SHOCK ABSORBER DISASSEMBLED
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | S454600021S0000 Shock upper part cpl. KTM 690 | Shock upper part cpl. KTM 690 | 1 | $397.99 | Available | 1 |
| 2 | 46181286S3 Rod link M18x1 h81,5 cpl. | Rod link M18x1 h81,5 cpl. | 1 | $318.39 | Available | 1 |
| 3 | 14460161 Silentblock 10,05x25x32 | Silentblock 10,05x25x32 | 1 | $18.03 | Available | 1 |
| 4 | 46811208 Rubber cap do not open 22x5,5 | Rubber cap do not open 22x5,5 | 1 | $3.62 | Available | 1 |
| 5 | 36120151ST PLUG SCREW M5X6 CPL. | PLUG SCREW M5X6 CPL. | 1 | $4.83 | Available | 1 |
| 6 | S208600003000FB O-ring 5,28x1,78 HNBR70 red | O-ring 5,28x1,78 HNBR70 red | 1 | $0.76 | Available | 1 |
| 7 | 50180095 HS cylinder-head screw R1/8 l8 | HS cylinder-head screw R1/8 l8 | 1 | $2.85 | Available | 1 |
| 8 | 52000215 Sticker APEX 90x40 | Sticker APEX 90x40 | 1 | $31.45 | Available | 1 |
| 9 | 50180213S39 Compression adjuster cpl. Blac | Compression adjuster cpl. Blac | 1 | $94.69 | Out of Stock | Notify Me |
| 10 | 50180218 O-ring 25x1,5 Viton70 | O-ring 25x1,5 Viton70 | 1 | $2.41 | Available | 1 |
| 11 | 46181369S Plastic Spring Retainer d46 cp | Plastic Spring Retainer d46 cp | 1 | $38.60 | Available | 1 |
| 12 | 91010338S SPRING 225MM 69 N/MM | SPRING 225MM 69 N/MM | — | $164.99 | Available | 1 |
| 12 | 91110003S SPRING 220MM 75N/MM (61) | SPRING 220MM 75N/MM (61) | 1 | $177.53 | Available | 1 |
| 12 | 91010367 Mainspring (59/61) 81-225 damp | Mainspring (59/61) 81-225 damp | — | $164.99 | Available | 1 |
| 13 | RP10023T Repair kit spring retainer | Repair kit spring retainer | — | $63.29 | Out of Stock | Notify Me |
| 14 | 50181080 Rubber pad 17x50x54 | Rubber pad 17x50x54 | 1 | $27.82 | Available | 1 |
| 15 | 46180010 Distance bush 10x15/18/24,5x10 | Distance bush 10x15/18/24,5x10 | 2 | $4.83 | Available | 2 |
| 16 | R12012T Ball joint bearing kit top 12m | Ball joint bearing kit top 12m | — | $42.01 | Available | 1 |
| 21 | S23902000000000 round-wire snap ring 49x1,75 | round-wire snap ring 49x1,75 | 1 | $28.49 | Available | 1 |
| 98 | 50180751S1 SHOCK ABSORBER FLUID 5 LT | SHOCK ABSORBER FLUID 5 LT | — | $175.99 | Available | 1 |
| 99 | RP10013T Repair kit ADV. R | Repair kit ADV. R | — | $97.01 | Available | 1 |
| 22 | 46181351 Cover 46,12x15 h5,5 red | Cover 46,12x15 h5,5 red | 1 | $32.55 | Available | 1 |
| 17 | 50180221 O-ring 6x2 Viton70 | O-ring 6x2 Viton70 | 1 | — | Obsolete | View Details |
| 18 | 50181094 Adjustment screw slot | Adjustment screw slot | 1 | $5.82 | Available | 1 |
| 19 | 48600522 Spring (1,6) l4,8 locking spri | Spring (1,6) l4,8 locking spri | 1 | $3.62 | Available | 1 |
| 20 | 40540603 Steel ball d3 | Steel ball d3 | 1 | $1.20 | Available | 1 |
