LUBRICATING SYSTEM
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 55638070033 Oilfillercap cpl. | Oilfillercap cpl. | 1 | — | Check availability | |
| 2 | 55638061020 Filler plug oil tank | Filler plug oil tank | 1 | — | Check availability | |
| 3 | 55638062000 Oil level sensor | Oil level sensor | 1 | — | Check availability | |
| 4 | 55638065200 Tube | Tube | 1 | — | Check availability | |
| 5 | 55738061060 Angle piece oil tank | Angle piece oil tank | 1 | — | Check availability | |
| 6 | 55738061200 Oil tank | Oil tank | 1 | — | Check availability | |
| 7 | 61238016100 Oil Screen | Oil Screen | 1 | — | Check availability | View Details |
| 8 | 55641075000 Crankcase Presure Sensor CCP | Crankcase Presure Sensor CCP | 2 | — | Check availability | |
| 9 | 55738061070 Sensor cover | Sensor cover | 1 | — | Check availability | |
| 10 | 55738061040 Oil pump bracket | Oil pump bracket | 1 | — | Check availability | |
| 11 | 0025060126S Hex collar screw M6x12 ISA30 s | Hex collar screw M6x12 ISA30 s | 2 | — | Check availability | |
| 12 | 55638064000 Oil pump | Oil pump | 1 | — | Check availability | |
| 13 | 00050271708 VARIABLE ONE-EAR CLAMP 27,1MM | VARIABLE ONE-EAR CLAMP 27,1MM | 3 | — | Check availability | |
| 14 | 0081645121 EJOT DELTA PT SCREW 45X12-Z | EJOT DELTA PT SCREW 45X12-Z | 3 | — | Check availability | |
| 15 | 0081050181 SCREW FOR PLASTIC K50X18 T20 | SCREW FOR PLASTIC K50X18 T20 | 2 | — | Check availability | |
| 16 | 59007017000 CLAMP YDNAC 10096F (9,6MM) | CLAMP YDNAC 10096F (9,6MM) | 1 | — | Check availability | |
| 17 | 58431082100 YDNAC-clamp 10173 (16MM) | YDNAC-clamp 10173 (16MM) | 1 | — | Check availability | |
| 18 | 55538086000 Clamp 1 | Clamp 1 | 2 | — | Check availability | |
| 19 | 55538087000 Clamp 2 | Clamp 2 | 2 | — | Check availability | |
| 20 | 55538083044 Tube set, oil tank | Tube set, oil tank | 1 | — | Check availability | |
| 21 | 0025060506 HH collar screw M6x50 TX30 | HH collar screw M6x50 TX30 | 1 | — | Check availability | |
| 22 | 55738061052 Damping rubber | Damping rubber | 2 | — | Check availability |
