CYLINDER HEAD
Parts (33)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A46036520044 Cylinder Head cpl. | Cylinder Head cpl. | 1 | — | Out of Stock | Notify Me |
| 2 | A46030036072 Cylinder head gasket | Cylinder head gasket | 1 | $60.27 | Available | 1 |
| 3 | A46036052000C1 Valve cover | Valve cover | 1 | $29.58 | Available | 1 |
| 4 | A46036053000 Valve cover seal | Valve cover seal | 1 | $4.99 | Available | 1 |
| 5 | 77336054150 VALVE COVER SCREW | VALVE COVER SCREW | 2 | $6.15 | Available | 2 |
| 6 | 77036054150 RUBBER GASKET FOR SCREW | RUBBER GASKET FOR SCREW | 2 | $4.99 | Available | 2 |
| 7 | 77136026001 VALVE GUIDE OUTLET | VALVE GUIDE OUTLET | 4 | $32.77 | Available | 4 |
| 8 | A46036075000 Spark plug shaft insert | Spark plug shaft insert | 1 | $12.53 | Available | 1 |
| 9 | 77336053050 GASKET SPARK-PLUG SHAFT | GASKET SPARK-PLUG SHAFT | 1 | $6.92 | Available | 1 |
| 10 | 07702300151 O-ring 23x1.5 Viton | O-ring 23x1.5 Viton | 2 | $6.15 | Available | 2 |
| 11 | 0000150703800 Collar screw M7x1x38 | Collar screw M7x1x38 | 8 | $1.99 | Available | 8 |
| 12 | 0770090015 O-RING 9X1,5 NBR | O-RING 9X1,5 NBR | 2 | $2.99 | Available | 2 |
| 13 | 77236080100 threaded plug | threaded plug | 2 | $7.80 | Available | 2 |
| 14 | 77336088210 COLLAR NUT M10X1,25 SW13 | COLLAR NUT M10X1,25 SW13 | 4 | $2.99 | Available | 4 |
| 15 | 77336089010 washer 19x10.5x2.5 | washer 19x10.5x2.5 | 4 | $4.99 | Available | 4 |
| 16 | 0900000814500 Stud M10x1,25 | Stud M10x1,25 | 4 | $4.99 | Available | 4 |
| 21 | 79536044000 rubber sleeve | rubber sleeve | 1 | $33.65 | Available | 1 |
| 22 | 61036047000 Hose clamp GEMI 63mm 05 | Hose clamp GEMI 63mm 05 | 1 | $8.90 | Available | 1 |
| 23 | 58530014100 dowl sleeve 10.2x12.5x10 | dowl sleeve 10.2x12.5x10 | 2 | $4.99 | Available | 2 |
| 25 | 79435047000 water temperature sensor | water temperature sensor | 1 | $27.93 | Backorder — Restocking | 1 |
| 27 | 58030010200 SCREW IN NOZZLE M20X1,5 | SCREW IN NOZZLE M20X1,5 | 1 | $10.44 | Available | 1 |
| 28 | A46036041000 Exhaust pipe flange gasket | Exhaust pipe flange gasket | 1 | $7.14 | Backorder — Restocking | 1 |
| 29 | A46036039000 Engine flange | Engine flange | 1 | $24.19 | Available | 1 |
| 30 | 0025060166S HH collar screw M6x16 TX30 SL | HH collar screw M6x16 TX30 SL | 2 | $2.99 | Available | 2 |
| 31 | 77336088106 COLLAR NUT M6X1 SW8 | COLLAR NUT M6X1 SW8 | 1 | $14.84 | Available | 1 |
| 32 | 0125060003 WASHER DIN0125-A 6,4 | WASHER DIN0125-A 6,4 | 1 | $1.99 | Available | 1 |
| 33 | 0900000607900 Stud M6 | Stud M6 | 1 | $2.99 | Available | 1 |
| 34 | A49030087000 Engine vent hose | Engine vent hose | 1 | $17.48 | Available | 1 |
| 35 | 58431082300 CLAMP YDNAC 10173 (18MM) | CLAMP YDNAC 10173 (18MM) | 1 | $2.99 | Available | 1 |
| 36 | A46036081000 Angle piece, engine breather | Angle piece, engine breather | 1 | $7.80 | Available | 1 |
| 40 | 77236048000 Hose clip GEMI 58 | Hose clip GEMI 58 | 1 | $14.18 | Available | 1 |
| 99 | A46030097000 Cylinder gasket kit mx 250 | Cylinder gasket kit mx 250 | — | $94.15 | Available | 1 |
| 17 | 60036123000 Vacuum fitting M6 | Vacuum fitting M6 | 1 | $11.21 | Out of Stock | Notify Me |
