ENGINE CASE
Parts (37)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 96230000044C1 Crankcase CPL | Crankcase CPL | 1 | $868.59 | Out of Stock | Notify Me |
| 2 | J625062122 BALL BEARING 15X35X11-C3-1 | BALL BEARING 15X35X11-C3-1 | 2 | $19.24 | Available | 2 |
| 3 | J410002001400 bearing ball-id 20xod 47xthk 1 | bearing ball-id 20xod 47xthk 1 | 1 | $11.54 | Out of Stock | Notify Me |
| 4 | 90230079000 STOPPER BALANCER SHAFT BEARING | STOPPER BALANCER SHAFT BEARING | 2 | $1.99 | Available | 2 |
| 5 | J01665060123S Hex collar screw, M6x12 | Hex collar screw, M6x12 | 2 | $13.74 | Available | 2 |
| 6 | 90130004004 Bearing ball | Bearing ball | 1 | $18.01 | Available | 1 |
| 8 | J618131912 NEEDLE ROLLER BEARING HK1312 | NEEDLE ROLLER BEARING HK1312 | 2 | $6.15 | Available | 2 |
| 9 | 90234030000 BUSH SHIFT RAIL | BUSH SHIFT RAIL | 2 | $2.99 | Available | 2 |
| 10 | J760122455 SHAFT SEALING RING 12X24X5,5 | SHAFT SEALING RING 12X24X5,5 | 1 | $9.12 | Available | 1 |
| 11 | 0760122406 Shaft seal ring 12x24x6 | Shaft seal ring 12x24x6 | 1 | $6.92 | Available | 1 |
| 12 | J625062041 BALL BEARING 6204-Z/HN3 | BALL BEARING 6204-Z/HN3 | 1 | $13.08 | Available | 1 |
| 13 | J710003012000 Lock ring for hubs | Lock ring for hubs | 1 | $0.99 | Available | 1 |
| 14 | J025060104 Hex collar screw M6X10 | Hex collar screw M6X10 | 1 | $1.99 | Available | 1 |
| 16 | 90140020002 BRACKET F. FREE WHEEL GEAR | BRACKET F. FREE WHEEL GEAR | 1 | $1.99 | Available | 1 |
| 17 | J025060141 Hex collar screw M6X14 | Hex collar screw M6X14 | 1 | $1.99 | Available | 1 |
| 18 | 90230022000 Pipe breather | Pipe breather | 1 | $3.99 | Available | 1 |
| 19 | J011050133 HH COLLAR SCREW M5X13 SW8 | HH COLLAR SCREW M5X13 SW8 | 2 | $1.99 | Available | 2 |
| 20 | 90238029003 OIL NOZZLE | OIL NOZZLE | 1 | $0.39 | Out of Stock | Notify Me |
| 21 | 90130003004 Seal - oil | Seal - oil | 1 | $2.99 | Available | 1 |
| 22 | J790001903000 Seal Oil | Seal Oil | 1 | $1.99 | Available | 1 |
| 23 | 90230066300 OIL NOZZLE | OIL NOZZLE | 1 | $1.99 | Available | 1 |
| 27 | 96211023100 sensor indicator gear | sensor indicator gear | 1 | $69.29 | Available | 1 |
| 28 | J770002024000 O RING | O RING | 1 | $0.99 | Available | 1 |
| 29 | J025050163S FLANGED BOLT M5X16 | FLANGED BOLT M5X16 | 2 | $1.99 | Available | 2 |
| 30 | 96239034000 Crankshaft position sensor | Crankshaft position sensor | 1 | $15.00 | Available | 1 |
| 31 | J900000607001 bolt flanged M6x1 | bolt flanged M6x1 | 9 | $0.99 | Available | 9 |
| 32 | J025060350 FLANGED BOLT M6X35 WS8 | FLANGED BOLT M6X35 WS8 | 5 | $1.99 | Available | 5 |
| 33 | 96204060000 GUARD CHAIN | GUARD CHAIN | 1 | $6.48 | Out of Stock | Notify Me |
| 34 | J005060123S SCREW PAN CROSS M6X12 PH SS | SCREW PAN CROSS M6X12 PH SS | 3 | $1.99 | Available | 3 |
| 35 | 96203096000 COVER REAR LH | COVER REAR LH | 1 | $6.48 | Out of Stock | Notify Me |
| 36 | J900000601607 SCREW SOCKET M6X1 | SCREW SOCKET M6X1 | 3 | $0.99 | Available | 3 |
| 39 | 90130164000 OIL NOZZLE | OIL NOZZLE | 2 | $32.44 | Available | 2 |
| 42 | 90130003007 DOWEL D14 | DOWEL D14 | 4 | $2.99 | Available | 4 |
| 43 | 90130024000 PIN DOWEL 8X6,4X14MM | PIN DOWEL 8X6,4X14MM | 1 | $1.99 | Available | 1 |
| 44 | J011080203S FLANGED BOLT M8X20 | FLANGED BOLT M8X20 | 1 | $1.99 | Available | 1 |
| 45 | J603061001 COPPER GASKET | COPPER GASKET | 1 | $1.99 | Backorder — Restocking | 1 |
| 47 | J900000608500 bolt flanged M6x1 | bolt flanged M6x1 | 2 | $0.99 | Out of Stock | Notify Me |
