COVER
Parts (48)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 2 | A61708062010IAA TANK LH CVR JU181387 GRN MET M | TANK LH CVR JU181387 GRN MET M with decal | 1 | — | Check availability | |
| 4 | A61708062000 SPOILER TANK INNER LH | SPOILER TANK INNER LH | 1 | — | Check availability | |
| 1 | A61708063010IAA TANK RH CVR JU181386 GRN MET M | TANK RH CVR JU181386 GRN MET M with decal | 1 | — | Check availability | |
| 3 | A61708063000 SPOILER TANK INNER RH | SPOILER TANK INNER RH | 1 | — | Check availability | |
| 6 | A61706005000 COVER FILTER AIR | COVER FILTER AIR | 1 | — | Check availability | |
| 5 | A61708064000 COVER SHOCKABSORBER | COVER SHOCKABSORBER | 1 | — | Check availability | |
| 30 | 93003077000 Clip nut M6 | Clip nut M6 | 8 | — | Check availability | |
| 10 | A61708052000 COVER TOP | COVER TOP | 1 | — | Check availability | |
| 11 | A61711068000 COVER SWITCH IGNITION | COVER SWITCH IGNITION | 1 | — | Check availability | |
| 27 | A61712010010 COLLAR | COLLAR | 2 | — | Check availability | |
| 28 | J900000602011 BOLT SOCKET M6X1 | BOLT SOCKET M6X1 | 2 | — | Check availability | |
| 43 | J900000600904 special screw M6x15-8.8-hexago | special screw M6x15-8.8-hexago | 2 | — | Check availability | |
| 45 | J900000601607 SCREW SOCKET M6X1 | SCREW SOCKET M6X1 | 2 | — | Check availability | |
| 12 | A61711066010 GROMMET SWITCH IGNITION | GROMMET SWITCH IGNITION | 1 | — | Check availability | |
| 46 | 96308077000 pin quick release M8 | pin quick release M8 | 1 | — | Check availability | |
| 42 | J900000601501 screw socket step M6x1 | screw socket step M6x1 | 8 | — | Check availability | |
| 37 | 93007040010 Seat cowl pad | Seat cowl pad | 2 | — | Check availability | |
| 36 | J650002001400 Rubber grommet | Rubber grommet | 4 | — | Check availability | |
| 9 | A61712010000 RACK TANK | RACK TANK | 1 | — | Check availability | |
| 21 | A61708021020 BRACKET BELLY PAN FRONT UPPER | BRACKET BELLY PAN FRONT UPPER | 1 | — | Check availability | |
| 26 | J900000605007 BOLT FLANGED M6X1 | BOLT FLANGED M6X1 | 2 | — | Check availability | |
| 20 | A61708021010 BRACKET ASSY BELLY PAN FRONT L | BRACKET ASSY BELLY PAN FRONT L | 1 | — | Check availability | |
| 40 | 93008028050 Rubber bushing | Rubber bushing | 2 | — | Check availability | |
| 39 | 93035065030 distance sleeve | distance sleeve | 2 | — | Check availability | |
| 38 | J900000602005 socket screw M6x20 | socket screw M6x20 | 2 | — | Check availability | |
| 22 | A61308021030 BRACKET ASSEMBLY BELLY PAN REA | BRACKET ASSEMBLY BELLY PAN REA | 1 | — | Check availability | |
| 23 | A61308021040 DAMPER | DAMPER | 2 | — | Check availability | |
| 24 | J800000709000 SLEEVE | SLEEVE | 1 | — | Check availability | |
| 25 | J900000610501 BOLT FLANGED M6X1 | BOLT FLANGED M6X1 | 1 | — | Check availability | |
| 19 | A61708020000 BELLY PAN | BELLY PAN | 1 | — | Check availability | |
| 47 | J900000601206 Allen head screw M6x12 | Allen head screw M6x12 | 4 | — | Check availability | |
| 41 | J900000601207 SCREW SOCKET STEP M6X1 | SCREW SOCKET STEP M6X1 | 2 | — | Check availability | |
| 15 | A61735032000CCA JU181394 RADTR RH CVR BLK BLU | JU181394 RADTR RH CVR BLK BLU with decal | 1 | — | Check availability | |
| 16 | A61735031000CCA JU181393 RADTR LH CVR BLK BLU | JU181393 RADTR LH CVR BLK BLU | 1 | — | Check availability | |
| 18 | A61735031050 BRACKET COVER RADIATOR LH | BRACKET COVER RADIATOR LH | 1 | — | Check availability | |
| 17 | A61735032050 BRACKET COVER RADIATOR RH | BRACKET COVER RADIATOR RH | 1 | — | Check availability | |
| 31 | J690000710000 washer | washer | 4 | — | Check availability | |
| 33 | J900000501301 SCREW TAPPING PAN CROSS ST4.8 | SCREW TAPPING PAN CROSS ST4.8 | 4 | — | Check availability | |
| 32 | J800000700602 SLEEVE SAI UNIT | SLEEVE SAI UNIT | 4 | — | Check availability | |
| 29 | J900000601900 AH oval head screw M6x19 | AH oval head screw M6x19 | 4 | — | Check availability | |
| 34 | J690000608000 WASHER PLAIN | WASHER PLAIN | 4 | — | Check availability | |
| 8 | A61708041000CCA SIDE LH CVR JU181702 BLK BLUE | SIDE LH CVR JU181702 BLK BLUE with decal | 1 | — | Check availability | |
| 7 | A61708042000CCA SIDE RH CVR JU181303 BLK BLUE | SIDE RH CVR JU181303 BLK BLUE with decal | 1 | — | Check availability | |
| 44 | J900000601207 SCREW SOCKET STEP M6X1 | SCREW SOCKET STEP M6X1 | 7 | — | Check availability | |
| 14 | 96303083010 frame cover left front | frame cover left front | 1 | — | Check availability | |
| 13 | 96303083020 frame cover right front | frame cover right front | 1 | — | Check availability | |
| 35 | 96303083030 Frame cover left | Frame cover left | 1 | — | Check availability | |
| 48 | 93014014000 Rubber bushing | Rubber bushing | 1 | — | Check availability |
