIODE WITH CONNECTOR '93 | * DIODE WITH CONNECTOR '93 | 1 | — | Check availability | |
| 11 | 49007439000 CLAMP RSGU 15/12 | CLAMP RSGU 15/12 | 1 | — | Check availability | |
| 12 | 0912050123 AH SCREW DIN0912-M 5X12 | AH SCREW DIN0912-M 5X12 | 1 | — | Check availability | |
| 13 | 0985050003 Self locking nut DIN 985 M5 | Self locking nut DIN 985 M5 | 2 | — | Check availability | |
| 14 | 58311090000 * DIODE CONNECTOR '93 | * DIODE CONNECTOR '93 | 1 | — | Check availability | |
| 15 | 54511008000 BATTERY 12V 1,2AH | BATTERY 12V 1,2AH | — | — | Check availability | |
| 16 | 54611186000 RUBBER BAND | RUBBER BAND | — | — | Check availability | |
| 17 | 58011109010 FUSE 10 A | FUSE 10 A | 3 | — | Check availability | View Details |
| 19 | 58311276000 REAR WIRNING HARNESS '93 | REAR WIRNING HARNESS '93 | 1 | — | Check availability | View Details |
| 30 | 42013121000 BRAKE LIGHT SWITCH | BRAKE LIGHT SWITCH | 1 | — | Check availability | View Details |
| 31 | 51011050000 FRONT BRAKE LIGHT SWITCH | FRONT BRAKE LIGHT SWITCH | 1 | — | Check availability | View Details |
| 34 | 58011234100 VOLTAGE REG'R ULO 12V LC4 | VOLTAGE REG'R ULO 12V LC4 | 1 | — | Check availability | View Details |
| 35 | 49111435100 CONDENSATOR 25V, 10.000 MF | CONDENSATOR 25V, 10.000 MF | 1 | — | Check availability | |
| 36 | 54511048000 CAPACITOR BRACKET | CAPACITOR BRACKET | 2 | — | Check availability | View Details |
| 37 | 54611448000 BRACKET FOR CAPACITOR | BRACKET FOR CAPACITOR | 1 | — | Check availability | |
| 38 | 0981550193 SHEET MET.SCR.DIN7981- 5,5x19 | SHEET MET.SCR.DIN7981- 5,5x19 | 1 | — | Check availability | View Details |
| 60 | 54511060100 DC HORN 12V NIKKO | DC HORN 12V NIKKO | 1 | — | Check availability | |
| 61 | 58307021000 BRACKET FOR HORN '93 | BRACKET FOR HORN '93 | 1 | — | Check availability | View Details |
| 62 | 54603048100 clip nut M6 | clip nut M6 | 1 | — | Check availability | |
| 64 | 0014060103 HH COLLAR SCREW M 6X10 WS=8 | HH COLLAR SCREW M 6X10 WS=8 | 2 | — | Check availability | View Details |
| 76 | 44011076305 CABLE TIE 300/4,8MM BLACK | CABLE TIE 300/4,8MM BLACK | 3 | — | Check availability | |
| 83 | 58311083000 CONNECTOR SUPPORT '93 | CONNECTOR SUPPORT '93 | 1 | — | Check availability | |
| 84 | 58311083051 COVER CONNECTOR SUPPORT '93 | COVER CONNECTOR SUPPORT '93 | 1 | — | Check availability | |
| 85 | 0912060103 AH SCREW DIN0912-M 6X10 | AH SCREW DIN0912-M 6X10 | 1 | — | Check availability |
