COOLING SYSTEM
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 63535010000 Radiator | Radiator | 1 | — | Check availability | |
| 2 | 62535009000 RADIATOR CAP 1,4 BAR | RADIATOR CAP 1,4 BAR | 1 | — | Check availability | |
| 3 | 41001052000 RUBBER SLEEVE D=12MM | RUBBER SLEEVE D=12MM | 2 | — | Check availability | |
| 4 | 54603048100 clip nut M6 | clip nut M6 | 2 | — | Check availability | |
| 5 | 0025060126 HH collar screw M6x12 TX30 | HH collar screw M6x12 TX30 | 1 | — | Check availability | |
| 6 | 60035048000 ALU-GASKET 6X10X1.5 | ALU-GASKET 6X10X1.5 | 1 | — | Check availability | |
| 7 | 63535040000 Radiator protection | Radiator protection | 1 | — | Check availability | |
| 8 | 0024060156 HH collar screw M6x15 TX30 | HH collar screw M6x15 TX30 | 6 | — | Check availability | |
| 9 | 43205062100 silentbloc 20x15-M6x10-(1) | silentbloc 20x15-M6x10-(1) | 2 | — | Check availability | |
| 10 | 0024060106 HH COLLAR SCREW M6X10 TX30 | HH COLLAR SCREW M6X10 TX30 | 2 | — | Check availability | |
| 11 | 60035001000 SPECIAL SCREW M6X21 WS=8 | SPECIAL SCREW M6X21 WS=8 | 2 | — | Check availability | |
| 12 | 63535141044 Radiator fan right, cmpl. | Radiator fan right, cmpl. | 1 | — | Check availability | |
| 13 | 63535041044 Fan left cpl. | Fan left cpl. | 1 | — | Check availability | |
| 14 | 63535026100 Pre-formed hose, radiator | Pre-formed hose, radiator | 1 | — | Check availability | |
| 15 | 63535027000 molded hose radiator | molded hose radiator | 1 | — | Check availability | View Details |
| 16 | 00050331706 Stufenlose Einohrklemme 33,1mm | Stufenlose Einohrklemme 33,1mm | 2 | — | Check availability | |
| 17 | 00050396706 VARIABLE ONE-EAR CLAMP 39,6MM | VARIABLE ONE-EAR CLAMP 39,6MM | 1 | — | Check availability | |
| 19 | 22135065001 Water reservoir | Water reservoir | 1 | — | Check availability | |
| 20 | 60335066044 Latch, compens. tank cpl. | Latch, compens. tank cpl. | 1 | — | Check availability | |
| 21 | 22135024020 Pre-formed hose, reservoir /AC | Pre-formed hose, reservoir /AC | 1 | — | Check availability | |
| 23 | 22135024010 Pre-formed hose, reservoir rad | Pre-formed hose, reservoir rad | 1 | — | Check availability | |
| 24 | 58007117000 YDNAC-CLAMP 10107 10MM | YDNAC-CLAMP 10107 10MM | 4 | — | Check availability | |
| 25 | 69008021160 special screw M5x12 | special screw M5x12 | 3 | — | Check availability | |
| 18 | 00050361706 VARIABLE ONE-EAR CLAMP 36,1MM | VARIABLE ONE-EAR CLAMP 36,1MM | 1 | — | Check availability |
