FRONT FORK DISASSEMBLED
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 48600864S2 Axle clamp right + tube cpl. | Axle clamp right + tube cpl. | 1 | — | Check availability | |
| 2 | 48601699S1 Axel clamp left + tube cpl. | Axel clamp left + tube cpl. | 1 | — | Check availability | |
| 3 | 0025080256 HH collar screw M8x25 | HH collar screw M8x25 | 4 | — | Check availability | |
| 5 | 48600692 Rubber cap 26,4x11 | Rubber cap 26,4x11 | 2 | — | Check availability | |
| 6 | 48601484S Adjustment screw slot M20x1 cp | Adjustment screw slot M20x1 cp | 1 | — | Check availability | |
| 7 | 48601533S HH collar screw M20x1x18 cpl. | HH collar screw M20x1x18 cpl. | 1 | — | Check availability | |
| 8 | 48601697S3 Piston rod 12x355 cmpl. | Piston rod 12x355 cmpl. | 1 | — | Check availability | |
| 9 | 48601695S2 Piston rof 12x440 cmpl. | Piston rof 12x440 cmpl. | 1 | — | Check availability | |
| 10 | 48601462S1 SCREW SLEEVE OIL CPL. | SCREW SLEEVE OIL CPL. | 1 | — | Check availability | View Details |
| 11 | 48601452S1 Screw sleeve M35,5x0,8 | Screw sleeve M35,5x0,8 | 1 | — | Check availability | View Details |
| 12 | 48600578S Spring (13,9) 37-32 rebound cp | Spring (13,9) 37-32 rebound cp | 1 | — | Check availability | |
| 13 | 48601820S Spring (22) 60-30 rebound cpl. | Spring (22) 60-30 rebound cpl. | 1 | — | Check availability | |
| 14 | RP10024 Repair kit piston air fork | Repair kit piston air fork | 1 | — | Check availability | |
| 15 | 48602049S Basevalve cpl. | Basevalve cpl. | 1 | — | Check availability | View Details |
| 16 | RP10029 adjuster kit screw cap compres | adjuster kit screw cap compres | 1 | — | Check availability | View Details |
| 17 | 48602048S1 screw cap M51x1,5 cpl. | screw cap M51x1,5 cpl. | 1 | — | Check availability | |
| 18 | 48602047S1 screw cap M51x1,5 cpl. | screw cap M51x1,5 cpl. | 1 | — | Check availability | |
| 19 | 00700007 ISA countersunk head screw M4x | ISA countersunk head screw M4x | 1 | — | Check availability | |
| 20 | 48601494S Schrader valve M8x1 cmpl. | Schrader valve M8x1 cmpl. | 1 | — | Check availability | View Details |
| 21 | 48601671 Fork outer tube 49,13x577 dt54 | Fork outer tube 49,13x577 dt54 | 2 | — | Check availability | View Details |
| 22 | R14047 Guide bushing set fork 48mm | Guide bushing set fork 48mm | 1 | — | Check availability | View Details |
| 23 | RP10012 Sealkit 48mm SKF black | Sealkit 48mm SKF black | 1 | — | Check availability | View Details |
| 24 | 04100002 X-ring 26,57x3,53 FKM80 | X-ring 26,57x3,53 FKM80 | 1 | — | Check availability | |
| 25 | 50180222 O-ring 4x1,5 NBR70 | O-ring 4x1,5 NBR70 | 1 | — | Check availability | |
| 26 | 48601628S Piston 34x35.4 mainpiston Freu | Piston 34x35.4 mainpiston Freu | 1 | — | Check availability | View Details |
| 96 | T14034 Fuchs grease IPR (250g) | Fuchs grease IPR (250g) | 1 | — | Check availability | |
| 97 | 00062010053 special grease AER Fork 400g | special grease AER Fork 400g | 1 | — | Check availability | |
| 98 | 48601166S1 Fork Fluid Viscosity 4.0 5L | Fork Fluid Viscosity 4.0 5L | 1 | — | Check availability | |
| 99 | R14060 SEALING KIT | SEALING KIT | 1 | — | Check availability | View Details |
| 28 | 52000158 Sticker warning 40x40 | Sticker warning 40x40 | 1 | — | Check availability | |
| 29 | 48602007 Stroke indicator 48mm red | Stroke indicator 48mm red | 2 | — | Check availability | |
| 30 | 52000235SET Sticker set XACT 5 AER CC 182. | Sticker set XACT 5 AER CC 182. | 1 | — | Check availability |
