TIMING DRIVE
Parts (21)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A47036509000 Intake camshaft | Intake camshaft | 1 | $218.01 | Available | 1 |
| 2 | A47036510044 Exhaust camshaft with decal | Exhaust camshaft with decal | 1 | $314.81 | Available | 1 |
| 3 | A47036004000 Slide bars | Slide bars | 1 | $18.14 | Available | 1 |
| 4 | 79236002000 TENSIONING RAIL | TENSIONING RAIL | 1 | $25.29 | Available | 1 |
| 5 | A47036001000 Slide bars | Slide bars | 1 | $10.55 | Available | 1 |
| 6 | 77236001160 BUSHING SCREW M6 | BUSHING SCREW M6 | 4 | $6.15 | Available | 4 |
| 7 | 77236002160 BUSHING SCREW M8 | BUSHING SCREW M8 | 1 | $3.99 | Available | 1 |
| 8 | 0770180020 o-ring 18.00x2.00 NBR70 | o-ring 18.00x2.00 NBR70 | 1 | $2.99 | Available | 1 |
| 9 | 77036003200 Chain tension adjuster, hydrau | Chain tension adjuster, hydrau | 1 | $62.25 | Available | 1 |
| 10 | 0603242920 CU SEAL-RING DIN7603 A24X29X2 | CU SEAL-RING DIN7603 A24X29X2 | 1 | $3.99 | Available | 1 |
| 11 | 77336008000 HOLDING BOLT M24X1,5 | HOLDING BOLT M24X1,5 | 1 | $24.19 | Available | 1 |
| 12 | 0770010010 o-ring 10.00x1.00 NBR70 | o-ring 10.00x1.00 NBR70 | 1 | $2.99 | Available | 1 |
| 13 | 77236080100 threaded plug | threaded plug | 1 | $7.80 | Available | 1 |
| 14 | A47036081000 Angle piece, engine breather | Angle piece, engine breather | 1 | $6.15 | Available | 1 |
| 15 | 77236005000 SECURING PROTECTION | SECURING PROTECTION | 1 | $3.99 | Available | 1 |
| 16 | A47036013000 Timing chain | Timing chain | 1 | $75.01 | Available | 1 |
| 17 | 79236016000 DECO LEVER | DECO LEVER | 1 | $38.16 | Available | 1 |
| 18 | 0402061780 NEEDLE ROLLER | NEEDLE ROLLER | 1 | $2.99 | Available | 1 |
| 19 | 77336016055 DECO SPRING PIN L=10,6 07 | DECO SPRING PIN L=10,6 07 | 1 | $20.67 | Available | 1 |
| 20 | 77336017030 SPRING FOR AUTO DECOMPR. | SPRING FOR AUTO DECOMPR. | 1 | $3.99 | Available | 1 |
| 21 | 77336017050 DECO SCREW PLUG | DECO SCREW PLUG | 1 | $18.03 | Available | 1 |
