TRANSMISSION II - COUNTERSHAFT
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 7 | 77733110100 Counter Shaft | Counter Shaft | 1 | $146.51 | Available | 1 |
| 8 | 75030085000 RETAINING PLATE F. CS BEARING | RETAINING PLATE F. CS BEARING | 4 | $1.99 | Available | 4 |
| 9 | 0019050121S INT. TORX FLAT HEAD M5X12 T25 | INT. TORX FLAT HEAD M5X12 T25 | 2 | $2.99 | Available | 2 |
| 11 | 72033016100 Sliding gear 6th gear t=30 | Sliding gear 6th gear t=30 | 1 | $164.99 | Backorder — Restocking | 1 |
| 12 | 77733112100 Idler gear 2 nd. | Idler gear 2 nd. | 1 | $157.84 | Available | 1 |
| 13 | 77733114200 Idler gear 4. gear | Idler gear 4. gear | 1 | $89.97 | Available | 1 |
| 14 | 77733115200 Sliding gear 5th gear T=23 | Sliding gear 5th gear T=23 | 1 | $120.66 | Available | 1 |
| 15 | 77733113200 Idler gear 3.G, Z=24 | Idler gear 3.G, Z=24 | 1 | $141.34 | Backorder — Restocking | 1 |
| 16 | 0417024000 CIRCLIP WS24 | CIRCLIP WS24 | 3 | $2.99 | Available | 3 |
| 17 | 77733011100 Idler Gear 1th Z=32 | Idler Gear 1th Z=32 | 1 | $166.09 | Available | 1 |
| 18 | 0471170015 CIRCLIP DIN 0471-17X1, 5 | CIRCLIP DIN 0471-17X1, 5 | 1 | $1.99 | Available | 1 |
| 20 | 59033034044 SCREW 10.9+SPRING WASHER | SCREW 10.9+SPRING WASHER | 1 | $9.23 | Available | 1 |
| 21 | 0405202612 NEEDLE BEARING K 20X26X12 | NEEDLE BEARING K 20X26X12 | 1 | $12.86 | Available | 1 |
| 22 | 0405242812 NEDDLE BEAR. K24X28X11,9 DIV. | NEDDLE BEAR. K24X28X11,9 DIV. | 1 | $8.57 | Available | 1 |
| 23 | 0405222611 NEEDLE BEAR.K 22X26X10 DIVIDED | NEEDLE BEAR.K 22X26X10 DIVIDED | 3 | $13.74 | Available | 3 |
| 25 | 49030023000 cylindrical roller bearing NJ2 | cylindrical roller bearing NJ2 | 1 | $87.55 | Available | 1 |
| 26 | 0625062035 BALL BEARING 6203 JR2 C3 | BALL BEARING 6203 JR2 C3 | 2 | $17.04 | Available | 2 |
| 29 | 79233029013 Sprocket 13-t | Sprocket 13-t | 1 | $36.40 | Available | 1 |
| 29 | 79233129014 ENGINE SPROCKET 14Z | ENGINE SPROCKET 14Z | 1 | $41.57 | Available | 1 |
| 30 | 77733043000 STOP DISC 23,4X31X1,5 | STOP DISC 23,4X31X1,5 | 2 | $3.99 | Available | 2 |
| 31 | 77233020000 STOP DISK 17,2X30X1,3 | STOP DISK 17,2X30X1,3 | 1 | $4.99 | Available | 1 |
| 32 | 78133014000 SPACER SLEEVE COUNTER | SPACER SLEEVE COUNTER | 1 | $33.43 | Available | 1 |
| 33 | 0760324571 SHAFT SEAL RING 32X45X7 BSLNBR | SHAFT SEAL RING 32X45X7 BSLNBR | 1 | $6.15 | Available | 1 |
| 35 | 0770020220 O-RING 25,12X1,78 NBR70 | O-RING 25,12X1,78 NBR70 | 1 | $3.99 | Available | 1 |
| 41 | 54833080000 STOP DISC 20,2X30X1 | STOP DISC 20,2X30X1 | 1 | $3.99 | Available | 1 |
| 43 | 77733044000 STOP DISC 24X32X1,5 | STOP DISC 24X32X1,5 | 1 | $4.99 | Available | 1 |
| 99 | 00050000941 COUNTER SHAFT REP.KIT 4 STROKE | COUNTER SHAFT REP.KIT 4 STROKE | — | $61.04 | Available | 1 |
