CYLINDER HEAD
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 7603602004452 CYLINDER HEAD CPL. | CYLINDER HEAD CPL. | 1 | $846.88 | Available | 1 |
| 2 | 76030036000 CYLINDER HEAD GASKET | CYLINDER HEAD GASKET | 1 | $73.14 | Available | 1 |
| 3 | 0474050100 GROOVED PIN DIN1474 5X10 | GROOVED PIN DIN1474 5X10 | 2 | $2.99 | Available | 2 |
| 4 | 0835080256 STUD DIN0835-M 8X25 10.9 | STUD DIN0835-M 8X25 10.9 | 2 | $3.99 | Available | 2 |
| 5 | 60036026101 VALVE GIUDE EXHAUST | VALVE GIUDE EXHAUST | 2 | $34.20 | Available | 2 |
| 6 | 60036025101 VALVE GIUDE INTAKE | VALVE GIUDE INTAKE | 2 | $13.41 | Available | 2 |
| 7 | 60036078050 SHIM 10,2X19X1,5MM 05 | SHIM 10,2X19X1,5MM 05 | 4 | $3.99 | Available | 4 |
| 8 | 75036079000 CYLINDERHEAD SCREW M10X168WS14 | CYLINDERHEAD SCREW M10X168WS14 | 4 | $10.99 | Available | 4 |
| 9 | 75035047000 TEMPERATURE SENSOR WATER 07 | TEMPERATURE SENSOR WATER 07 | 1 | $28.70 | Available | 1 |
| 10 | 0770100020 o-ring 10.00x2.00 silicone | o-ring 10.00x2.00 silicone | 1 | $2.99 | Available | 1 |
| 12 | 59030296000 SCREW PLUG | SCREW PLUG | 3 | $7.36 | Available | 3 |
| 13 | 76036052051 SEALING PLUG | SEALING PLUG | 1 | $1.99 | Available | 1 |
| 14 | 75036053000 VALVE COVER GASKET 07 | VALVE COVER GASKET 07 | 1 | $23.42 | Available | 1 |
| 15 | 75036052000 VALVE COVER 07 | VALVE COVER 07 | 1 | $71.93 | Available | 1 |
| 16 | 75036052050 BREATHER COVER 07 | BREATHER COVER 07 | 1 | $11.87 | Available | 1 |
| 18 | 0025050106 HH collar screw M5x10 TX30 | HH collar screw M5x10 TX30 | 3 | $1.99 | Available | 3 |
| 19 | 0770150151 O-RING 15,00X1,50 VITON | O-RING 15,00X1,50 VITON | 1 | $3.99 | Available | 1 |
| 20 | 75036055000 valve mechanism cover screw | valve mechanism cover screw | 4 | $4.99 | Available | 4 |
| 21 | 75036052010 decoupling element | decoupling element | 4 | $4.99 | Available | 4 |
| 22 | 75036144000 RUBBER SLEEVE INTAKE FLANGE | RUBBER SLEEVE INTAKE FLANGE | 1 | $68.96 | Available | 1 |
| 23 | 75036047000 HOSE CLAMP GEMI 70MM | HOSE CLAMP GEMI 70MM | 2 | $11.10 | Available | 2 |
| 24 | 0603061001 CU-SEAL RING DIN7603-6X10X1 | CU-SEAL RING DIN7603-6X10X1 | 1 | $2.99 | Available | 1 |
| 25 | 0025060086 HH collar screw M6x8 TX30 | HH collar screw M6x8 TX30 | 1 | $2.99 | Available | 1 |
| 26 | 0025060256 HH collar screw M6x25 TX30 | HH collar screw M6x25 TX30 | 2 | $3.99 | Available | 2 |
| 29 | 76530088100 PREFORMED HOSE OIL STRAINER | PREFORMED HOSE OIL STRAINER | 1 | $14.62 | Available | 1 |
| 30 | 00049200121 CLAMP STD DN20 | CLAMP STD DN20 | 1 | $1.99 | Available | 1 |
| 31 | 00049210121 CLAMP 21X12 STD-DES | CLAMP 21X12 STD-DES | 1 | $3.99 | Available | 1 |
