SUBFRAME
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 21003002210C1 Tail braceing | Tail braceing | 1 | — | Check availability | |
| 2 | 0025080406 HH COLLAR SCREW M8X40 TX40 | HH COLLAR SCREW M8X40 TX40 | 4 | — | Check availability | |
| 3 | 21003002001ABA left subframe | left subframe | 1 | — | Check availability | |
| 4 | 21003002002ABA right subframe | right subframe | 1 | — | Check availability | |
| 5 | 21103048000C1A Rear footpeg bracket left | Rear footpeg bracket left | 1 | — | Check availability | |
| 7 | 21103049000C1A Rear footpeg bracket right | Rear footpeg bracket right | 1 | — | Check availability | |
| 8 | 0015080256S HH COLLAR SCREW M8X25 WS=10 | HH COLLAR SCREW M8X25 WS=10 | 2 | — | Check availability | |
| 9 | 21003950044 Footpeg set | Footpeg set | 1 | — | Check availability | |
| 11 | 60003152000 ENGAGE PANEL FOOTREST L/S 03 | ENGAGE PANEL FOOTREST L/S 03 | 2 | — | Check availability | |
| 13 | 60003052000 ENGAGE PANEL FOOTREST R/S 03 | ENGAGE PANEL FOOTREST R/S 03 | 2 | — | Check availability | |
| 14 | 60003044000 BOLT FOR FOOTREST REAR 03 | BOLT FOR FOOTREST REAR 03 | 2 | — | Check availability | |
| 15 | 0799060003 retaining washer DIN 6799 - 6 | retaining washer DIN 6799 - 6 | 2 | — | Check availability | |
| 16 | 21003089000 Plug | Plug | 4 | — | Check availability | |
| 17 | 0025060126 HH collar screw M6x12 TX30 | HH collar screw M6x12 TX30 | 2 | — | Check availability | |
| 18 | 0035100209 AH collar screw M10x20 ISA45 | AH collar screw M10x20 ISA45 | 4 | — | Check availability | |
| 19 | 0035080306S AH collar screw M8x30 ISA45 | AH collar screw M8x30 ISA45 | 4 | — | Check availability | |
| 20 | 21007057000 Seat pulling strap | Seat pulling strap | 1 | — | Check availability | |
| 21 | 0025060406 HH collar screw M6x40 TX30 | HH collar screw M6x40 TX30 | 2 | — | Check availability | |
| 22 | 21108041020 Shim | Shim | 1 | — | Check availability |
