FRONT FORK DISASSEMBLED
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 43578142 Fork outer tube 44x560 dt54 db | Fork outer tube 44x560 dt54 db | 2 | — | Check availability | |
| 2 | 43578206 Fork protection ring d43 | Fork protection ring d43 | 2 | — | Check availability | |
| 3 | 43578219 O-ring 40x2,5 VMQ70 red ISO 36 | O-ring 40x2,5 VMQ70 red ISO 36 | 2 | — | Check availability | View Details |
| 4 | 43578198S1 axle clamp right d43mm black c | axle clamp right d43mm black c | 1 | — | Check availability | |
| 5 | 43578197S1 axle clamp left d43mm black cp | axle clamp left d43mm black cp | 1 | — | Check availability | |
| 6 | 0025080206 HH collar screw M8x20 | HH collar screw M8x20 | 4 | — | Check availability | |
| 7 | 43578321S1 Cartridge right 901 Norden 22 | Cartridge right 901 Norden 22 | 1 | — | Check availability | |
| 8 | 43578290S1 Cartridge left 901 Norden 22 c | Cartridge left 901 Norden 22 c | 1 | — | Check availability | |
| 9 | 43578240S Screw cap M51x1.5 black right | Screw cap M51x1.5 black right | 1 | — | Check availability | |
| 10 | 43578239S Screw cap M51x1.5 black left c | Screw cap M51x1.5 black left c | 1 | — | Check availability | |
| 12 | 43578190 Mainspring (38,3) 6,5-480 fork | Mainspring (38,3) 6,5-480 fork | 1 | — | Check availability | |
| 13 | 52000210SET Sticker set APEX OC 90x40 | Sticker set APEX OC 90x40 | 1 | — | Check availability | View Details |
| 14 | R14042T GUIDE BUSHING SET | GUIDE BUSHING SET | — | — | Check availability | |
| 15 | R513 GASKET SET | GASKET SET | — | — | Check availability | View Details |
| 16 | R14032 AH bolt M10x25 set | AH bolt M10x25 set | — | — | Check availability | |
| 17 | RP80002 Shim Kit Fork | Shim Kit Fork | — | — | Check availability | |
| 18 | RP10026 Adjuster kit fork | Adjuster kit fork | — | — | Check availability | View Details |
| 97 | T14034 Fuchs grease IPR (250g) | Fuchs grease IPR (250g) | — | — | Check availability | |
| 98 | 48601166S1 Fork Fluid Viscosity 4.0 5L | Fork Fluid Viscosity 4.0 5L | — | — | Check availability | |
| 11 | 46810340 O-ring 45x2 NBR70 siliconized | O-ring 45x2 NBR70 siliconized | 2 | — | Check availability |
