TANK, SEAT
Parts (38)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 28507013099 fuel tank cpl. | fuel tank cpl. | 1 | $396.87 | Available | 1 |
| 2 | 69007027000 rubber grommet, tank mounting | rubber grommet, tank mounting | 2 | $3.99 | Available | 2 |
| 3 | 61007065000 collar bushing, front tank hol | collar bushing, front tank hol | 2 | $9.23 | Available | 2 |
| 4 | 77307040041 Isolation pad | Isolation pad | 5 | $2.99 | Available | 5 |
| 5 | 28515023000 Reducer GRS8-6 | Reducer GRS8-6 | 1 | $13.74 | Available | 1 |
| 6 | 0025080306 HH collar screw M8x30 | HH collar screw M8x30 | 6 | $3.62 | Available | 6 |
| 7 | 0024060156 HH collar screw M6x15 TX30 | HH collar screw M6x15 TX30 | 4 | $3.99 | Available | 4 |
| 8 | 31008060000 rubber grommet D=8mm open | rubber grommet D=8mm open | 2 | $2.99 | Available | 2 |
| 9 | 0912080403 AH collar screw DIN0912 M8x40 | AH collar screw DIN0912 M8x40 | 1 | $2.99 | Available | 1 |
| 10 | 61007060000 collar bushing, bearing, outsi | collar bushing, bearing, outsi | 1 | $11.65 | Available | 1 |
| 11 | 77407011000 screw, seat M5 | screw, seat M5 | 1 | $12.20 | Available | 1 |
| 12 | 28007040000 seat | seat | 1 | $184.35 | Available | 1 |
| 13 | 21007008151 gasket tank insert | gasket tank insert | 1 | $16.49 | Available | 1 |
| 14 | 28507008060 gasket, upper tank insert | gasket, upper tank insert | 1 | $6.15 | Available | 1 |
| 15 | 47106003160 quick release rubber grommet | quick release rubber grommet | 2 | $4.99 | Available | 2 |
| 16 | 28508057000CCA Cover, ignition lock | Cover, ignition lock | 1 | $198.65 | Available | 1 |
| 17 | 014580060451 Cap hd. screw ISO 14580-M6x45- | Cap hd. screw ISO 14580-M6x45- | 4 | $2.99 | Available | 4 |
| 18 | 28508057010 Bushing ignition switch | Bushing ignition switch | 4 | $7.47 | Available | 4 |
| 19 | 014579050301 Screw ISO 14579-M5x30-8.8-P3R | Screw ISO 14579-M5x30-8.8-P3R | 3 | $1.99 | Available | 3 |
| 21 | 28507059000 rubber grommet, ignition lock | rubber grommet, ignition lock | 1 | $12.97 | Available | 1 |
| 22 | 28508058020 rubber grommet, adapter | rubber grommet, adapter | 1 | $4.99 | Available | 1 |
| 23 | 58314060050 spacer bushing for speedometer | spacer bushing for speedometer | 2 | $6.15 | Available | 2 |
| 24 | 28508058000 Tank Spider | Tank Spider | 1 | $50.37 | Available | 1 |
| 25 | 28503002010 rubber support | rubber support | 4 | $4.99 | Available | 4 |
| 26 | 28507050050 Seat lever assy | Seat lever assy | 1 | $12.20 | Available | 1 |
| 27 | 0738060181 BHCS ISO 7380 M6X18 | BHCS ISO 7380 M6X18 | 2 | $2.99 | Available | 2 |
| 28 | 60015025100 Y-CONNECTING PIECE YS 6-6-6 06 | Y-CONNECTING PIECE YS 6-6-6 06 | 1 | $6.15 | Available | 1 |
| 29 | 014579050081 Screw ISO 14579 M5x08-8.8-P3R | Screw ISO 14579 M5x08-8.8-P3R | 3 | $1.99 | Available | 3 |
| 30 | 28512010000 Passenger grip | Passenger grip | 1 | $90.63 | Available | 1 |
| 33 | 28007047000 pillion seat | pillion seat | 1 | $162.46 | Out of Stock | Notify Me |
| 34 | 83008000012 special screw M6x12x3 | special screw M6x12x3 | 1 | $3.99 | Available | 1 |
| 36 | 28012010010 collar bushing | collar bushing | 4 | $8.57 | Available | 4 |
| 31 | 28012010000 Luggage Carrier | Luggage Carrier | 2 | $45.64 | Available | 2 |
| 32 | 28507040030 rubber grommet, seat cover | rubber grommet, seat cover | 2 | $3.99 | Available | 2 |
| 37 | 58605083014 Oval head screw M5x14 TX25 | Oval head screw M5x14 TX25 | 2 | $3.99 | Available | 2 |
| 38 | 0019050121 COUNTERSUNK SCREW ISA25 M5X12 | COUNTERSUNK SCREW ISA25 M5X12 | 1 | $2.99 | Available | 1 |
| 39 | 28515024001 Hose 8x13 FKM/ECO | Hose 8x13 FKM/ECO | — | $77.65 | Available | 1 |
| 40 | 78015019001 HOSE EPA D=6/10 PER METER | HOSE EPA D=6/10 PER METER | — | $73.69 | Available | 1 |
