WIRING HARNESS
Parts (41)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 55611075000 Main harness | Main harness | 1 | — | Check availability | |
| 2 | 77711081100 TURN SIGNAL WIRING HARNESS | TURN SIGNAL WIRING HARNESS | 1 | — | Check availability | |
| 3 | 77711079000 WIRING HARNESS LIGHT CPL. EU | WIRING HARNESS LIGHT CPL. EU | 1 | — | Check availability | |
| 4 | 77711083000 SUPPORT BRACKET | SUPPORT BRACKET | 1 | — | Check availability | |
| 5 | 000700000BH01 DUMMY PLUG 6-PIN | DUMMY PLUG 6-PIN | 1 | — | Check availability | |
| 6 | 69011040000 END PLUG CAN-BUS 08 | END PLUG CAN-BUS 08 | 1 | — | Check availability | View Details |
| 7 | 76511030000 FLASHER UNIT | FLASHER UNIT | 1 | — | Check availability | |
| 8 | 58211031100 BRACKET FOR FLASHER RELAY | BRACKET FOR FLASHER RELAY | 1 | — | Check availability | |
| 9 | 49111425200 BULB 12V 2,3W (W2X4,6D) | BULB 12V 2,3W (W2X4,6D) | 2 | — | Check availability | |
| 10 | 60011093075 RUBBER CABLE TIE 75MM 03 | RUBBER CABLE TIE 75MM 03 | 1 | — | Check availability | |
| 11 | 77711050000 BRAKE LIGHT SWITCH FRONT 2014 | BRAKE LIGHT SWITCH FRONT 2014 | 1 | — | Check availability | |
| 12 | 50311060200 DC HORN 12V 07 | DC HORN 12V 07 | 1 | — | Check availability | |
| 13 | 79611034000 VOLTAGE REGULATOR | VOLTAGE REGULATOR | 1 | — | Check availability | |
| 14 | 24511055000 Battery box | Battery box | 1 | — | Check availability | |
| 15 | 78011061000 HORN BRACKET EXC 08 | HORN BRACKET EXC 08 | 1 | — | Check availability | |
| 16 | 0125050003 WASHER DIN0125-A 5,3 | WASHER DIN0125-A 5,3 | 1 | — | Check availability | |
| 17 | 0934050003 HEXAGON NUT DIN0934-M 5 | HEXAGON NUT DIN0934-M 5 | 1 | — | Check availability | |
| 18 | 44011076305 CABLE TIE 300/4,8MM BLACK | CABLE TIE 300/4,8MM BLACK | — | — | Check availability | |
| 19 | 0017060206 SCREW F. PLASTIC K60X20AL SW6 | SCREW F. PLASTIC K60X20AL SW6 | 1 | — | Check availability | |
| 23 | 57013072000 WIRING HOLDER 12MM | WIRING HOLDER 12MM | — | — | Check availability | |
| 23 | 57013072100 WIRING HOLDER 16MM | WIRING HOLDER 16MM | — | — | Check availability | |
| 26 | 77311953000 LITHIUM ION BATTERY 5S | LITHIUM ION BATTERY 5S | 1 | — | Check availability | View Details |
| 27 | 58411059100 STARTERCABLE 700 MM '97 | STARTERCABLE 700 MM '97 | 1 | — | Check availability | |
| 31 | 79011056100 BATTERY BOX SUPPORT | BATTERY BOX SUPPORT | 1 | — | Check availability | |
| 33 | 50303018000 RUBBER L=145MM | RUBBER L=145MM | 1 | — | Check availability | |
| 34 | 58111076000 CABLE SUPPORT KHS NR.150-47610 | CABLE SUPPORT KHS NR.150-47610 | 1 | — | Check availability | |
| 35 | 0024060156 HH collar screw M6x15 TX30 | HH collar screw M6x15 TX30 | 2 | — | Check availability | |
| 36 | 0017060205 SCREW FOR PLASTIC K60X20 SW6 | SCREW FOR PLASTIC K60X20 SW6 | 3 | — | Check availability | |
| 37 | 59003001099 METAMOLL 90X45X3MM 03 | METAMOLL 90X45X3MM 03 | 1 | — | Check availability | |
| 40 | 58011109120 Plug-in fuse, big 20A | Plug-in fuse, big 20A | 2 | — | Check availability | |
| 56 | 58711086000 WIRING HARNESS BATTERY DUKE'99 | WIRING HARNESS BATTERY DUKE'99 | 1 | — | Check availability | |
| 58 | 58211058000 Starter reley 12V 99 | Starter reley 12V 99 | 1 | — | Check availability | |
| 59 | 55111059000 STARTERCABLE 1100MM 07 | STARTERCABLE 1100MM 07 | 1 | — | Check availability | |
| 69 | 77240099000 Protection cap for starter eng | Protection cap for starter eng | 1 | — | Check availability | |
| 73 | 0985060003 Self lock. nut DIN985-M6-A2 | Self lock. nut DIN985-M6-A2 | 1 | — | Check availability | |
| 88 | 0902060083 Oval head screw ISO 7380 M 6X8 | Oval head screw ISO 7380 M 6X8 | 2 | — | Check availability | |
| 18 | 44011076200 Cable tie 200/4.6mm black | Cable tie 200/4.6mm black | — | — | Check availability | |
| 18 | 44011076140 CABLE TIE 140/2,5MM BLACK | CABLE TIE 140/2,5MM BLACK | — | — | Check availability | |
| 20 | 59001092050 SPECIAL SCREW M6X12,5 WS=8 | SPECIAL SCREW M6X12,5 WS=8 | 1 | — | Check availability | |
| 21 | 61111057000 RELAY CM1A-R-12V-H80 07 | RELAY CM1A-R-12V-H80 07 | 2 | — | Check availability | |
| 60 | 58211058050 BRACKET RUBBER F.STARTRELAY 07 | BRACKET RUBBER F.STARTRELAY 07 | 1 | — | Check availability |
