CLUTCH
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 77032001000 OUTER CLUTCH CPL. 05 | OUTER CLUTCH CPL. 05 | 1 | — | Obsolete | View Details |
| 2 | 77032002000 INNER CLUTCH HUB 05 | INNER CLUTCH HUB 05 | 1 | — | Obsolete | View Details |
| 3 | 77032003000 PRESSURE PLATE 05 | PRESSURE PLATE 05 | 1 | $123.63 | Available | 1 |
| 9 | 77032010000 INTERMEDI. DISC STEEL 05 | INTERMEDI. DISC STEEL 05 | 7 | $13.85 | Available | 7 |
| 11 | 77032011000 LINING DISC 3,0MM 05 | LINING DISC 3,0MM 05 | 7 | $42.67 | Available | 7 |
| 13 | 50332013000 INNER RING 20X26X25,9 '98 | INNER RING 20X26X25,9 '98 | 1 | — | Obsolete | View Details |
| 18 | 50332018000 SHEET METAL LOCK 1,5MM '98 | SHEET METAL LOCK 1,5MM '98 | 1 | $7.36 | Available | 1 |
| 19 | 0936181505 HEXAGON NUT DIN0936-M18X1,5 R. | HEXAGON NUT DIN0936-M18X1,5 R. | 1 | $9.12 | Available | 1 |
| 20 | 50332020000 STOP DISK 20X39,6X3 '98 | STOP DISK 20X39,6X3 '98 | 1 | $19.24 | Available | 1 |
| 23 | 77032000122 PRIMARY GEAR 22T. 05 | PRIMARY GEAR 22T. 05 | 1 | $126.38 | Out of Stock | Notify Me |
| 24 | 59032065000 GASKET FOR SLAVE CYLINDER | GASKET FOR SLAVE CYLINDER | 1 | $6.59 | Available | 1 |
| 50 | 50232050000 WASHER 6,2X18X2 | WASHER 6,2X18X2 | 2 | $6.15 | Available | 2 |
| 53 | 77032054000 PUSH ROD 05 | PUSH ROD 05 | 1 | $12.75 | Available | 1 |
| 54 | 50332054051 PRESSURE PIECE 125-380 '98 | PRESSURE PIECE 125-380 '98 | 1 | $31.12 | Available | 1 |
| 66 | 0770300015 O-ring 30x1.5 NBR 70 | O-ring 30x1.5 NBR 70 | 1 | $2.99 | Available | 1 |
| 71 | 0015060203 HH COLLAR SCREW M 6X20 WS=8 | HH COLLAR SCREW M 6X20 WS=8 | 6 | $3.99 | Available | 6 |
| 72 | 0015060353 HH COLLAR SCREW M 6X35 WS=8 | HH COLLAR SCREW M 6X35 WS=8 | — | $3.99 | Available | 1 |
| 73 | 0015060253 HH COLLAR SCREW M 6X25 WS=8 | HH COLLAR SCREW M 6X25 WS=8 | 5 | $3.99 | Available | 5 |
| 75 | 50329050000 VENT INJEKTION HYDR. CLUTCH | VENT INJEKTION HYDR. CLUTCH | 1 | $63.24 | Available | 1 |
| 80 | 77032005000 CLUTCH SPRING | CLUTCH SPRING | 5 | $3.99 | Available | 5 |
| 81 | 54832066000 PISTON CPL. | PISTON CPL. | 1 | $80.51 | Available | 1 |
| 82 | 54832061044 OUTPUT CYLINDER CPL. 06 | OUTPUT CYLINDER CPL. 06 | 1 | $161.69 | Available | 1 |
| 85 | 54832067000 O-RING | O-RING | 1 | $3.99 | Available | 1 |
| 86 | 54832069000 PRESSURE SPRING | PRESSURE SPRING | 1 | $14.18 | Available | 1 |
| 87 | 42013226000 CU-SEAL RING DIN7603-10X16X1 | CU-SEAL RING DIN7603-10X16X1 | 1 | $2.99 | Available | 1 |
| 88 | 54813020000 BLEEDER HOLLOW SCREW M10X1 | BLEEDER HOLLOW SCREW M10X1 | 1 | $32.33 | Available | 1 |
| 95 | 56532095000 NEEDLE BEARING K26X30X22ZW.KSE | NEEDLE BEARING K26X30X22ZW.KSE | 1 | $28.04 | Available | 1 |
| 97 | 54637097200 AXIAL NEEDLE BEARING AXK 1226 | AXIAL NEEDLE BEARING AXK 1226 | 1 | $11.98 | Available | 1 |
| 98 | 54637098200 AXIAL WASHER AS1226 12X26X1 | AXIAL WASHER AS1226 12X26X1 | 1 | $6.15 | Available | 1 |
| 99 | 0993012000 CIRCLIP DIN7993-RW12 | CIRCLIP DIN7993-RW12 | 1 | $3.99 | Available | 1 |
