CYLINDER HEAD
Parts (34)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 77136020144 CYLINDER HEAD CPL. | CYLINDER HEAD CPL. | 1 | $825.43 | Available | 1 |
| 2 | 77030036000 CYLINDER HEAD GASKET 05 | CYLINDER HEAD GASKET 05 | 1 | $50.15 | Available | 1 |
| 3 | 77036052100 VALVE COVER 06 | VALVE COVER 06 | 1 | — | Obsolete | View Details |
| 4 | 77036053000 VALVE COVER GASKET 05 | VALVE COVER GASKET 05 | 1 | $12.86 | Available | 1 |
| 5 | 77036055100 VALVE COVER SCR. M6X12 WS10 07 | VALVE COVER SCR. M6X12 WS10 07 | 3 | $3.99 | Available | 3 |
| 6 | 77036054050 RUBBER GASKET FOR SCREW 05 | RUBBER GASKET FOR SCREW 05 | 3 | $6.47 | Out of Stock | Notify Me |
| 7 | 77036052050 COVER PLATE BREATHER 05 | COVER PLATE BREATHER 05 | 1 | $21.44 | Available | 1 |
| 8 | 0009050106 EJOT SPIRAL SCREW SF M5X10-K | EJOT SPIRAL SCREW SF M5X10-K | 2 | $2.99 | Available | 2 |
| 9 | 60038082000 ANGLE CONNECTOR LC8 03 | ANGLE CONNECTOR LC8 03 | 1 | $2.99 | Available | 1 |
| 10 | 0770080020 O-RING 8X2 SILICONE | O-RING 8X2 SILICONE | 1 | $1.99 | Available | 1 |
| 11 | 77036081000 SPECIAL SCREW M7X73 WS 10 | SPECIAL SCREW M7X73 WS 10 | 2 | $25.40 | Available | 2 |
| 12 | 77036080000 SPECIAL SCREW M7X40 WS10 | SPECIAL SCREW M7X40 WS10 | 2 | $3.99 | Available | 2 |
| 13 | 61036047000 Hose clamp GEMI 63mm 05 | Hose clamp GEMI 63mm 05 | 1 | $8.90 | Available | 1 |
| 14 | 77036024000 COLLAR NUT 7X1 05 | COLLAR NUT 7X1 05 | 2 | $6.15 | Available | 2 |
| 15 | 77036023000 STUD 7X1 05 | STUD 7X1 05 | 2 | $6.81 | Available | 2 |
| 16 | 77036020150 BUSH SUPPORT A.BRIDGE CPL '05 | BUSH SUPPORT A.BRIDGE CPL '05 | 1 | — | Obsolete | View Details |
| 17 | 0402050980 needle roller DIN 5402 5x9.8 | needle roller DIN 5402 5x9.8 | 2 | $1.99 | Available | 2 |
| 18 | 60030063050 oil jet 50 M5 | oil jet 50 M5 | 1 | $11.10 | Available | 1 |
| 19 | 77036090000 DOWEL(BUSH BRIDGE)7/9/8 05 | DOWEL(BUSH BRIDGE)7/9/8 05 | 4 | $6.15 | Available | 4 |
| 20 | 77136025001 VALVE GUIDE INTAKE | VALVE GUIDE INTAKE | 2 | — | Obsolete | View Details |
| 21 | 77136026001 VALVE GUIDE OUTLET | VALVE GUIDE OUTLET | 2 | $32.77 | Available | 2 |
| 22 | 77036079000 CYLINDER HEAD SCREW 05 | CYLINDER HEAD SCREW 05 | 2 | $12.75 | Available | 2 |
| 23 | 59036090000 WASHER 10,8X18,8X1,5 | WASHER 10,8X18,8X1,5 | 4 | $1.99 | Available | 4 |
| 24 | 77036041000 GASKET EXHAUST FLANGE 06 | GASKET EXHAUST FLANGE 06 | 1 | $8.24 | Available | 1 |
| 25 | 77036039100 EXHAUST FLANGE CPL. 07 | EXHAUST FLANGE CPL. 07 | 1 | — | Obsolete | View Details |
| 26 | 0025060206 HH collar screw M6x20 TX30 | HH collar screw M6x20 TX30 | 6 | $3.99 | Available | 6 |
| 27 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 4 | $3.99 | Available | 4 |
| 28 | 77236044000 CONNECTION RUBBER EFI | CONNECTION RUBBER EFI | 1 | $42.67 | Available | 1 |
| 29 | 77236048000 Hose clip GEMI 58 | Hose clip GEMI 58 | 1 | $14.18 | Available | 1 |
| 30 | 0770100020 o-ring 10.00x2.00 silicone | o-ring 10.00x2.00 silicone | 1 | $2.99 | Available | 1 |
| 31 | 60011252000 TEMPERAT.-SENSOR WATER LC8 02 | TEMPERAT.-SENSOR WATER LC8 02 | 1 | $43.11 | Available | 1 |
| 32 | 77438087000 ENGINE BREATHER HOSE | ENGINE BREATHER HOSE | 1 | $13.63 | Available | 1 |
| 33 | 00049160121 CLAMP STD DN16 | CLAMP STD DN16 | 1 | $2.99 | Available | 1 |
| 34 | 58030010200 SCREW IN NOZZLE M20X1,5 | SCREW IN NOZZLE M20X1,5 | 1 | $10.44 | Available | 1 |
