FRONT FORK, TRIPLE CLAMP
Parts (28)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 28301001000 LEG ASSEMBLY LH | LEG ASSEMBLY LH | 1 | — | Check availability | |
| 2 | 28301002000 LEG ASSEMBLY RH | LEG ASSEMBLY RH | 1 | — | Check availability | |
| 3 | 90501044000 steering head screw | steering head screw | 1 | — | Check availability | |
| 4 | 90101036100 Adjusting ring steering head | Adjusting ring steering head | 1 | — | Check availability | |
| 5 | 90101086000 protection cap | protection cap | 1 | — | Check availability | |
| 6 | 90101080044 STEERING HEAD BEARING-KIT | STEERING HEAD BEARING-KIT | 1 | — | Check availability | |
| 7 | 28301031033C1 BRACKET ASSLY UNDER BLACK MATT | BRACKET ASSLY UNDER BLACK MATT | 1 | — | Check availability | |
| 8 | 90501045000 AH SCREW M8X1.25X30 | AH SCREW M8X1.25X30 | 8 | — | Check availability | |
| 9 | 28113026000 Brake line holder, front | Brake line holder, front | 1 | — | Check availability | |
| 10 | 90113055010 sleeve for hose clamp | sleeve for hose clamp | 4 | — | Check availability | |
| 11 | J021060156 AH SCREW M6X15 10.9 | AH SCREW M6X15 10.9 | 4 | — | Check availability | |
| 12 | 90212582001 side reflector, front | side reflector, front | 2 | — | Check availability | |
| 13 | 28301034033C1 Triple clamp top | Triple clamp top | 1 | — | Check availability | |
| 14 | 90101041000 SPACER TUBE | SPACER TUBE | 2 | — | Check availability | |
| 15 | 90101040000 RUBBER BUSHING | RUBBER BUSHING | 4 | — | Check availability | |
| 16 | 90101042000 WASHER 10,5X32X2 | WASHER 10,5X32X2 | 4 | — | Check availability | |
| 17 | 28101039000 Handlebar mount | Handlebar mount | 1 | — | Check availability | |
| 18 | J912100706 Hexagon socket screw. M10x70 | Hexagon socket screw. M10x70 | 2 | — | Check availability | |
| 19 | 28101038000 Handlebar clamp | Handlebar clamp | 1 | — | Check availability | |
| 20 | J912080293 Bolt socket-M8X1.25Xl 29Xblack | Bolt socket-M8X1.25Xl 29Xblack | 4 | — | Check availability | |
| 21 | J926100006 Hex collar nut, M10 | Hex collar nut, M10 | 2 | — | Check availability | |
| 23 | 43578014 GUIDE BUSH LOWER | GUIDE BUSH LOWER | 2 | — | Check availability | |
| 24 | 43578044 CIRCLIP | CIRCLIP | 2 | — | Check availability | |
| 25 | 43578219 O-ring 40x2,5 VMQ70 red ISO 36 | O-ring 40x2,5 VMQ70 red ISO 36 | 2 | — | Check availability | View Details |
| 26 | 90201025000 FORK FRONT DUST COVER | FORK FRONT DUST COVER | 2 | — | Check availability | |
| 42 | 43570618 Guide bushing 43x47x12 | Guide bushing 43x47x12 | 2 | — | Check availability | |
| 43 | 43570623 Shaft seal SKF 43x52,9x11,4 bl | Shaft seal SKF 43x52,9x11,4 bl | 2 | — | Check availability | |
| 44 | 43570723 Dirt scarper SKF 43mm red | Dirt scarper SKF 43mm red | 2 | — | Check availability | View Details |
