TRANSMISSION I - MAIN SHAFT
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 77733001000 MAIN SHAFT CPL. | MAIN SHAFT CPL. | 1 | $201.62 | Available | 1 |
| 2 | 77733102000 SOLID GEAR 2ND G. T=16 | SOLID GEAR 2ND G. T=16 | 1 | $41.46 | Available | 1 |
| 3 | 77733103000 SLIDING GEAR 3/4 G. T=''16/23 | SLIDING GEAR 3/4 G. T=''16/23 | 1 | $194.69 | Available | 1 |
| 4 | 77733105000 IDLER GEAR 5TH G. T=23 | IDLER GEAR 5TH G. T=23 | 1 | $194.03 | Available | 1 |
| 5 | 72033006044 IDLER GEAR 6TH GEAR CPL. | IDLER GEAR 6TH GEAR CPL. | 1 | $147.50 | Available | 1 |
| 6 | 78033001110 BUSHING | BUSHING | 1 | $13.41 | Available | 1 |
| 7 | 75030085000 RETAINING PLATE F. CS BEARING | RETAINING PLATE F. CS BEARING | 4 | $1.99 | Available | 4 |
| 8 | 0019050121S INT. TORX FLAT HEAD M5X12 T25 | INT. TORX FLAT HEAD M5X12 T25 | 2 | $2.99 | Available | 2 |
| 10 | 0625062054 BALL BEARING 6205 C3 NTN | BALL BEARING 6205 C3 NTN | 1 | $24.30 | Available | 1 |
| 11 | 77733024000 IDLER GEAR BUSHING | IDLER GEAR BUSHING | 1 | $30.57 | Available | 1 |
| 16 | 50133090000 LOCK RING 22X1,2 | LOCK RING 22X1,2 | 2 | $2.99 | Available | 2 |
| 19 | 77733027000 BUSHING | BUSHING | 1 | $29.25 | Available | 1 |
| 20 | 0625160041 BALL BEARING TM 16004 C4 | BALL BEARING TM 16004 C4 | 1 | $22.87 | Available | 1 |
| 22 | 77233088000 SPACER SHIM 21X42X0.2 | SPACER SHIM 21X42X0.2 | 1 | $6.81 | Available | 1 |
| 30 | 77733021000 STOP DISC | STOP DISC | 1 | $4.99 | Available | 1 |
| 43 | 77733022000 STOP DISC | STOP DISC | 1 | $4.99 | Available | 1 |
