TANK, SEAT
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 22107047000 Passenger seat | Passenger seat | 1 | $211.08 | Available | 1 |
| 2 | 22107040000 Rider seat | Rider seat | 1 | $308.21 | Available | 1 |
| 3 | 22107013066C1 Fuel tank | Fuel tank | 1 | $1979.55 | Available | 1 |
| 8 | 22107008050 Tank insert | Tank insert | 1 | $16.05 | Available | 1 |
| 9 | 21007008251 Seal, tank insert | Seal, tank insert | 1 | $16.49 | Available | 1 |
| 4 | 014579050301 Screw ISO 14579-M5x30-8.8-P3R | Screw ISO 14579-M5x30-8.8-P3R | 3 | $1.99 | Available | 3 |
| 5 | 014579050081 Screw ISO 14579 M5x08-8.8-P3R | Screw ISO 14579 M5x08-8.8-P3R | 3 | $1.99 | Available | 3 |
| 10 | 0912080403 AH collar screw DIN0912 M8x40 | AH collar screw DIN0912 M8x40 | 4 | $2.99 | Available | 4 |
| 11 | 61007060000 collar bushing, bearing, outsi | collar bushing, bearing, outsi | 4 | $11.65 | Available | 4 |
| 12 | 61007065000 collar bushing, front tank hol | collar bushing, front tank hol | 8 | $9.23 | Available | 8 |
| 13 | 22107088020 Protective plate, fuel pump | Protective plate, fuel pump | 1 | $27.60 | Available | 1 |
| 14 | 60307080090 Gasket fuel lever sensor | Gasket fuel lever sensor | 1 | $59.61 | Available | 1 |
| 15 | 22107080000 Fuel level sensor | Fuel level sensor | 1 | $170.38 | Available | 1 |
| 16 | 0912050163 AH collar screw DIN 912 M5x16 | AH collar screw DIN 912 M5x16 | 4 | $1.99 | Available | 4 |
| 17 | 63507016000 Interconnection hose | Interconnection hose | 1 | $24.74 | Available | 1 |
| 18 | 58031005000 CLAMP YDNAC 10128 12MM | CLAMP YDNAC 10128 12MM | 2 | $3.99 | Available | 2 |
| 20 | 58507003200 Fuel cock cmpl. | Fuel cock cmpl. | 2 | $31.23 | Available | 2 |
| 19 | 0025060126S Hex collar screw M6x12 ISA30 s | Hex collar screw M6x12 ISA30 s | 4 | $1.99 | Available | 4 |
| 21 | 22115126000 Pre-formed hose, tank insert/d | Pre-formed hose, tank insert/d | 1 | $51.47 | Available | 1 |
| 6 | 76007008052 GASKET TANK PLUG | GASKET TANK PLUG | 1 | $6.46 | Available | 1 |
| 22 | 64111059020 Cable holder, attachable | Cable holder, attachable | 3 | $3.99 | Available | 3 |
| 23 | 22107013040 Fuel tank protection sticker | Fuel tank protection sticker | 6 | $2.99 | Backorder — Restocking | 6 |
| 24 | 0019050121 COUNTERSUNK SCREW ISA25 M5X12 | COUNTERSUNK SCREW ISA25 M5X12 | 1 | $2.99 | Available | 1 |
| 25 | 58605083014 Oval head screw M5x14 TX25 | Oval head screw M5x14 TX25 | 2 | $3.99 | Available | 2 |
