TIMING DRIVE
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 78036010333 CAMSHAFT W. AUTODECO | CAMSHAFT W. AUTODECO | 1 | $388.51 | Available | 1 |
| 2 | 0025060206 HH collar screw M6x20 TX30 | HH collar screw M6x20 TX30 | 6 | $3.99 | Available | 6 |
| 3 | 78036012033 RETAINING PLATE CAMSHAFT CPL. | RETAINING PLATE CAMSHAFT CPL. | 1 | $13.30 | Available | 1 |
| 10 | 77336008010 HOLDING BOLT | HOLDING BOLT | 1 | $9.78 | Available | 1 |
| 11 | 0770010010 o-ring 10.00x1.00 NBR70 | o-ring 10.00x1.00 NBR70 | 1 | $2.99 | Available | 1 |
| 12 | 78036008100 CHAIN ADJUSTER HOLDING BOLT | CHAIN ADJUSTER HOLDING BOLT | 1 | $25.51 | Available | 1 |
| 13 | 0603242920 CU SEAL-RING DIN7603 A24X29X2 | CU SEAL-RING DIN7603 A24X29X2 | 1 | $3.99 | Available | 1 |
| 14 | 77036003100 chain tension adjuster | chain tension adjuster | 1 | $75.12 | Available | 1 |
| 15 | 0770180020 o-ring 18.00x2.00 NBR70 | o-ring 18.00x2.00 NBR70 | 1 | $2.99 | Available | 1 |
| 17 | 0618182414 NEEDLE SLEEVE HK1814RS18/24/14 | NEEDLE SLEEVE HK1814RS18/24/14 | 1 | $10.66 | Available | 1 |
| 18 | 0618404712 NEEDLE SLEEVE HK4012B40X47X12 | NEEDLE SLEEVE HK4012B40X47X12 | 1 | $12.97 | Available | 1 |
| 20 | 78036013000 TIMING CHAIN 110T 08 | TIMING CHAIN 110T 08 | 1 | $97.67 | Available | 1 |
| 21 | 78036002100 TIMING CHAIN TENSIONER | TIMING CHAIN TENSIONER | 1 | $8.79 | Available | 1 |
| 22 | 78036001000 GUIDE RAIL | GUIDE RAIL | 1 | $7.47 | Available | 1 |
| 23 | 77036001050 SPACER BUSHING 6.1X8.2X9.1 05 | SPACER BUSHING 6.1X8.2X9.1 05 | 5 | $4.99 | Available | 5 |
| 24 | 0984060203 AH SCREW DIN6912-M 6X20 8.8 | AH SCREW DIN6912-M 6X20 8.8 | 4 | $2.99 | Available | 4 |
| 25 | 78036005100 FAILURE PROTECTION | FAILURE PROTECTION | 1 | $7.91 | Available | 1 |
