REAR BRAKE CONTROL
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 64113069100 Expansion Tank | Expansion Tank | 1 | $41.57 | Backorder — Restocking | 1 |
| 2 | 69013099050 Screw for expansion tank | Screw for expansion tank | 1 | $4.99 | Available | 1 |
| 3 | 64113026000 Brake line holder | Brake line holder | 1 | — | Obsolete | View Details |
| 4 | 64142046000 Bracket ABS line dia7.5 | Bracket ABS line dia7.5 | 1 | $2.99 | Backorder — Restocking | 1 |
| 5 | 50231005000 HOSE CLAMP YDNAC 10119 11MM | HOSE CLAMP YDNAC 10119 11MM | 2 | $2.99 | Available | 2 |
| 6 | 69013069001 HOSE FOR RESERVOIR 6X1,5 | HOSE FOR RESERVOIR 6X1,5 | 1 | $19.24 | Available | 1 |
| 8 | 6411306000030 Foot master cylinder cpl. blac | Foot master cylinder cpl. blac | 1 | $137.60 | Backorder — Restocking | 1 |
| 9 | 64113061000 Piston assembly | Piston assembly | 1 | $69.84 | Backorder — Restocking | 1 |
| 11 | 63513050033C1 Foot brake lever cpl. without | Foot brake lever cpl. without | 1 | $182.92 | Available | 1 |
| 12 | 63513051000 Footbrake lever step plate | Footbrake lever step plate | 1 | $44.54 | Available | 1 |
| 13 | 014581050162 CS screw, ISO14581-M5x16-A2-07 | CS screw, ISO14581-M5x16-A2-07 | 2 | $1.99 | Available | 2 |
| 14 | 0025060206 HH collar screw M6x20 TX30 | HH collar screw M6x20 TX30 | 1 | $3.99 | Available | 1 |
| 15 | 0934060003 Hex. nut DIN 934 M6 | Hex. nut DIN 934 M6 | 2 | $1.99 | Available | 2 |
| 16 | 0625006087 Grooved ball bearing 608 2RS C | Grooved ball bearing 608 2RS C | 2 | $25.18 | Available | 2 |
| 17 | 54603069000 SWIVEL HEAD M6 FOOT BRAKE LEV. | SWIVEL HEAD M6 FOOT BRAKE LEV. | 1 | $43.77 | Available | 1 |
| 19 | 54603068000 PRESSURE ROD ALU 250 '90 | PRESSURE ROD ALU 250 '90 | 1 | $7.47 | Available | 1 |
| 20 | 0738060205S Oval head screw ISR M6x20-A2-7 | Oval head screw ISR M6x20-A2-7 | 1 | $1.99 | Available | 1 |
| 21 | 54603062200 Return spring for brake lever | Return spring for brake lever | 1 | $7.69 | Available | 1 |
| 22 | 54310086200 Self locking nut M8 10.9 | Self locking nut M8 10.9 | 1 | $3.99 | Available | 1 |
| 23 | 014579080301S screw ISO 14579-M8x30-10.9-MK | screw ISO 14579-M8x30-10.9-MK | 1 | $2.99 | Available | 1 |
| 24 | 62113020100 banjo bolt M10x1x19.5 | banjo bolt M10x1x19.5 | 1 | $10.33 | Available | 1 |
| 25 | 0603100141 sealing ring DIN 7603 10x14x1 | sealing ring DIN 7603 10x14x1 | 2 | $2.99 | Available | 2 |
| 26 | 63742002000 Brake line, rear master cylind | Brake line, rear master cylind | 1 | $80.07 | Available | 1 |
