TANK, SEAT
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 22107947500C1A Ergo passenger seat | Ergo passenger seat | 1 | — | Check availability | |
| 2 | 22107940000C1A Ergo rider seat heated | Ergo rider seat heated | 1 | — | Check availability | |
| 3 | 22107013066C1 Fuel tank | Fuel tank | 1 | — | Check availability | |
| 4 | 014579050301 Screw ISO 14579-M5x30-8.8-P3R | Screw ISO 14579-M5x30-8.8-P3R | 3 | — | Check availability | |
| 5 | 014579050081 Screw ISO 14579 M5x08-8.8-P3R | Screw ISO 14579 M5x08-8.8-P3R | 3 | — | Check availability | |
| 6 | 76007008052 GASKET TANK PLUG | GASKET TANK PLUG | 1 | — | Check availability | |
| 8 | 22107008050 Tank insert | Tank insert | 1 | — | Check availability | |
| 9 | 21007008251 Seal, tank insert | Seal, tank insert | 1 | — | Check availability | View Details |
| 10 | 0912080403 AH collar screw DIN0912 M8x40 | AH collar screw DIN0912 M8x40 | 4 | — | Check availability | |
| 11 | 6100716000001 Bearing sleeve, external | Bearing sleeve, external | 4 | — | Check availability | |
| 12 | 61007065000 collar bushing, front tank hol | collar bushing, front tank hol | 8 | — | Check availability | |
| 13 | 22107088020 Protective plate, fuel pump | Protective plate, fuel pump | 1 | — | Check availability | |
| 14 | 60307080090 Gasket fuel lever sensor | Gasket fuel lever sensor | 1 | — | Check availability | |
| 15 | 22107080000 Fuel level sensor | Fuel level sensor | 1 | — | Check availability | |
| 16 | 0912050163 AH collar screw DIN 912 M5x16 | AH collar screw DIN 912 M5x16 | 4 | — | Check availability | |
| 17 | 63507016000 Interconnection hose | Interconnection hose | 1 | — | Check availability | |
| 18 | 58031005000 CLAMP YDNAC 10128 12MM | CLAMP YDNAC 10128 12MM | 2 | — | Check availability | |
| 19 | 0025060126S Hex collar screw M6x12 ISA30 s | Hex collar screw M6x12 ISA30 s | 4 | — | Check availability | |
| 20 | 58507003200 Fuel cock cmpl. | Fuel cock cmpl. | 2 | — | Check availability | |
| 21 | 22115126000 Pre-formed hose, tank insert/d | Pre-formed hose, tank insert/d | 1 | — | Check availability | |
| 22 | 64111059020 Cable holder, attachable | Cable holder, attachable | 3 | — | Check availability | |
| 23 | 22107013040 Fuel tank protection sticker | Fuel tank protection sticker | 6 | — | Check availability | |
| 24 | 0019050121 COUNTERSUNK SCREW ISA25 M5X12 | COUNTERSUNK SCREW ISA25 M5X12 | 1 | — | Check availability | |
| 25 | 58605083014 Oval head screw M5x14 TX25 | Oval head screw M5x14 TX25 | 2 | — | Check availability |
