WIRING HARNESS
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 76911075000 main harness | main harness | 1 | $1007.92 | Available | 1 |
| 2 | 000700000BH SPARE CONNECTOR BH 6-PINS | SPARE CONNECTOR BH 6-PINS | 1 | $26.06 | Available | 1 |
| 3 | 75011088010 FUSE 10A 07 | FUSE 10A 07 | — | $4.99 | Available | 1 |
| 4 | 75011088015 FUSE 15A 07 | FUSE 15A 07 | — | $4.99 | Available | 1 |
| 5 | 75011087050 RUBBER CASING FOR FUSE BOX | RUBBER CASING FOR FUSE BOX | 1 | $13.63 | Available | 1 |
| 6 | 61011055045 EDGE PROTECTOR L=45MM 05 | EDGE PROTECTOR L=45MM 05 | 1 | $3.99 | Available | 1 |
| 8 | 0985060003 Self lock. nut DIN985-M6-A2 | Self lock. nut DIN985-M6-A2 | 1 | $2.99 | Available | 1 |
| 9 | 76511060100 DC horn cpl. | DC horn cpl. | 1 | $41.24 | Available | 1 |
| 10 | 43205062100 silentbloc 20x15-M6x10-(1) | silentbloc 20x15-M6x10-(1) | 1 | $16.38 | Available | 1 |
| 11 | 0024060136 HH collar screw M6x13 TX30 | HH collar screw M6x13 TX30 | 1 | $3.99 | Available | 1 |
| 12 | 61434051000 Shift shaft sensor | Shift shaft sensor | 1 | $154.76 | Available | 1 |
| 13 | 76834052000 Quickshifter sensor cover | Quickshifter sensor cover | 1 | $2.99 | Available | 1 |
| 14 | 78003023070 SPACER BUSH. SPRING BRACKET | SPACER BUSH. SPRING BRACKET | 2 | $1.99 | Available | 2 |
| 15 | 014580050203S Cap hd. screw DIN14580 M5x20 P | Cap hd. screw DIN14580 M5x20 P | 2 | $1.20 | Available | 2 |
| 20 | 44011076140 CABLE TIE 140/2,5MM BLACK | CABLE TIE 140/2,5MM BLACK | — | $1.99 | Available | 1 |
| 20 | 44011076200 Cable tie 200/4.6mm black | Cable tie 200/4.6mm black | — | $1.99 | Available | 1 |
| 20 | 44011076305 CABLE TIE 300/4,8MM BLACK | CABLE TIE 300/4,8MM BLACK | — | $2.99 | Available | 1 |
| 21 | 60011093045 RUBBER CABLE TIE 45MM 03 | RUBBER CABLE TIE 45MM 03 | — | $3.99 | Available | 1 |
| 25 | 76511030000 FLASHER UNIT | FLASHER UNIT | 1 | $27.27 | Available | 1 |
| 28 | 60011034100 VOLTAGE REGULATOR | VOLTAGE REGULATOR | 1 | $188.64 | Available | 1 |
| 29 | 0024060256 HH COLLAR SCREW M6X25 TX30 | HH COLLAR SCREW M6X25 TX30 | 2 | $3.99 | Available | 2 |
| 30 | 54603048100 clip nut M6 | clip nut M6 | 2 | $4.99 | Available | 2 |
| 26 | 27011080000 Cable for flasher | Cable for flasher | 1 | $16.38 | Available | 1 |
| 16 | 61341031300 Control unit EFI | Control unit EFI | 1 | $735.56 | Available | 1 |
| 17 | 60341031050 ECU RUBBER BRACKET | ECU RUBBER BRACKET | 1 | $20.89 | Available | 1 |
