CLUTCH
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 50532001073 clutch basket SX | clutch basket SX | 1 | $339.67 | Available | 1 |
| 2 | 50532002000 Inner clutch hub | Inner clutch hub | 1 | $40.03 | Available | 1 |
| 3 | 50532013000 Inner ring | Inner ring | 1 | $8.13 | Available | 1 |
| 4 | 50532011000 Friction plate 1.95 mm | Friction plate 1.95 mm | 7 | $22.87 | Available | 7 |
| 5 | 78132057144 PRESSURE PIECE CPL. | PRESSURE PIECE CPL. | 1 | $36.18 | Available | 1 |
| 6 | 50532004000 Sleeve 7.95x31.65 | Sleeve 7.95x31.65 | 5 | $3.99 | Available | 5 |
| 7 | 0025050206 HH collar screw M5x20 TX30 | HH collar screw M5x20 TX30 | 1 | $2.99 | Available | 1 |
| 8 | 50532006000 Spring plate | Spring plate | 1 | $33.10 | Available | 1 |
| 9 | 50532005000 Clutch spring | Clutch spring | 1 | $12.97 | Available | 1 |
| 10 | 0936181506 Hex nut DIN0936-M18x1.5 right | Hex nut DIN0936-M18x1.5 right | 1 | $3.99 | Available | 1 |
| 11 | 0252012002900 Wedge lock washer 19.5x29x3.4 | Wedge lock washer 19.5x29x3.4 | 1 | $3.99 | Available | 1 |
| 12 | 50532017000 Supporting plate 20x36x2.5 | Supporting plate 20x36x2.5 | 1 | $11.32 | Available | 1 |
| 13 | 0405263017 Needle cage K263017 | Needle cage K263017 | 1 | $12.86 | Available | 1 |
| 14 | 50532015000 Collar 20x26x19,5 | Collar 20x26x19,5 | 1 | $24.63 | Available | 1 |
| 15 | 50532023023 gear primary drive | gear primary drive | 1 | $127.92 | Available | 1 |
| 17 | A42032054000 Push rod | Push rod | 1 | $13.52 | Available | 1 |
| 18 | 0770300015 O-ring 30x1.5 NBR 70 | O-ring 30x1.5 NBR 70 | 1 | $2.99 | Available | 1 |
| 19 | 79232061044 OUTPUT CYLINDER CPL. | OUTPUT CYLINDER CPL. | 1 | $220.76 | Available | 1 |
| 20 | 0603082121 SEAL RING CU DIN7603- 8X12X1 | SEAL RING CU DIN7603- 8X12X1 | 2 | $3.99 | Available | 2 |
| 21 | 79232063000 CLUTCH PIPE | CLUTCH PIPE | 1 | $132.21 | Available | 1 |
| 22 | 79032064000 BLEEDER SCREW CPL. | BLEEDER SCREW CPL. | 1 | $35.74 | Available | 1 |
| 23 | 0025060166 HH collar screw M6x16 TX30 | HH collar screw M6x16 TX30 | 4 | $3.99 | Available | 4 |
| 24 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 4 | $3.99 | Available | 4 |
| 25 | 50329050000 VENT INJEKTION HYDR. CLUTCH | VENT INJEKTION HYDR. CLUTCH | 1 | $63.24 | Available | 1 |
| 26 | 50532003000 Preasure plate | Preasure plate | 1 | $29.14 | Available | 1 |
| 99 | 50532010033 Clutch disc pack | Clutch disc pack | 1 | $192.93 | Available | 1 |
