CRANKSHAFT, PISTON
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 76030018100 CRANKSHAFT CPL. | CRANKSHAFT CPL. | 1 | $1290.07 | Available | 1 |
| 2 | 0888040050 woodruff key DIN 6888 4x5x13 | woodruff key DIN 6888 4x5x13 | 1 | $4.99 | Available | 1 |
| 3 | 75030018150 CYL.ROLLER BEARING NJ207 ECPC4 | CYL.ROLLER BEARING NJ207 ECPC4 | 2 | $98.00 | Out of Stock | Notify Me |
| 4 | 56530081000 SHIM WASHER 36X48X0,10 | SHIM WASHER 36X48X0,10 | — | $2.99 | Available | 1 |
| 4 | 56530081100 SHIM WASHER 36X48X0,15 | SHIM WASHER 36X48X0,15 | — | $2.99 | Available | 1 |
| 4 | 56530081200 SHIM WASHER 36X48X0,20 STEEL | SHIM WASHER 36X48X0,20 STEEL | — | $2.99 | Available | 1 |
| 4 | 56530081300 SHIM WASHER 36X48X0,30 | SHIM WASHER 36X48X0,30 | — | $2.99 | Available | 1 |
| 6 | 75032000102 PRIMARY GEAR 36T. | PRIMARY GEAR 36T. | 1 | $194.69 | Available | 1 |
| 7 | 75030029100 NUT FOR PRIMARY GEAR | NUT FOR PRIMARY GEAR | 1 | $12.31 | Available | 1 |
| 8 | 75030055100 DRIVE WHEEL BALANCING SHAFT | DRIVE WHEEL BALANCING SHAFT | 1 | $66.54 | Backorder — Restocking | 1 |
| 9 | 0749080300 TENSION PIN ISO13337 8X30 | TENSION PIN ISO13337 8X30 | 1 | $2.99 | Available | 1 |
| 10 | 75036014100 TIMING PINION | TIMING PINION | 1 | $25.62 | Available | 1 |
| 11 | 0888030050 WOODRUFF KEY DIN6888-3X5X13 | WOODRUFF KEY DIN6888-3X5X13 | 1 | $2.99 | Available | 1 |
| 12 | 6946005 WOODRUFF KEY 5X6,5 HARDED | WOODRUFF KEY 5X6,5 HARDED | 1 | $2.99 | Available | 1 |
| 14 | 0471300151 CIRCLIP DIN0471-30X1,5 NIRO | CIRCLIP DIN0471-30X1,5 NIRO | 1 | $8.90 | Available | 1 |
| 15 | 58132072000 LOCK WASHER VSK 18 | LOCK WASHER VSK 18 | 1 | $2.99 | Available | 1 |
| 16 | 0936181505 HEXAGON NUT DIN0936-M18X1,5 R. | HEXAGON NUT DIN0936-M18X1,5 R. | 1 | $9.12 | Available | 1 |
| 17 | 0760355070 SHAFT SEAL R.35X50X7B VITON | SHAFT SEAL R.35X50X7B VITON | 2 | $12.53 | Available | 2 |
| 18 | 75330015144 CON-ROD REPAIR KIT | CON-ROD REPAIR KIT | 1 | $718.84 | Available | 1 |
| 33 | 61230033000 PISTON PIN D=20 08 | PISTON PIN D=20 08 | 1 | $55.98 | Backorder — Restocking | 1 |
| 34 | 77630074000 CIRCLIP | CIRCLIP | 2 | $12.42 | Available | 2 |
| 40 | 75330007100 I PISTON I CPL. D=102 | PISTON I CPL. D=102 | — | $460.34 | Available | 1 |
| 40 | 75330007100 II PISTON II CPL. D=102 | PISTON II CPL. D=102 | — | $457.81 | Available | 1 |
| 42 | 75330031144 PISTON RING KIT | PISTON RING KIT | 1 | $96.90 | Available | 1 |
| 98 | 00050000224 PISTON KIT GR. I 690 DUKE12-14 | PISTON KIT GR. I 690 DUKE12-14 | — | $522.38 | Available | 1 |
| 98 | 00050000225 PISTON KIT GR. II 690DUKE12-14 | PISTON KIT GR. II 690DUKE12-14 | — | $517.65 | Available | 1 |
| 99 | 00050002305 CRANKSHAFT REP. KIT 690 | CRANKSHAFT REP. KIT 690 | — | $223.62 | Available | 1 |
