FRAME
Parts (28)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 56503001900 FRAME 440/500/550 '94 | FRAME 440/500/550 '94 | 1 | — | Obsolete | View Details |
| 2 | 56503002900 SUB FRAME STEEL 440/500/550'94 | SUB FRAME STEEL 440/500/550'94 | 1 | — | Obsolete | View Details |
| 3 | 58303002090 PLUG 12 X 17 MM | PLUG 12 X 17 MM | 2 | — | Obsolete | View Details |
| 13 | 54610052000 SPROCKET SCREW-AH M8X20 WS=6 | SPROCKET SCREW-AH M8X20 WS=6 | 2 | $2.99 | Available | 2 |
| 14 | 54510052000 SPROCKET SCREW-AH M 8X26 | SPROCKET SCREW-AH M 8X26 | 6 | — | Obsolete | View Details |
| 16 | 0931081103 HH SCREW DIN931 M8x110 | HH SCREW DIN931 M8x110 | 2 | — | Obsolete | View Details |
| 17 | 0912080503 AH SCREW DIN912 M8X50 | AH SCREW DIN912 M8X50 | 2 | $3.99 | Available | 2 |
| 18 | 0912080553 AH SCREW DIN912 M8X55 | AH SCREW DIN912 M8X55 | 2 | $2.99 | Available | 2 |
| 20 | 0125080003 washer DIN 125 A -8.4 | washer DIN 125 A -8.4 | 1 | $1.99 | Available | 1 |
| 22 | 54635022000 SLEEVE FOR STEERING HEAD | SLEEVE FOR STEERING HEAD | 2 | — | Obsolete | View Details |
| 40 | 54603040000 FOOT REST L/S '90 | FOOT REST L/S '90 | 1 | — | Obsolete | View Details |
| 41 | 54603044000 BOLT FOR FOOTREST 9,8 X 50 | BOLT FOR FOOTREST 9,8 X 50 | 2 | $14.62 | Available | 2 |
| 42 | 54603041000 FOOTREST SPRING L/S & R/S | FOOTREST SPRING L/S & R/S | 2 | $6.15 | Available | 2 |
| 43 | 0125100003 washer DIN 125 A 10.5 | washer DIN 125 A 10.5 | 2 | $2.99 | Available | 2 |
| 44 | 0094032253 PIN DIN0094-3,2X25 STEEL | PIN DIN0094-3,2X25 STEEL | 2 | $1.99 | Available | 2 |
| 46 | 50203028000 WINDOW PANE 8,4X14X1MM | WINDOW PANE 8,4X14X1MM | 1 | — | Obsolete | View Details |
| 49 | 36003014000 LOCK WASHER 8MM | LOCK WASHER 8MM | 2 | $2.99 | Available | 2 |
| 50 | 50203053000 CHAIN ROLL D=30MM | CHAIN ROLL D=30MM | 1 | $7.91 | Available | 1 |
| 55 | 56503055000 ENGINE BRACKET STEEL | ENGINE BRACKET STEEL | 2 | — | Obsolete | View Details |
| 56 | 56505073000 * EXHAUST BRACKET 495 | * EXHAUST BRACKET 495 | 1 | — | Obsolete | View Details |
| 60 | 50203053100 CHAIN ROLL D=35MM | CHAIN ROLL D=35MM | 1 | — | Obsolete | View Details |
| 61 | 0625006087 Grooved ball bearing 608 2RS C | Grooved ball bearing 608 2RS C | 2 | $25.18 | Available | 2 |
| 62 | 74003021000 BUSHING 8.2 X 12 X 6 | BUSHING 8.2 X 12 X 6 | 1 | $3.99 | Available | 1 |
| 65 | 0931080353 HH SCREW DIN931 M8x35 | HH SCREW DIN931 M8x35 | 1 | — | Obsolete | View Details |
| 70 | 54503045000 CYLINDER HEAD BRACKET | CYLINDER HEAD BRACKET | 2 | — | Obsolete | View Details |
| 71 | 0933080303 HH SCREW DIN0933-M 8X30 | HH SCREW DIN0933-M 8X30 | 2 | $2.99 | Available | 2 |
| 72 | 0137080000 * SPRING WASHER DIN137 B8 | * SPRING WASHER DIN137 B8 | — | — | Obsolete | View Details |
| 86 | 54310086000 | 2 | — | Obsolete | View Details |
